Philips LCD Monitor Electronic User's Manual
file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/INDEX.HTM4/3/2009 9:47:33 AM

Advertisement

Table of Contents
loading

Related Manuals for Philips 220V

Summary of Contents for Philips 220V

  • Page 1 Philips LCD Monitor Electronic User’s Manual file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/INDEX.HTM4/3/2009 9:47:33 AM...

  • Page 2: Safety And Troubleshooting Information

    DC power cord for normal operation. Please use approved power cord provided by Philips all the time. If your power cord is missing, please contact with your local service center. (Please refer to Customer Care Consumer Information Center) Do not subject the LCD monitor to severe vibration or high impact conditions during operation.
  • Page 3 Safety and Troubleshooting Information Service: ● ● ● ● file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/safety/safety.htm（第 2／2 页）4/3/2009 9:47:36 AM The casing cover should be opened only by qualified service personnel. If there is any need for any document for repair or integration, please contact with your local service center. (please refer to the chapter of "Consumer Information Center") For transportation information, please refer to "Physical Specifications".

  • Page 4: Faqs (Frequently Asked Questions)

    Restart your computer and repeat step 2 and 3 to verify that your PC is set at 1680 x 1050@60Hz . Shut down your computer, disconnect your old monitor and reconnect your Philips LCD monitor. Turn on your monitor and then turn on your PC.
  • Page 5 FAQs (Frequently Asked Questions) What if I get lost when I am making monitor adjustments? What is the Auto function? of a single button – without the need to navigate through OSD (On Screen Display) menus and control keys. Note: My Monitor has no power (Power LED does not light up).

  • Page 6: Screen Adjustments

    Neutral temperature is white, at 6504K. Can the Philips LCD Monitor be mounted on the wall? allows the user to mount the Philips monitor on most of the VESA standard arms or accessories. We recommend to contact your Philips sales representative for more information.

  • Page 7: Compatibility With Other Peripherals

    FAQs (Frequently Asked Questions) Compatibility with other Peripherals Are Philips LCD monitors Plug-and-Play? LCD Panel Technology What is a Liquid Crystal Display? and images on digital items such as watches, calculators, portable game consoles, etc. LCD is the technology used for displays in notebooks and other small computers. Like light-emitting diode and gas- plasma technologies, LCD allows displays to be much thinner than cathode ray tube (CRT) technology.
  • Page 8 FAQs (Frequently Asked Questions) has two glass panels and the space between them is filled with liquid crystal. When each cell is connected with electrodes and impressed with voltage, the molecular structure of the liquid crystal is altered and controls the amount of inlet lighting to display images. A TFT LCD has several advantages over a CRT, since it can be very thin and no flickering occurs because it does not use the scanning method.
  • Page 9 FAQs (Frequently Asked Questions) file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/safety/saf_faq.htm（第 6／6 页）4/3/2009 9:47:47 AM...

  • Page 10: Troubleshooting

    • Safety and Troubleshooting • FAQs This page deals with problems that can be corrected by a user. If the problem still persists after you have tried these solutions, contact Philips • Common Problems customer service representative. • Imaging Problems Common Problems •...
  • Page 11 The after-image will disappear after a peroid of time. The remaining dots are normal characteristic of the liquid crystal used in ● today’s technology. Consumer Information Centers list and contact Philips customer service representative. RETURN TO TOP OF THE PAGE...

  • Page 12: Regulatory Information

    (FCC Declaration) From the planning, design and production stages, Philips emphasizes the important of making products that can easily be • EN 55022 Compliance (Czech Republic recycled. At Philips, end-of-life management primarily entails participation in national take-back initiatives and recycling Only) programs whenever possible, preferably in cooperation with competitors.
  • Page 13 < 29.8 (typ.) OFF (Sleep) Amber < 0.8 W Switch Off < 0.5 W ® PHILIPS s an NERGY artner, has determined that this product meets the ® guidelines for energy efficiency. We recommend you switch off the monitor when it is not in use for a long time.

  • Page 14: Fcc Declaration Of Conformity

    Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. RETURN TO TOP OF THE PAGE Trade Name: Philips Philips Consumer Electronics North America P.O. Box 671539 Responsible Party: Marietta , GA 30006-0026...
  • Page 15 Regulatory Information Commission Federale de la Communication (FCC Declaration) Réorienter ou déplacer l'antenne de réception. ● Augmenter la distance entre l'équipement et le récepteur. ● Brancher l'équipement sur un autre circuit que celui utilisé par le récepteur. ● Demander l'aide du marchand ou d'un technicien chevronné en radio/télévision. ●...
  • Page 16 Regulatory Information be located near the equipment and easily accessible. A protection mark "B" confirms that the equipment is in compliance with the protection usage requirements of standards PN-93/ T-42107 and PN-89/E-06251. North Europe (Nordic Countries) Information Placering/Ventilation VARNING: FÖRSÄKRA DIG OM ATT HUVUDBRYTARE OCH UTTAG ÄR LÄTÅTKOMLIGA, NÄR DU STÄLLER DIN UTRUSTNING PÅPLATS.
  • Page 17 Regulatory Information Paikka/Ilmankierto VAROITUS: SIJOITA LAITE SITEN, ETTÄ VERKKOJOHTO VOIDAAN TARVITTAESSA HELPOSTI IRROTTAA PISTORASIASTA. Plassering/Ventilasjon ADVARSEL: NÅR DETTE UTSTYRET PLASSERES, MÅ DU PASSE PÅ AT KONTAKTENE FOR STØMTILFØRSEL ER LETTE Å NÅ. BSMI Notice (Taiwan Only) Ergonomie Hinweis (nur Deutschland) Der von uns gelieferte Farbmonitor entspricht den in der "Verordnung über den Schutz vor Schäden durch Röntgenstrahlen"...
  • Page 18 Please find out about the local regulations on how to dispose of your old monitor from your local Philips dealer. (For customers in Canada and U.S.A.) This product may contain lead and/or mercury.

  • Page 19: China Rohs

    Regulatory Information China RoHS The People's Republic of China released a regulation called "Management Methods for Controlling Pollution by Electronic Information Products" or commonly referred to as China RoHS. All products including CRT and LCD monitor which are produced and sold for China market have to meet China RoHS request. file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/safety/regs/regulat.htm（第...
  • Page 20 Regulatory Information RETURN TO TOP OF THE PAGE file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/safety/regs/regulat.htm（第 9／9 页）4/3/2009 9:47:55 AM...

  • Page 21: About This Manual

    • Notational Descriptions About This Guide This electronic user's guide is intended for anyone who uses the Philips LCD Monitor. It describes the LCD monitor's features, setup, operation and other important information. Its contents are identical to the information in our printed version.
  • Page 22 ©2009 Koninklijke Philips Electronics NV All rights reserved. Reproduction, copying, use, modification, hiring, renting, public performance, transmission and/or broadcasting in whole or in part is prohibited without written consent of Philips Electronics NV file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/about/about.htm（第 2／2 页）4/3/2009 9:48:01 AM NOTE: This icon indicates important information and tips that help you make better use of your computer system.

  • Page 23: Product Information

    • Horizontal Frequency file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/product/product.htm（第 1／6 页）4/3/2009 9:48:06 AM Philips eliminated toxic substances like lead from its displays. Lead-free display helps protect your health and promotes environmentally sound recovery and disposal of waste from electrical and electronic equipment.Philips complies with the European Community stringent RoHS Directive mandating restrictions on hazardous substances in electrical and electronic equipment.

  • Page 24: Resolution & Preset Modes

    Product Information VIDEO • Video dot rate • Input impedance - Video - Sync • Input signal levels • Sync input signal • Sync polarities * This data is subject to change without notice. Resolution & Preset Modes A. Maximum Resolution For 220V1 1680 x 1050 at 75Hz (analog input) 1680 x 1050 at 75Hz (digital input)

  • Page 25: Automatic Powersaving

    Product Information 1680 x 1050 at 60Hz (digital input) 12 factory preset modes: H. freq (kHz) Automatic Power Saving If you have VESA DPMS compliance display card or software installed in your PC, the monitor can automatically reduce its power consumption when not in use.

  • Page 26: Physical Specifications

    • System MTBF • Cabinet color Pin Assignment The 15-pin D-sub connector (male) of the signal cable: Pin No. file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/product/product.htm（第 4／6 页）4/3/2009 9:48:06 AM ® ® PHILIPS NERGY compliant. s an NERGY artner, ® NERGY guidelines for energy efficiency.

  • Page 27: Product Views

    Product Information Product Views Follow the links to see various views of the monitor and its components. Front View Product Description Physical Function Tilt file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/product/product.htm（第 5／6 页）4/3/2009 9:48:06 AM Blue video input Sense (GND) Cable detect (GND) Red video ground Green video ground Blue video ground RETURN TO TOP OF THE PAGE...
  • Page 28 Product Information RETURN TO TOP OF THE PAGE file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/product/product.htm（第 6／6 页）4/3/2009 9:48:06 AM...

  • Page 29: Philips' Flat Panel Monitors Pixel Defect Policy

    TFT LCD panel must exceed these acceptable levels. For example, no more than 0.0004% of the sub pixels on a XGA monitor may be defective. Furthermore, Philips sets even higher quality standards for certain types or combinations of pixel defects that are more noticeable than others.
  • Page 30 Pixel Defect Tolerances In order to qualify for repair or replacement due to pixel defects during the warranty period, a TFT LCD panel in a Philips flat panel monitor must have pixel or sub pixel defects exceeding the tolerances listed in the following tables.
  • Page 31 Philips Pixel Defect Policy BLACK DOT DEFECTS MODEL 1 dark subpixel 2 adjacent dark subpixels 3 adjacent dark subpixels Distance between two black dot defects* Total black dot defects of all types TOTAL DOT DEFECTS MODEL Total bright or black dot defects of all types...

  • Page 32: Installing Your Lcd Monitor

    Installing Your LCD Monitor Installing Your LCD Monitor • Front View Produt Description • Connecting to Your PC Front View Product Description • The Base • Getting Started • Optimizing Performance file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/install/install.htm（第 1／3 页）4/3/2009 9:48:16 AM To switch monitor's power On and Off To access OSD menu MENU / OK To adjust brightness of the display...

  • Page 33: Rear View

    Installing Your LCD Monitor Rear View Optimizing Performance For best performance, ensure that your display settings are set at 1680 x 1050, 60Hz. ● file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/install/install.htm（第 2／3 页）4/3/2009 9:48:16 AM Return to previous OSD level. RETURN TO TOP OF THE PAGE Kensington anti-thief lock AC power input DVI-D(available for selective models）...
  • Page 34 Installing Your LCD Monitor file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/install/install.htm（第 3／3 页）4/3/2009 9:48:16 AM Note: You can check the current display settings by pressing the 'MENU' button once. The current display mode is shown in OSD main controls called RESOLUTION. RETURN TO TOP OF THE PAGE...

  • Page 35: Connecting To Your Pc

    Connecting to Your PC Connecting to Your PC • Front View Product Description Accessory Pack • Accessory Pack Unpack all the parts. • Connecting to Your PC • Getting Started • Optimizing Performance • The base file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/install/connect.htm（第 1／3 页）4/3/2009 9:48:19 AM Power cord VGA cable EDFU pack...
  • Page 36 Connecting to Your PC Connecting to Your PC Connect the power cord to the back of the monitor firmly. Connect to PC file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/install/connect.htm（第 2／3 页）4/3/2009 9:48:19 AM DVI input (available for selective models) DVI input (available for selective models) Turn off your computer and unplug its power cable.
  • Page 37 Connecting to Your PC Turn on your computer and monitor. If the monitor displays an image, installation is complete. RETURN TO TOP OF THE PAGE file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/install/connect.htm（第 3／3 页）4/3/2009 9:48:19 AM...

  • Page 38: Remove The Base

    The Base The Base • Front View Product Description Remove the Base • Accessory Pack Condition: • Connecting to your PC for VESA standard mounting applications • Getting Started ● • Optimizing Performance Remove the 3 screws and then remove the base from the LCD monitor. •...
  • Page 39 The Base RETURN TO TOP OF THE PAGE file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/install/base.htm（第 2／2 页）4/3/2009 9:48:24 AM...

  • Page 40: Your Lcd Monitor

    The built-in VESA DDC2B feature in Philips Monitors supports Plug & Play requirements for Windows® 95/98/2000/ Me/XP/Vista. This information file ( .inf) should be installed in order that your Philips monitor can be enabled from the 'Monitor' dialog box in Windows® 95/98/2000/Me/XP/Vista and the Plug & Play application can be activated. The installation procedure based on Windows®...

  • Page 41: For Windows® Me

    Getting Started For Windows® Me For Windows® XP file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/install/gt_start.htm（第 2／3 页）4/3/2009 9:48:28 AM Select 'Monitor' - If the 'Properties' button is inactive, it means your monitor is properly configured. Please stop installation. - If the 'Properties' button is active. Click on 'Properties' button. Please follow the steps given below. Click on 'Driver' and then click on 'Update Driver...' then click on the 'Next' button.

  • Page 42: For Windows Vista

    Getting Started For Windows® Vista If your Windows® 95/98/2000/Me/XP/Vista version is different or you need more detailed installation information, please refer to your Windows® 95/98/2000/Me/XP/Vista user's manual. file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/install/gt_start.htm（第 3／3 页）4/3/2009 9:48:28 AM Start Windows® Vista Click the Start button; select and click on 'Control Panel'. Select and click on 'Hardware and Sound' Choose 'Device Manager' and Click on 'Update device drivers'.

  • Page 43: Description Of The On Screen Display

    What is the On-Screen Display? This is a feature in all Philips LCD monitors. It allows an end user to adjust screen performance of the monitors directly through an on-screen instruction window. The user interface provides user-friendliness and ease-of-use when operating the monitor.

  • Page 44: Analog Model

    On-Screen Display Analog model file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/osd/osddesc.htm（第 2／4 页）4/3/2009 9:48:36 AM...
  • Page 45 On-Screen Display The OSD Tree Below is an overall view of the structure of the On-Screen Display. You can use this as a reference when you want to work your way around the different adjustments later on. file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/osd/osddesc.htm（第 3／4 页）4/3/2009 9:48:36 AM RETURN TO TOP OF THE PAGE...
  • Page 46 On-Screen Display RETURN TO TOP OF THE PAGE file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/osd/osddesc.htm（第 4／4 页）4/3/2009 9:48:36 AM...

  • Page 47: Customer Care And Warranty

    Customer Care & Warranty Customer Care & Warranty PLEASE SELECT YOUR COUNTRY/AREA TO REVIEW DETAILS OF YOUR WARRANTY COVERAGE WESTERN EUROPE: Luxembourg EASTERN EUROPE: LATIN AMERICA: Venezuela NORTH AMERICA: PACIFIC: ASIA: Bangladesh Singapore AFRICA: MIDDLE EAST: file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/warranty/warranty.htm4/3/2009 9:48:40 AM Austria •...
  • Page 48 Should you encounter any difficulties while installing or using this product, please contact the Philips helpdesk directly to benefit from your Philips Warranty. This two-year service warranty entitles you to a swap model on-site if your monitor turns out to be faulty or defective.
  • Page 49 Just a phone call away In order to avoid unnecessary inconvenience, we advise you to read the operating instructions carefully or go to the philips.com/support To solve your problem quickly, please prepare the following details before contacting the Philips helpdesk: ● ●...
  • Page 50 Philips Warranty Contact Information Philips Warranty Contact Information Country Austria Belgium Denmark Finland France Germany Greece Ireland Italy Luxembourg The Netherlands Norway Portugal Spain Sweden Switzerland United Kingdom file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/warranty/warfirst.htm4/3/2009 9:48:49 AM Code Telephone number Tariff 0810 000206 € 0.07 078 250851 €...

  • Page 51: Your Guarantee In Central And Eastern Europe

    What is excluded? The Philips guarantee applies provided the product is handled properly for its intended use, in accordance with its operating instructions and upon presentation of the original invoice or cash receipt, indicating the date of purchase, dealer's name and model and production number of the product.
  • Page 52 In order to avoid unnecessary inconvenience, we advise you to read the operating instructions carefully before contacting our dealers or Information Centers In case your Philips product is not working correctly or is defective, please contact your Philips dealer or directly the Philips Service and Consumer Information Centers Website: file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/warranty/war_ee.htm（第...

  • Page 53: Consumer Information Centers

    Consumer Information Centers Consumer Information Centers Antilles Croatia Lithuania Romania • Turkey Eastern Europe BELARUS Technical Center of JV IBA M. Bogdanovich str. 155 BY - 220040 Minsk Tel: +375 17 217 33 86 BULGARIA LAN Service 140, Mimi Balkanska Str. Office center Translog 1540 Sofia, Bulgaria Tel: +359 2 960 2360...
  • Page 54 Consumer Information Centers ESTONIA FUJITSU SERVICES OU Akadeemia tee 21G EE-12618 Tallinn Tel: +372 6519900 www.ee.invia.fujitsu.com HUNGARY Serware Szerviz Vizimolnár u. 2-4 HU - 1031 Budapest Tel: +36 1 2426331 Email: inbox@serware.hu www.serware.hu LATVIA ServiceNet LV Jelgavas iela 36 LV - 1055 Riga, Tel: +371 7460399 Email: serviss@servicenet.lv LITHUANIA...
  • Page 55 PL - 05-500 Piaseczno Tel: +48 22 7501766 Email: servmonitor@zolter.com.pl www.zolter.com.pl RUSSIA Tel: +7 095 961-1111 Tel: 8-800-200-0880 Website: www.philips.ru TURKEY Türk Philips Ticaret A.S. Yukari Dudullu Org.San.Bolgesi 2.Cadde No:22 34776-Umraniye/Istanbul Tel: (0800)-261 33 02 file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/warranty/warcic.htm（第 3／11 页）4/3/2009 9:49:02 AM...
  • Page 56 Philips Antillana N.V. Vedia 3892 Capital Federal CP: 1430 Buenos Aires Phone/Fax: (011)-4544 2047 BRASIL Philips da Amazônia Ind. Elet. Ltda. Rua Verbo Divino, 1400-São Paulo-SP CEP-04719-002 Phones: 11 21210203 -São Paulo & 0800-701-0203-Other Regions without São Paulo City CHILE Philips Chilena S.A.
  • Page 57 Consumer Information Centers COLOMBIA Industrias Philips de Colombia S.A.-Division de Servicio CARRERA 15 Nr. 104-33 Bogota, Colombia Phone:(01)-8000 111001 (toll free) Fax : (01)-619-4300/619-4104 MEXICO Consumer Information Centre Norte 45 No.669 Col. Industrial Vallejo C.P.02300, -Mexico, D.F. Phone: (05)-3687788 / 9180050462...
  • Page 58 Rambla O'Higgins 5303 Montevideo Uruguay Phone: (598) 619 66 66 Fax: (598) 619 77 77 Customer Desk: Phone: 0004054176 VENEZUELA Industrias Venezolanas Philips S.A. Apartado Postal 1167 Caracas 1010-A Phone: (02) 2377575 Fax : (02) 2376420 Canada CANADA Philips Electronics Ltd.
  • Page 59 Rm 1007, Hongyun Building, No. 501 Wuning road, 200063 Shanghai P.R. China Phone: 4008 800 008 Fax: 21-52710058 HONG KONG Philips Electronics Hong Kong Limited Consumer Service Unit A, 10/F. Park Sun Building 103-107 Wo Yi Hop Road Kwai Chung, N.T.
  • Page 60 Madras 600 006 NEW DELHI Customer Relation Centre 68, Shivaji Marg New Dehli 110 015 INDONESIA Philips Group of Companies in Indonesia Consumer Information Centre Jl.Buncit Raya Kav. 99-100 12510 Jakarta Phone: (021)-7940040 ext: 2100 Fax : (021)-794 7511 / 794 7539...
  • Page 61 PHILIPS ELECTRONICS & LIGHTING, INC. Consumer Electronics 48F PBCOM tower 6795 Ayala Avenue cor VA Rufino St. Salcedo Village 1227 Makati City, PHILS Phone: (02)-888 0572, Domestic Toll Free: 1-800-10-PHILIPS or 1-800-10-744 5477 Fax: (02)-888 0571 file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/warranty/warcic.htm（第 9／11 页）4/3/2009 9:49:02 AM...
  • Page 62 Consumer Information Centers SINGAPORE Accord Customer Care Solutions Ltd Authorized Philips Service Center Consumer Service 620A Lorong 1 Toa Rayoh Singapore 319762 Tel: +65 6882 3999 Fax: +65 6250 8037 TAIWAN Philips Taiwan Ltd. Consumer Information Centre 13F, No. 3-1 Yuan Qu St., Nan Gang Dist.,...
  • Page 63 Consumer Information Centers SOUTH AFRICA PHILIPS SA (PTY) LTD Customer Care Center 195 Main Road Martindale, Johannesburg P.O. box 58088 Newville 2114 Telephone: +27 (0) 11 471 5194 Fax: +27 (0) 11 471 5123 E-mail: customercare.za@philips.com Middle East DUBAI Philips Middle East B.V.

  • Page 64: Your International Guarantee

    In case your Philips product is not working correctly or is defective, please contact your Philips dealer. In the event you require service whilst in another country a dealer address can be given to you by the Philips Consumer Help Desk in that country, the telephone and fax number of which can be found in the relevant part of this booklet.
  • Page 65 Should you encounter any difficulties while installing or using this product, please contact Philips directly to benefit from your Philips F1rst Choice Warranty. This three-year service warranty entitles you to a swap model on-site within 48 hours of your call being received within the first year of purchase.
  • Page 66 ● Where IS SERVICE AVAILABLE? Warranty service is available in all countries where the product is officially distributed by Philips Consumer Electronics. In countries where Philips Consumer Electronics does not distribute the product, the local Philips service organization will attempt to provide service (although there may be a delay if the appropriate spare parts and technical manual(s) are not readily available).
  • Page 67 Please contact Philips at: (800) 479-6696 Three years free parts and three years free labor will be provided at Philips Canada depot or any one of its authorized service centers. (In Canada, this warranty is given in lieu of all other warranties. No other warranties are expressed or implied, including any implied warranties of merchantability or fitness for a particular purpose.
  • Page 68 Just a phone call away Philips’ customer help desks are located worldwide. Within the U.S. you can contact Philips customer care Monday- Friday from 8:00 AM-9:00 PM Eastern Time (ET) and on Saturdays from 10:00 AM-5:00 PM ET hrs by using one of the contact phone numbers.

  • Page 69: Aspect Ratio

    Glossary Glossary A B C D E Active matrix This is a kind of liquid crystal display structure in which switching transistors are attached to each pixel to control the on/ off voltage. It produces a brighter and sharper display with a broader viewing angle than a passive matrix display. Also refer to TFT (thin film transistor).
  • Page 70 (degrees Kelvin). Lower Kelvin temperatures such as 2400° K are red; higher temperatures such as 9300° K are blue. Neutral temperature is white, at 6504° K. Philips monitors generally offers 9300° K, 6500° K, and user define.
  • Page 71 Glossary The ratio of luminance between the brightest white pattern and the darkest black pattern. D-SUB A VGA Analog input connector. Your monitor comes with a D-Sub cable. Digital Visual Interface (DVI) The Digital Visual Interface (DVI) specification provides a high-speed digital connection for visual data types that is display technology independent.
  • Page 72 Glossary Gamma Screen luminance as a function of video voltage approximately follows a mathematical power function of the input video signal, the exponent of which is called gamma. Grayscale An achromatic scale ranging from black through a series of successively lighter grays to white. Such a series may be made up of steps, which appear to be equally distant from one another.

  • Page 73: Liquid Crystal

    Glossary LCD (liquid crystal display) A display composed of liquid crystal suspended between two transparent sheets. The display is composed thousands of pixels which can be turned on or off with electrical stimulation. Thus, colorful images/texts can be generated. Liquid crystal The compound found in liquid crystal displays.

  • Page 74: Refresh Rate

    Using a standard unified color space, sRGB will help represent pictures taken by an sRGB compatible device correctly on your sRGB enabled Philips monitors. In that way, the colors are calibrated and you can rely on the correctness of the colors shown on your screen.
  • Page 75 Glossary pixel on an active matrix LCD. USB or Universal Serial Bus A smart plug for PC peripherals. required by peripherals. USB makes necessary resources available without user intervention. ● ● ● In short, USB transforms today's "Plug-and-Pray" into true Plug-and-Play! A Universal Serial Bus device that provides additional connections to the Universal Serial Bus.
  • Page 76 Glossary refer to a collection of hardware components that perform a particular function, such as a Universal Serial Bus interface device. At an even higher level, device may refer to the function performed by an entity attached to the Universal Serial Bus;...
  • Page 77 Glossary RETURN TO TOP OF THE PAGE file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/220V1/glossary/glossary.htm（第 9／9 页）4/3/2009 9:50:01 AM...

  • Page 78: Download And Print

    Download and Print Download and Print • Installing your LCD monitor driver • Download and Printing Instructions Installing Your LCD monitor driver System requirements: PC running Windows 95, Windows® 98, Windows® 2000 , Windows® Me, Windows® XP, Windows® Vista or ●...

  • Page 79: Printing Instructions

    Download and Print Printing instructions: To print the manual: With the manual file open, follow your printer's instructions and print the pages you need. file:///G|/CD MANUAL/22/813/Q70G2201813 4A(220V1)/lcd/manual/ENGLISH/download/download.htm（第 2／2 页）4/3/2009 9:50:19 AM RETURN TO TOP OF THE PAGE...
