  • Page 2 Version 1.0 Published October 2021 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3 AUSTRALIA ONLY Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage caused by our goods. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
  • Page 4 ES OF ANY KIND WHETHER UNDER THIS AGREEMENT OR OTHERWISE, EVEN IF INTEL HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. LICENSE TO USE COMMENTS AND SUGGESTIONS. This Agreement does NOT obligate Licensee to provide Intel with comments or suggestions regarding the Software. However, if Licensee provides Intel with comments or suggestions for the modification, correction, improvement or enhancement of (a) the Software or (b) Intel products or processes that work with the Software, Licensee grants to Intel a non-exclusive, worldwide,...

  • Page 5: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Motherboard Layout Front Panel Rear Panel Chapter 2 Installation Installing the CPU Installing the CPU Fan and Heatsink Installing Memory Modules (DIMM) Expansion Slot (PCIe Slot) Jumpers Setup Onboard Headers and Connectors M.2 WiFi/BT Module Installation Guide M.2_SSD (NGFF) Module Installation Guide Chapter 3 Software and Utilities Operation Installing Drivers...
  • Page 6 OC Tweaker Screen Advanced Screen 4.4.1 CPU Configuration 4.4.2 Onboard Devices Configuration 4.4.3 Storage Configuration 4.4.5 ACPI Configuration 4.4.6 Trusted Computing 4.4.7 AMD Firmware Version Tools Hardware Health Event Monitoring Screen Security Screen Boot Screen Exit Screen...

  • Page 7: Chapter 1 Introduction

    X300-ITX / X300-ITX/COM Chapter 1 Introduction Thank you for purchasing X300-ITX / X300-ITX/COM motherboard. In this documentation, Chapter 1 and 2 contains the introduction of the motherboard and step-by-step installation guides. Chapter 3 contains the operation guide of the software and utilities. Chapter 4 contains the configuration guide of the BIOS setup.

  • Page 8: Specifications

    1.2 Specifications Platform • Deep mini-ITX Form Factor • Solid Capacitor design • Supports AMD AM4 Socket Ryzen 2000, 3000, 4000 G-Series, 5000 and 5000 G-Series Desktop Processors • Supports CPU up to 65W • 6 Power Phase design Chipset • AMD X300 Memory • Dual Channel DDR4 Memory Technology...
  • Page 9 X300-ITX / X300-ITX/COM * Please refer to page 18 for DDR4 DIMM maximum frequency support. • Max. capacity of system memory: 128GB • 15μ Gold Contact in DIMM Slots AMD Ryzen series CPUs (Vermeer, Matisse, Pinnacle Ridge) Expansion Slot • 1 x PCIe Gen3x16 Slot (x16 mode)* AMD Ryzen series APUs (Cezanne, Renoir) • 1 x PCIe Gen3x16 Slot (x16 mode)*...
  • Page 10 Audio • Realtek ALC897 Audio Codec • Supports Surge Protection • 1 x Headphone/Headset Jack • 1 x Line out Jack • PCIE x1 Gigabit LAN 10/100/1000 Mb/s • Realtek RTL8111H • Supports Wake-On-LAN • Supports Lightning/ESD Protection • Supports Energy Efficient Ethernet 802.3az • Supports PXE Front • 1 x Headphone/Headset Jack...
  • Page 11 X300-ITX / X300-ITX/COM Connector • 1 x COM Port Header (Optional for X300-ITX/COM model) • 1 x Chassis Intrusion Header • 1 x CPU Fan Connector * The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.

  • Page 12: Motherboard Layout

    1.3 Motherboard Layout HDMI1 VGA1 COM1 RJ-45 ATX12V2 M.2 WiFi CPU_FAN1 SOCKET AM4 M.2 PCIe SSD RoHS DDR4_A1 (64 bit, 288-pin module) DDR4_A2 (64 bit, 288-pin module) DDR4_B1 (64 bit, 288-pin module) DDR4_B2 (64 bit, 288-pin module) AT X P W R1 SATA3_2 SATA3_1 CLRMOS1...
  • Page 13 X300-ITX / X300-ITX/COM No. Description COM Port Header (COM1) (for X300-ITX/COM only) 8 pin 12V Power Connector (ATX12V2) CPU Fan Connector (CPU_FAN1) 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1) 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2) Chassis Intrusion Header (CI1) ATX Power Connector (ATXPWR1) USB 2.0 Header (USB_5_6)

  • Page 14: Front Panel

    1.4 Front Panel No. Description No. Description Headphone/Headset Jack (AUDIO1) USB 3.2 Gen1 Type-A Ports USB 3.2 Gen1 Type-C Port (USB3_12) (USB3_TC_1) USB 2.0 Ports (USB_12)

  • Page 15: Rear Panel

    X300-ITX / X300-ITX/COM 1.5 Rear Panel No. Description No. Description DisplayPort 1.2 USB 3.2 Gen1 Type-A Ports D-Sub Port (USB3_34) HDMI Port Line out Jack USB 2.0 Ports (USB_34) LAN RJ-45 Port* * There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.

  • Page 16: Chapter 2 Installation

    Chapter 2 Installation This is a Deep mini-ITX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.

  • Page 17: Installing The Cpu

    X300-ITX / X300-ITX/COM 2.1 Installing the CPU Unplug all power cables before installing the CPU.

  • Page 19: Installing The Cpu Fan And Heatsink

    X300-ITX / X300-ITX/COM 2.2 Installing the CPU Fan and Heatsink After you install the CPU into this motherboard, it is necessary to install a larger heatsink and cooling fan to dissipate heat. You also need to spray thermal grease between the CPU and the heatsink to improve heat dissipation. Make sure that the CPU and the heatsink are securely fastened and in good contact with each other.
  • Page 20 4-pin FAN cable...
  • Page 21 X300-ITX / X300-ITX/COM Installing the CPU Box Cooler -2...
  • Page 23 X300-ITX / X300-ITX/COM 4-pin FAN cable...

  • Page 24: Installing Memory Modules (Dimm)

    2.3 Installing Memory Modules (DIMM) This motherboard provides four 288-pin DDR4 (Double Data Rate 4) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR4 DIMM pairs. 2.
  • Page 25 X300-ITX / X300-ITX/COM Ryzen Series CPUs (Matisse): UDIMM Memory Slot Frequency (Mhz) 3200 3200 3200 3200 2933 SR/DR SR/DR 2667 SR/DR SR/DR SR/DR SR/DR 2667 Ryzen Series APUs (Renoir): UDIMM Memory Slot Frequency (Mhz) 3200 3200 3200 3200 2933 SR/DR...
  • Page 26 Ryzen Series CPUs (Pinnacle Ridge): UDIMM Memory Slot Frequency (Mhz) 2933 2933 2933 2933 2933 SR/DR SR/DR 2667 SR/DR SR/DR SR/DR SR/DR 2133-2400 Ryzen Series APUs (Picasso): UDIMM Memory Slot Frequency (Mhz) 2933 2667 2667 2400 2133 SR/DR SR/DR 1866 SR/DR SR/DR SR/DR...
  • Page 27 X300-ITX / X300-ITX/COM Ryzen Series CPUs (Raven Ridge): UDIMM Memory Slot Frequency (Mhz) 2933 2933 2933 2933 2933 SR/DR SR/DR 2667 SR/DR SR/DR SR/DR SR/DR 2133-2400 SR: Single rank DIMM, 1Rx4 or 1Rx8 on DIMM module label DR: Dual rank DIMM, 2Rx4 or 2Rx8 on DIMM module label...
  • Page 28 The DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.

  • Page 29: Expansion Slot (Pcie Slot)

    X300-ITX / X300-ITX/COM 2.4 Expansion Slot (PCIe Slot) There are 1 PCIe slot on the motherboard. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.

  • Page 30: Jumpers Setup

    2.5 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Clear CMOS Jumper Short: Clear CMOS (CLRCMOS1) Open: Default (see p.6, No.

  • Page 31: Onboard Headers And Connectors

    X300-ITX / X300-ITX/COM 2.6 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard.
  • Page 32 If you plan to connect a 3-Pin CPU fan, please connect it to Pin 1-3. Serial Port Header This COM1 header (9-pin COM1) supports a serial port RRI#1 CCTS#1 RRTS#1 (see p.6, No.1) module. DDSR#1 (for X300-ITX/COM DDTR#1 TTXD#1 RRXD#1 only) DDCD#1...
  • Page 33 X300-ITX / X300-ITX/COM ATX Power Connector This motherboard pro- (24-pin ATXPWR1) vides a 24-pin ATX power (see p.6, No. 7) connector. To use a 20-pin ATX power supply, please plug it along Pin 1 and Pin ATX 12V Power This motherboard...

  • Page 34: Wifi/Bt Module Installation Guide

    2.7 M.2 WiFi/BT Module Installation Guide The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The M.2 Socket (Key E) supports type 2230 WiFi/BT module. Installing the WiFi/BT module Step 1 Prepare a type 2230 WiFi/BT module...
  • Page 35 X300-ITX / X300-ITX/COM Step 4 Tighten the screw with a screwdriver to secure the module into place. Please do not overtighten the screw as this might damage the module.

  • Page 36: M.2_Ssd (Ngff) Module Installation Guide

    2.8 M.2_SSD (NGFF) Module Installation Guide The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Ultra M.2 Socket (M2_1) supports type 2280 M.2 PCI Express module up to Gen3 x4 (32 Gb/s) or Gen3 x2 (16 Gb/s) (with Athlon 2xxGE series).
  • Page 37 X300-ITX / X300-ITX/COM M.2_SSD (NGFF) Module Support List Vendor Interface ADATA PCIe ADATA ASX7000NPC-512GT-C (XPG SX7000) (NVMe) ADATA PCIe ADATA ASX8000NPC-512GM-C (XPG ASX8000) (NVMe) Apacer PCIe Apacer Z280 AP240GZ280-240G (NVMe) Intel PCIe Intel Optane Memory 32GB (MEMPEK1W032GA)(NVMe) Intel PCIe Intel Optane Memory 16GB (MEMPEK1W016GA)(NVMe)

  • Page 38: Chapter 3 Software And Utilities Operation

    Chapter 3 Software and Utilities Operation 3.1 Installing Drivers The Support CD that comes with the motherboard contains necessary drivers and useful utilities that enhance the motherboard’s features. Running The Support CD To begin using the support CD, insert the CD into your CD-ROM drive. The CD automatically displays the Main Menu if “AUTORUN”...

  • Page 39: Chapter 4 Uefi Setup Utility

    X300-ITX / X300-ITX/COM Chapter 4 UEFI SETUP UTILITY 4.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. You may run the UEFI SETUP UTILITY by pressing <F2> or <Del> right after you power on the computer, otherwise, the Power-On-Self-Test (POST) will continue with its test routines.

  • Page 40: Navigation Keys

    4.1.2 Navigation Keys Use < > key or < > key to choose among the selections on the menu bar, and use < > key or < > key to move the cursor up or down to select items, then press <Enter>...

  • Page 41: Main Screen

    X300-ITX / X300-ITX/COM 4.2 Main Screen When you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview.

  • Page 42: Oc Tweaker Screen

    4.3 OC Tweaker Screen In the OC Tweaker screen, you can set up overclocking features. Because the UEFI software is constantly being updated, the following UEFI setup screens and descriptions are for reference purpose only, and they may not exactly match what you see on your screen.
  • Page 43 X300-ITX / X300-ITX/COM CCD0 CCX0 Frequency (MHz) Use this item to adjust CCX0 Frequency. CCX1 Frequency (MHz) Use this item to adjust CCX1 Frequency. CCD1 CCX0 Frequency (MHz) Use this item to adjust CCX0 Frequency. CCX1 Frequency (MHz) Use this item to adjust CCX1 Frequency.
  • Page 44 Global C-state Control This option controls IO based C-state generation and DF C-states. Graphic Configuration GFX Clock Frequency (Only for processor with integrated graphics) This item allows you to alter the frequency for the GFX clock frequency. After you alter the GFX Clock Frequency settings, make sure to adjust the GFX Core Voltage settings.
  • Page 45 X300-ITX / X300-ITX/COM DRAM Voltage Configure the voltage for the DRAM Voltage. VDDP Configure the voltage for the VDDP. SMU Common Options XFR Enhancement Save User Default Type a profile name and press enter to save your settings as user default.

  • Page 46: Advanced Screen

    4.4 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Onboard Devices Configuration, Storage Configuration, Super IO Configuration, ACPI Configuration, Trusted Computing and AMD Firmware Version. Setting wrong values in this section may cause the system to malfunction. UEFI Configuration Full HD UEFI When [Auto] is selected, the resolution will be set to 1920 x 1080 if the monitor...

  • Page 47: Cpu Configuration

    X300-ITX / X300-ITX/COM 4.4.1 CPU Configuration PSS Support Use this to enable or disable the generation of ACPI_PPC, _PSS, and _PCT objects. NX Mode Use this to enable or disable NX mode. SVM Mode When this is set to [Enabled], a VMM (Virtual Machine Architecture)can utilize the additional hardware capabilities provided by AMD-V.

  • Page 48: Onboard Devices Configuration

    4.4.2 Onboard Devices Configuration SR-IOV Support Enable/disable the SR-IOV (Single Root IO Virtualization Support) if the system has SR-IOV capable PCIe devices. UMA Frame buffer Size (Only for processor with integrated graphics) This item allows you to set the size of the UMA frame buffer. Onboard HD Audio Enable/disable onboard HD audio.

  • Page 49: Storage Configuration

    X300-ITX / X300-ITX/COM 4.4.3 Storage Configuration SATA Controller(s) Enable/disable the SATA controllers. SATA Mode AHCI: Supports new features that improve performance. RAID: Combine multiple disk drives into a logical unit. NVME RAID Enable/disable RAID mode on NVMe device.
  • Page 50 4.4.4 Super IO Configuration Serial Port (for X300-ITX/COM only) Enable or disable the Serial port. Serial Port Address (for X300-ITX/COM only) Select the address of the Serial port.

  • Page 51: Acpi Configuration

    X300-ITX / X300-ITX/COM 4.4.5 ACPI Configuration Suspend to RAM It is recommended to select auto for ACPI S3 power saving. Deep Sleep Configure deep sleep mode for power saving when the computer is shut down. Wake From Onboard LAN Allow the system to be waked up by a onboard LAN.

  • Page 52: Trusted Computing

    4.4.6 Trusted Computing NOTE: Options vary depending on the version of your connected TPM module. Security Device Support Use this item to enable or disable BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available. SHA-1 PCR Bank Use this item to enable or disable SHA-1 PCR Bank.
  • Page 53 X300-ITX / X300-ITX/COM TPM2.0 UEFI Spec Version Use this item to select the TCG2 spec. version supported. The optional settings: [TCG_1_2]; [TCG_2]. [TCG_1_2]: compatible mode for Win8/Win10. [TCG_2]: for TCG2 newer spec. compatible mode for Win10 Physical Presence Spec version Select this item to tell OS to support PPI spec version 1.2 or 1.3.

  • Page 54: Amd Firmware Version

    4.4.7 AMD Firmware Version This page shows all of AMD Firmware Version.

  • Page 55: Tools

    X300-ITX / X300-ITX/COM 4.5 Tools Instant Flash Save UEFI files in your USB storage device and run Instant Flash to update your UEFI.

  • Page 56: Hardware Health Event Monitoring Screen

    4.6 Hardware Health Event Monitoring Screen This section allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, fan speed and voltage. CPU Fan 1 Setting Select a fan mode for CPU Fan 1, or choose Customize to set 5 CPU temperatures and assign a respective fan speed for each temperature.

  • Page 57: Security Screen

    X300-ITX / X300-ITX/COM 4.7 Security Screen In this section you may set or change the supervisor/user password for the system. You may also clear the user password. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility.

  • Page 58: Boot Screen

    4.8 Boot Screen This section displays the available devices on your system for you to configure the boot settings and the boot priority. Fast Boot Fast Boot minimizes your computer's boot time. In fast mode you may not boot from an USB storage device. Boot From Onboard LAN Allow the system to boot from a network instead of the local drive.
  • Page 59 X300-ITX / X300-ITX/COM CSM (Compatibility Support Module) Enable to launch the Compatibility Support Module. Please do not disable unless you’re running a WHCK test. Launch PXE OpROM Policy Select UEFI only to run those that support UEFI option ROM only. Select Legacy only to run those that support legacy option ROM only.

  • Page 60: Exit Screen

    4.9 Exit Screen Save Changes and Exit When you select this option the following message, “Save configuration changes and exit setup?” will pop out. Select [OK] to save changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option the following message, “Discard changes and exit setup?”...
  • Page 61 13848 Magnolia Ave, Chino, CA91710 Phone/Fax No: +1-909-590-8308/+1-909-590-1026 hereby declares that the product Product Name : Motherboard X300-ITX / X300-ITX/COM Model Number : Conforms to the following speci cations: FCC Part 15, Subpart B, Unintentional Radiators Supplementary Information: is device complies with part 15 of the FCC Rules. Operation is subject to the...
  • Page 62 EU Declaration of Conformity For the following equipment: Motherboard (Product Name) X300-ITX / X300-ITX/COM (Model Designation / Trade Name) EMC Directive - 2014/30/EU EN 55032:2015/A11:2020 EN 55024:2010/A1:2015 ■ ■ EN 55035:2017/A11:2020 EN 61000-3-2:2014 □ ■ EN 61000-3-3:2013 EN 61000-4-2:2009 ■...
