Amana Technical Information—Room Air Conditioner
AAC081SRA
• Due to a possibility of personal injury or property damage, always contact an authorized technician for servicing or
repair of this air conditioner.
• Refer to Service Manual 16022061 for installation, operation, disassembly, testing, and troubleshooting
information.
• Refer to Parts Reference material for part number information.
All safety information must be followed as provided in Service Manual 16022061.
To avoid risk of electrical shock that can cause death or severe injury, disconnect unit from power and discharge
capacitor through a 10,000-ohm resistor before servicing, unless tests require power. Wires removed during
disassembly must be replaced on correct terminals to ensure proper grounding and polarization.
Model
Electrical requirements
Refrigerant/amount
Compressor
Voltage low/high (nominal)
BTUH
Watts
Current
Lock rotor
Full load
Overload protector
Fan motor
Electrical requirements
RPM
Low speed
Med speed
High speed
Watts at high speed
Current at high speed
Compressor Capacitor
Capacitance
Voltage rating (nominal)
Fan motor Capacitor
Capacitance
Voltage rating (nominal)
December 2002
PAAC081SRA0
!
CAUTION
!
WARNING
1
AAC081SRA
115V VAC 60Hz
HCFC22/25.8 ounces
98/132 VAC (115 VAC)
8,390 BTUH
790 watts
42 amps
7.1amps
External
115 VAC 60Hz
700 RPM
800 RPM
1000 RPM
60 watts
1.4 amps
40 Mfd ±10%
250 VAC
5 Mfd ±10%
450 VAC
(Replaces RT4110055 Rev. 0)
16022063
