  • Page 1 P3PC-5822-04ENZ0 fi-748PRB Imprinter Operator's Guide...

  • Page 2: Table Of Contents

    Contents Introduction ......................... 1 Chapter 1 Preparations....................... 3 1.1. Checking the Package Contents ....................3 1.2. Names of Component Parts ..................... 3 Chapter 2 Installation ......................5 2.1. Installing the Imprinter ......................5 2.2. Loading the Print Cartridge ...................... 6 2.3.

  • Page 3: Introduction

    Introduction Thank you for your purchase of the fi-748PRB Imprinter. Abbreviations Used in This Manual The fi-748PRB Imprinter is an optional unit to be used The operating systems and products in this manual are indicated with the fi-7460/fi-7480 image scanner.
  • Page 4 Screen Examples in This Manual Microsoft product screenshots are reprinted with permission from Microsoft Corporation. The screen examples in this manual are subject to change without notice in the interest of product development. If the actual displayed screen differs from the screen examples in this manual, operate by following the actual displayed screen while referring to the user's manual of the scanner application that you are using.

  • Page 5: Chapter 1 Preparations

    Operator Panel (Feeder) imprinter package box to make sure that all items are ・ LCD included in the package. ・ [Menu] Button If anything is missing or damaged, contact your FUJITSU ・ [ ] Button/[ ] Button   scanner dealer or an authorized FUJITSU scanner service ・...
  • Page 6 <Inside> Print Cartridge Cover Print Cartridge Holder...

  • Page 7: Chapter 2 Installation

    Raise the locks (two locks on the rear side). ATTENTION ● You must remove the stacker before installing the imprinter. ● Do not pull forcibly, since this might damage the stacker. fi-748PRB Imprinter Operator's Guide |...

  • Page 8: Loading The Print Cartridge

    2.2. Loading the Print Cartridge Turn the locks inside (two locks on the rear side). Load the print cartridge as follows: ATTENTION When installing the print cartridge, install it properly. Turn off the scanner. Place your hand in the middle part of the print cartridge cover and open it as shown below.

  • Page 9: Test Print

    Confirm that the print cartridge is positioned within the document width. Move the print cartridge to an appropriate printing position. The print cartridge should be positioned within the section where the document will pass through. fi-748PRB Imprinter Operator's Guide |...
  • Page 10 Press the [Menu] button. Select a print pattern by pressing the [] button or the [] button, and then confirm the selection by pressing the [Scan/Enter] button. HINT Below are the print test patterns: (Horizontal): Test Pattern 1 ABCDEFGHIJKLMNOPQRSTUVWXYZ[¥]^_`00000000 (Horizontal): Test Pattern 2 abcdefghijklmnopqrstuvwxyz{|}‾...

  • Page 11: Chapter 3 Basic Operation

    Load the actual document in the scanner and make sure that the print cartridge is positioned within the width of Raise the stacker. document. Lift up the stacker tab (one on each side). Put back the stacker. Close the print cartridge cover. fi-748PRB Imprinter Operator's Guide |...

  • Page 12: Replacing The Print Cartridge

    3.4. Replacing the Print Cartridge Remove the old print cartridge. The print cartridge is a consumable. Replace the print cartridge as follows: ATTENTION ● When the following message appears, replace the print cartridge as soon as possible. If you continue to print without replacing the cartridge, your print output will be faded.
  • Page 13  The value of the counter is set to 100. ③ Click the [OK] button on the [Software Operation Panel] window. ④ A message appears. Click the [OK] button.  The [Software Operation Panel] window closes, and the ink counter is cleared. fi-748PRB Imprinter Operator's Guide | 11...

  • Page 14: Removing Jammed Documents

    3.5. Removing Jammed Documents Close the ADF. If a document jams, remove the jammed document as follows: ATTENTION Print Section Open the ADF and the print section to remove the jammed document. Do not pull out the document forcefully. Remove the documents from the ADF paper chute (feeder).

  • Page 15: Chapter 4 Daily Care

    Replacing the Print Cartridge".) Confirm that the dirt is removed and then close the print section. ATTENTION When installing the print cartridge, install it properly. Reinstall the print cartridge. (Refer to "3.4. Replacing the Print Cartridge".) fi-748PRB Imprinter Operator's Guide | 13...

  • Page 16: Cleaning The Rollers

    (*1) (*2) Clean the entire surface of the rubber rollers as you rotate them manually. For information about the cleaning materials, contact your FUJITSU ATTENTION scanner dealer or an authorized FUJITSU scanner service provider. When cleaning, be careful not to touch the metal wheels located at the print section.

  • Page 17: Chapter 5 Error Messages

    Check if the print cartridge is installed correctly. Print cartridge not installed If the problem persists, write down the displayed error code and U6:B4 contact your FUJITSU scanner dealer or an authorized FUJITSU scanner service provider. An error occurred in the imprinter. Imprinter error (RAM)

  • Page 18: Chapter 6 Specifications

    Chapter 6 Specifications Item Specification Printing Method Thermal inkjet printing Print Timing Post printing, rear surface printing Printing Characters Alphabet A to Z, a to z Numeric characters: 0, 1 to 9 Symbols: ! " # $ % & ' ( ) * + , - . / : ; < = > ? @ [ ¥ ] ^ _ ` { | } ‾ 43 digits Maximum Number of Maximum of...
  • Page 19 Replacement cycle: 4,000,000 characters or six months after opening (A print cartridge has a specific expiration date, and the expiration period differs whether the package is opened or not. Start using the print cartridge before the expiration date that is written on the package.) fi-748PRB Imprinter Operator's Guide | 17...

  • Page 20: Contact For Inquiries

    For other inquiries regarding the scanner, refer to the following web page: https://www.fujitsu.com/global/support/products/computing/peripheral/scanners/fi/ If the solution to your problem cannot be found on the above web page, refer to the contact information for your Fujitsu office on the following web page: https://www.fujitsu.com/global/about/resources/shop/computing/peripheral/scanners/index.html...
