IDENTIFICATION
1. Handlebar
2. Auger Control Bar
3. Auger Control Cable Assembly
4. Remote Discharge Chute Handle Assembly
(Model 938033)
5. Recoil Starter Handle
6. Discharge Chute Handle
(Models 938030, 031, 032, 034)
7. Discharge Chute Deflector Handle
8. Discharge Chute
9. Wing Knob
10. Auger Paddle
© Copyright 2013 Ariens Company
1
2
5
15
16
Path-Pro
Setup Instructions
3
17
16
11. Oil Fill (Models 938030, 034)
12. Oil Fill (Models 938031, 032, 033)
13. Oil Drain Plug
14. Fuel Cap & Tank
15. Fuel & Oil Door
16. Pivot Bolt
17. Knob
18. Water Guard Ring
19. 1/4 x 1 1/4" Plastic Tapping Screw (3)
20. 16 oz 5W-30 Oil
Tools Required:
• 7/16" wrench or socket
• 3/8" wrench or socket
EN - 1
®
13
11
6
7
8
9
18
10
19
03/13
20
04537600
