Gaggia MAGENTA MILK RI8701 Operating Instructions Manual
Hide thumbs
Also See for MAGENTA MILK RI8701:
- Operating instructions manual (60 pages) ,
- Operating instructions manual (32 pages)
Related Manuals for Gaggia MAGENTA MILK RI8701
Summary of Contents for Gaggia MAGENTA MILK RI8701
- Page 1 ENGLISH NEDERLANDS POLSKI GAGGIA MAGENTA MILK RI8701 (SUP 051P) Operating instructions Gebruiksaanwijzing Instrukcja obsługi 4219-465-02541 MAN. GAG. MAGENTA Milk EN-NL-PL Rev 03.indd 1 21/01/2021 11:32:05...
- Page 2 4219-465-02541 MAN. GAG. MAGENTA Milk EN-NL-PL Rev 03.indd 2 21/01/2021 11:32:09...
- Page 3 Before using it for the first time, please read carefully the safety manual provided separately and store it for future use. Van harte gelukgewenst met de aanschaf van een Gaggia Magenta Milk! Met deze machine zal u op eenvoudige wijze steeds uitstekende resultaten verkrijgen.
- Page 4 First installation / Eerste installatie / Pierwsza instalacja Confermi di voler cambiare la lingua in Italiano? In the next steps we will set the correct water hardness level 1 min. 1 sec. Capp in Cup System / Capp in Cup-systeem / System Capp in Cup 4219-465-02541 MAN.
-
Page 5: Table Of Contents
Stand-by Time ................................................................................................................Units ............................................................................................................................Water hardness ..............................................................................................................Beverage counter ............................................................................................................Button sound ................................................................................................................... Factory settings ..............................................................................................................Error code key .................................................................................................................. Troubleshooting ..............................................................................................................GAGGIA accessories ......................................................................................................Technical specifications ................................................................................................... 4219-465-02541 MAN. GAG. MAGENTA Milk EN-NL-PL Rev 03.indd 5 21/01/2021 11:32:28... -
Page 6: Machine Overview (Fig.2)
English Machine overview (Fig.2) Control panel Coffee pucks container Adjustable coffee dispensing spout Drip tray Water tank lid Drip tray grid Coffee bean container lid Espresso tray Pre-ground coffee compartment Capp in Cup system handle Power cord socket Steam tube Espresso tray insertion slot Glass milk carafe Full drip tray indicator... -
Page 7: Control Panel And Display
English Control panel and display Control panel overview (Fig. 1) Select the function shown on the display. 1/2 MULTIFUNCTION buttons To switch the machine on or off, by keeping the button pressed for a few ON/OFF button seconds. To open the beverage menu. HOME button To open the cleaning and settings menu. -
Page 8: First Installation
English First installation Before using the machine, it is essential to follow a few simple steps, clearly described in the explanatory drawings you found in the quick guide at the 15 cm beginning of this instruction manual. Note: for even tastier coffee, we recommend that you initially prepare 5 cups of 15 cm coffee to allow the machine to self-adjust. -
Page 9: Measuring Water Hardness
English Measuring water hardness You will need to set the water hardness when you install your machine. Take the water hardness measuring strip contained in the packaging and follow the steps shown on the display during the installation phase. To change the water button, then select "SETTINGS", and hardness later, press the CLEAN/SET once in the settings menu, please select "WATER HARDNESS". -
Page 10: Installing The Intenza+ Water Filter
English Installing the INTENZA+ water filter Immerse the INTENZA+ water filter in cold water, in a vertical position and with the opening facing upwards. Press both sides of the filter gently to let air bubbles out. Remove the INTENZA+ water filter from the water. Set the machine according to the detected water hardness - see the “Measuring water hardness”... -
Page 11: Types Of Beverage
Coffee 40 ml layer of compact, natural “crema”. It is the result of the pressurized hot water extraction process invented by Achille Gaggia in 1938. Espresso lungo The long espresso is an espresso with a longer extraction time. It is more diluted, with a different aromatic intensity and a higher caffeine content. -
Page 12: Espresso Tray
English Espresso tray This machine was designed to guarantee flawless results, from a traditional espresso to a number of different beverages. If you want to enjoy an Italian espresso with a delicious layer of its natural “crema” on top and as tradition dictates, we suggest your using of the "Espresso Tray"... -
Page 13: Brewing Coffee Using Pre-Ground Coffee
English Finally, press the START/STOP button to start brewing. Note: you can interrupt the brewing at any time by pressing the START/STOP button. If you wish to customise the settings of a specific beverage, please refer to the “Beverage customisation” chapter. Brewing coffee using pre-ground coffee Use the measuring scoop provided to insert the correct dose in the pre-ground coffee compartment. -
Page 14: Preparation Of Coffee-Based Beverages And Frothed Milk
English Preparation of coffee-based beverages and frothed milk How to assemble the Capp in Cup system Note: Before preparing any milk-based beverage, make sure that the Capp in Cup system is fitted properly on the machine. Fit the spout on the main body of the Capp in Cup system. Insert the Capp in Cup system into the rubber grip on the steam tube until it locks into place. -
Page 15: Dispensing Hot Water
English 3 Place a cup or a glass under the Coffee dispensing spout and the Capp in Cup system. 4 Press the HOME button and choose the desired beverage from the menu. Press the button corresponding to the desired beverage. Press the START/STOP button to start dispensing the selected bever- age. -
Page 16: Customising Beverages And Saving Settings (Memo)
English Press the "HOT WATER" button Finally, press the START/STOP button to commence dispensing. ESPRESSO LUNGO AMERICANO Note: you can interrupt dispensing at any time by pressing the START/STOP ACQUA CALDA button. If you wish to customise the settings of a specific beverage, please refer to the “Beverage Customisation”... -
Page 17: Coffee Grind Settings
English To change the intensity of the aroma or select the pre-ground, press the “ “ button. You can choose among 5 different degrees of intensity. Every ” button, the aroma strength changes by one degree. time you press the “ The display shows the selected intensity or the selection of the pre-ground. -
Page 18: Cleaning And Maintenance
English While the machine is grinding coffee, press the grind settings adjustment knob in the bean container and turn it one notch at a time, to the left or right. You can select from 5 different grinding settings. The smaller the notch, the stronger and richer the coffee. - Page 19 See the “Cleaning and lubricating the brew group” Depending on usage chapter. Monthly Clean the brew group with the Gaggia coffee oil remover to remove any oily coffee residue Drip tray full When the red mark appears from Empty the drip tray and clean it under running the drip tray grid.
-
Page 20: Cleaning The Capp In Cup System
English Cleaning the Capp in Cup system Capp in Cup system Cleaning Programmes The machine allows two cleaning programmes for the Capp in Cup system: quick and deep clean. Both programmes can be selected with the CLEAN/SET button. Press the “CLEANING” button upon selection. Quick clean is also recommended after dispensing a milk-based beverage. -
Page 21: Cleaning The Brew Group
English Cleaning the brew group Warning: do not wash the brew group in the dishwasher and do not use dishwashing detergents, since they may cause the malfunctioning of the brew group and alter the coffee flavour. Removing the brew group Turn off the machine and disconnect the power cord. - Page 22 English Reinserting the brew group Before placing the brew group back into the machine, make sure that the two yellow reference marks on the side match. If this is not the case, perform the following step: Make sure that the lever is in contact with the base of the brew group. Make sure that the yellow locking hook of the brew group is in the right position.
-
Page 23: Lubricating The Brew Group
Cleaning the brew group with cleaning tablets for the removal of oily coffee residues Warning: use only Gaggia cleaning tablets to remove oily coffee residues. Place a container under the coffee dispensing spout. button and select the "CLEAN " button shown on Press the CLEAN/SET the display. -
Page 24: Descaling
Descaling procedure Descaling needs to be carried out when the machine requires it. Use only Gaggia descaling solution designed to guarantee the machine’s excellent performance. The use of different products could damage the machine and leave residue in the water. Failure to descale the machine will void the warranty. -
Page 25: What To Do If The Descaling Process Is Interrupted
English Pour the entire bottle of Gaggia descaling solution into the water tank and fill the tank with water up to the CALC CLEAN level. Reinsert it into the machine. Place a large recipient (1.5l) under the steam tube and the coffee dispensing spout. -
Page 26: Other Settings
English Other settings button and selecting “SETTINGS” on the display, By pressing the CLEAN/SET you can reset or modify some of the machine parameters including: Language. Water filter. Stand-by Time. Units. Water hardness. Beverage counter. Button sound Factory settings. Language When the language setting icon is selected, the list of available languages will be displayed. -
Page 27: Units
English Units By selecting “UNITS”: SETTING UNITS WATER HARDNESS you can set the unit of measurement in "ml" or "oz". BEVERAGE COUNTER BUTTON SOUND Water hardness With “WATER HARDNESS” selected, follow the instructions on the display and those described under the “Measuring water hardness” chapter. Beverage counter It is possible to display the number of cups of each beverage that have been dispensed since the first operation of the machine. -
Page 28: Error Code Key
The contact info is listed on www.gaggia.com and www.gaggia.it. Error code Problem... -
Page 29: Troubleshooting
This chapter outlines the most common problems you may encounter while using the machine. If you are unable to solve the problem using the information provided below, visit the FAQ sections on www.gaggia.com or www.gaggia.it or contact the either the Customer Service Centre or the local distributors in your country. - Page 30 English Problem Cause Solution The brew group cannot The brew group is not in the correct The brew group has not been positioned be inserted. position. correctly before being placed back. Ensure that the lever is in contact with the base of the brew group and that the hook of the brew group is in its correct position.
- Page 31 English Problem Cause Solution The milk does not froth. The Capp in Cup system is dirty Clean the Capp in Cup system as indicated or not correctly inserted. Or, the in the chapter “Capp in Cup System Deep Cleaning Under Running Water”, then place it system has not been correctly installed in all its components.
-
Page 32: Gaggia Accessories
English GAGGIA accessories Coffee and accessories are available through authorised centres (Italy), or distributors in your country. INTENZA+ water filter Descaling product Coffee oil remover Milk circuit cleaner (Philips) Coffee range available in beans and powder: 100% Arabica / Intense / Decaffeinated...
