  • Page 1 ® DP9295 PRESENTATIONS WORKING SESSIONS TRAINING MULTIMEDIA ANIMATION VIDEO...

  • Page 2: To The Owner

    Heat build-up can reduce the service life of your projector, and can also be dangerous. Do not put any flammable object or spray can near the projector, hot air is exhausted from the ventilation holes. Remote Control Unit, supplied to this projector, emits the laser beam as the laser pointer function from Laser Light Window while pressing LASER button (for 1 minute / LASER POINTER INDICATOR lights red to indicate laser emission).

  • Page 3: Safety Instructions

    Do not use attachments not recommended by the manufacturer as they may cause hazards. Do not place this projector on an unstable cart, stand, or table. The projector may fall, causing serious injury to a child or adult, and serious damage to the projector. Use only with a cart or stand recommended by the manufacturer, or sold with the projector.

  • Page 4: Federal Communication Commission Notice

    AC POWER CORD REQUIREMENT The AC Power Cord supplied with this projector meets the requirement for use in the country you purchased it. AC Power Cord for the United States and Canada : AC Power Cord used in the United States and Canada is listed by the Underwriters Laboratories (UL) and certified by the Canadian Standard Association (CSA).

  • Page 5: Table Of Contents

    IBM and PS/2 are trademarks or registered trademarks of International Business Machines, Inc. Windows and PowerPoint are registered trademarks of Microsoft Corporation. Proxima and InFocus are trademarks or registered trademarks of InFocus Corporation. Each name of corporations or products in the user's guide is a trademark or a registered trademark of its respective corporation.

  • Page 6: Features And Design

    This Multimedia Projector is designed with most advanced technology for portability, durability, and ease of use. This projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display (LCD) technology. Compact Design This projector is extremely compact in size and weight.

  • Page 7: Preparation

    PREPARATION NAME OF EACH PART OF PROJECTOR FRONT OF CABINET PROJECTION LENS LENS COVER BACK OF CABINET EXHAUST VENT HOT AIR EXHAUSTED ! Air blown from exhaust vent is hot. When using or installing a projector, following precautions should be taken.

  • Page 8: Setting-Up Projector

    NOTE ON POWER CORD AC Power Cord must meet requirement of country where you use a projector. Confirm AC plug type with chart below and proper AC power cord must be used. If supplied AC Power Cord does not match AC outlet, contact your sales dealer.

  • Page 9: Positioning Projector

    POSITIONING PROJECTOR This projector is designed to project on a flat projection surface. Projector can be focused from 4.6’ (1.4m) ~ 48.3’ (14.7m). Refer to figure below to adjust screen size. 4.6’(1.4m) 40” 31” 40” Max. Zoom Screen Size 31”...

  • Page 10: Adjustable Feet

    When carrying a projector, use a suitable carrying case. Do not transport a projector by using a courier or transport service in an unsuitable transport case. This may cause damage to a projector. To transport a projector through a courier or transport service, consult your dealer for best way.

  • Page 11: Connecting Projector

    CONNECTING PROJECTOR TERMINALS OF PROJECTOR This projector has input and output terminals on its back for connecting computers and video equipment. Refer to figures on pages 11 to 13 and connect properly. TERMINALS (DIGITAL/ANALOG) COMPUTER AUDIO INPUT (1 and 2) JACKS Connect computer (digital/analog) output to one of these terminals.

  • Page 12: Connecting To Computer

    16" MODE (832 x 624) 19" MODE (1024 x 768) 21" MODE (1152 x 870) ( = Cable or adapter is not supplied with this projector.) • USB Cable • MAC Adapter (When connecting to Macintosh computer) • Audio Cables (RCA x 2 and Mini Plug (stereo) x 1)

  • Page 13: Connecting To Video Equipment

    When connecting cable, power cords of both a projector and external equipment should be disconnected from AC outlet. ( = Cable is not supplied with this projector.) Component video output equipment. (such as DVD player or high-definition TV source.) Video Disc Player...

  • Page 14: Before Operation

    1 minute, release LASER button and press it again. LASER POINTER FUNCTION These caution labels are put on remote control. POWER ON-OFF BUTTON Used to turn projector on or off. (P19) power focus volume INPUT BUTTON Used to select input source.

  • Page 15: Remote Control Batteries Installation

    BEFORE OPERATION Operating Range Point Remote Control Unit toward projector (Receiver Window) whenever pressing any button. Maximum operating range for Remote Control Unit is about 16.4’ (5m) and 60° in front and rear of a projector.

  • Page 16: Top Controls And Indicators

    BEFORE OPERATION TOP CONTROLS AND INDICATORS This projector has CONTROL BUTTONS (TOP CONTROLS) and INDICATORS on its top. ZOOM BUTTON FOCUS BUTTON Used to adjust zoom. Used to adjust focus. (P20) (P20) LAMP INDICATOR Becomes dim when a projector is turned on.

  • Page 17: Operating On-Screen Menu

    OPERATING ON-SCREEN MENU HOW TO OPERATE ON-SCREEN MENU You can control and adjust this projector through ON-SCREEN MENU. Refer to following pages to operate each adjustment on ON-SCREEN MENU. 1 DISPLAY MENU Press MENU button to display ON-SCREEN MENU. 2 MOVING POINTER Move pointer ( see below) or adjust value of item by pressing POINT button(s) on Top Control or on Remote Control Unit.

  • Page 18: Menu Bar

    (Refer to P33, 34) SCREEN MENU SETTING MENU Used to adjust size Used to change of image. [Normal settings of projector / True / Wide / or reset Lamp Digital zoom +/–] Replace Counter. (Refer to P29) (Refer to P35,-37)

  • Page 19: Turning On / Off Projector

    When “Power Management” function is ON, projector detects signal interruption and turns off Projection Lamp automatically. Refer to “Power Management” on page 35. When WARNING TEMP. Indicator flashes red, projector is automatically turned off. Wait at least 5 minutes before turning on projector again.

  • Page 20: Basic Operation

    BASIC OPERATION Press ZOOM button on Top Control or ZOOM Remote Control Unit. Message “Zoom” is displayed. Press ZOOM button or POINT UP button to make image larger, and press ZOOM make image smaller. Press FOCUS button on Top Control or FOCUS Remote Control Unit.

  • Page 21: Picture Freeze Function

    PICTURE FREEZE FUNCTION Press FREEZE button on Remote Control Unit to freeze picture on-screen. To cancel FREEZE function, press FREEZE button again or press any other button except POINT / SELECT / RIGHT CLICK / LASER button. Press BLANK button on Remote Control Unit to black out image. To restore to normal, press BLANK button again or press any other button except POINT / SELECT / RIGHT CLICK / LASER button.

  • Page 22: Computer Mode

    DIRECT OPERATION Choose Computer by pressing INPUT button on Top Control or on Remote Control Unit. If projector cannot reproduce proper image, select correct input source through MENU OPERATION (see below). MENU OPERATION Press MENU button and ON-SCREEN MENU will appear. Press POINT LEFT/RIGHT buttons to select Input and press SELECT button.

  • Page 23: Pc Adjustment

    AUTOMATIC MULTI-SCAN SYSTEM This projector automatically tunes to most different types of computers based on VGA, SVGA, XGA or SXGA (refer to “COMPATIBLE COMPUTER SPECIFICATION” on page 26). When selecting Computer, this projector automatically tunes to incoming signal and projects proper image without any special setting. (Some computers need setting manually.) Note : Projector may display one of following messages.

  • Page 24: Manual Pc Adjustment

    Multi-Scan system of this projector. If this happens, projector cannot reproduce a proper image and image may be recognized as a flickering picture, a non-synchronized picture, a non-centered picture or a skewed picture.

  • Page 25: Computer Input

    Display area Selects area displayed with this projector. Select resolution at Display area dialog box. Display area H Adjustment of horizontal area displayed with this projector. Press POINT LEFT/RIGHT button(s) to decrease/increase value and then press SELECT button. Display area V Adjustment of vertical area displayed with this projector.

  • Page 26: Compatible Computer Specifications

    COMPUTER INPUT COMPATIBLE COMPUTER SPECIFICATIONS Basically this projector can accept a signal from all computers with V, H-Frequency mentioned below and less than 160 MHz of Dot Clock. ON-SCREEN RESOLUTION DISPLAY VGA 1 640 x 480 VGA 2 720 x 400...

  • Page 27: Picture Image Adjustment

    Select image level among Standard, Real, Image 1, Image 2, Image 3 and Image 4 by pressing IMAGE button on Top Control or on Remote Control Unit. Standard Normal picture level preset on this projector. Real Picture level with improved halftone for graphics. IMAGE 1~4 User preset picture adjustment in IMAGE ADJUST Menu (P28).

  • Page 28: Image Level Adjustment

    COMPUTER INPUT Press MENU button and ON-SCREEN MENU will appear. Press POINT LEFT/RIGHT buttons to move a red frame pointer to IMAGE ADJUST Menu icon. Press POINT DOWN button to move a red frame pointer to item that you want to adjust and then press SELECT button. Level of each item is displayed.

  • Page 29: Picture Screen Adjustment

    PICTURE SCREEN ADJUSTMENT This projector has a picture screen resize function, which enables you to display desirable image size. Press MENU button and ON-SCREEN MENU will appear. Press POINT LEFT/RIGHT button(s) to move a red frame pointer to SCREEN Menu icon.

  • Page 30: Video Mode

    VIDEO INPUT WHEN SELECT INPUT 2 (5 BNC INPUT JACKS ) When connecting to those equipment, select a type of Video source in SOURCE SELECT Menu. Press MENU button and ON-SCREEN MENU will appear. Press POINT LEFT/RIGHT button to move a red frame pointer to INPUT Menu icon.

  • Page 31: Selecting Video System

    When Video System is PAL-M or PAL-N, select system manually first. PAL / SECAM / NTSC / NTSC4.43 / PAL-M / PAL-N If projector cannot reproduce proper video image, it is necessary to select a specific broadcast signal format among PAL, SECAM, NTSC, NTSC 4.43, PAL-M, and PAL-N.

  • Page 32: Picture Image Adjustment

    Select image level among Standard, Cinema, Image 1, Image 2, Image 3 and Image 4 by pressing IMAGE button on Top Control or on Remote Control Unit. Standard Normal picture level preset on this projector. Cinema Picture level adjusted for picture with fine tone. IMAGE 1~4 User preset picture adjustment in IMAGE ADJUST Menu (P34).

  • Page 33: Image Level Adjustment

    IMAGE LEVEL ADJUSTMENT Press MENU button and ON-SCREEN MENU will appear. Press POINT LEFT/RIGHT button(s) to move a red frame pointer to IMAGE ADJUST Menu icon. Press POINT DOWN button to move a red frame pointer to item that you want to adjust and then press SELECT button. Level of each item is displayed.

  • Page 34: Picture Screen Adjustment

    Closes IMAGE MENU. PICTURE SCREEN ADJUSTMENT This projector has a picture screen resize function, which enables you to display desirable image size. Press MENU button and ON-SCREEN MENU will appear. Press POINT LEFT/RIGHT button(s) to move a red frame pointer to SCREEN Menu icon.

  • Page 35: Setting

    POINT UP/DOWN/LEFT/RIGHT button(s). Refer to KEYSTONE ADJUSTMENT on page 20. Blue back When this function is “On,” this projector will produce a blue image instead of video noise on screen when any input source is unplugged or turned off.
  • Page 36 When this function is “On,” projector is automatically turned on just by connecting AC Power cord to a wall outlet. Note ; Be sure to turn projector off properly (refer to section “TURNING OFF PROJECTOR” on P19). If projector is turned off in wrong steps, On Start function does not operate properly.

  • Page 37: Appendix

    Closes SETTING MENU. OPERATING WIRELESS MOUSE Wireless Remote Control Unit is not only able to operate this projector but also usable as a wireless mouse for most Personal Computers. POINT buttons and two CLICK buttons are used for wireless mouse operation.

  • Page 38: Maintenance

    Indicator stops flashing when temperature of a projector returns to normal. When WARNING TEMP. Indicator continues to flash, check items listed below. Ventilation Slots of a projector may be blocked. In such an event, reposition a projector so that Ventilation Slots are not obstructed.

  • Page 39: Lamp Replacement

    When life of Projection Lamp of this projector draws to an end, LAMP REPLACEMENT indicator lights yellow. When a projected image becomes dark or color of an image becomes unnatural, replacement of Projection Lamp is required. CAUTION For continued safety, replace with a lamp assembly of same type.

  • Page 40: Troubleshooting

    Problem may be with your graphics controller rather than with a projector. (When you reconnect a projector, be sure to turn computer and monitor off before you power up a projector. Power equipment back on in order of : Projector and computer.)
  • Page 41 If you still need help after checking the table above, you should call your dealer's technical support line and explain your problem. If your dealer cannot solve your problem, please call InFocus Corporation's Technical Support directly at 1-800- 799-9911. Support is free between 6 a.m. and 6 p.m. PST, Monday through Friday. Support is available in North America after hours and weekends for a fee at 1-888-592-6800.

  • Page 42: Technical Specifications

    APPENDIX TECHNICAL SPECIFICATIONS Projector Type Dimensions (W x H x D) Net Weight LCD Panel System Panel Resolution Number of Pixels Color System High Definition TV Signal Scanning Frequency Projection Lens Throw distance Motorized Lens Shift Projection Image Size (Diagonal)

  • Page 43: Configurations Of Terminals

    CONFIGURATIONS OF TERMINALS COMPUTER INPUT-1 TERMINAL (ANALOG) Terminal : HDB15-PIN Connect display output terminal of computer to this terminal with VGA Cable (supplied). When connecting Macintosh computer, MAC Adapter (supplied) is required. Pin Configuration COMPUTER INPUT-1 TERMINAL (DIGITAL) Terminal : DVI 24-pin Connect display output terminal of computer to this terminal with DVI cable (for Single Link T.M.D.S.
  • Page 44 'XU LQJ WKH :DUUDQW\ SHULRG IRU WKH 3URGXFW ,Q)RFXV ZDUUDQWV WKDW 5HSODFHPHQW ODPSV ZKLFK DUH SXUFKDVHG DW WKH WLPH RI SUR MHFWRU SXUFKDVH ZLOO KDYH D GD\ RU  KRXU ZDUUDQW\ ZKLFKHYHU FRPHV ILUVW IURP WKH GDWH WKH VSDUH ODPS LV SXW LQWR XVH...
  • Page 46 InFocus Corporation 27700B SW Parkway Avenue Wilsonville, Oregon 97070-9215 1-800-294-6400 503-685-8888 Fax: 503-685-8887 http://www.infocus.com Part No. 010-0429-00 11/2002 610 304 0028 (1AA6P1P3747-- MK3F) In Europe: Strawinskylaan 585. 1077 XX Amsterdam, The Netherlands Phone: (31) 20-5792000 Fax: (31) 20-5792999 In Asia:...
