Hunter 21623 Parts Manual

Hardware
(Drawn to Scale)
x 1
x 2
x 4
x 2
x 3
x 4
x 1
x 4
x 11
x 16
x 16
Balancing
x 1
Kit
x 3
Wire
x 4
Connector
x 3
Low Profile
Washer
3" Wood Screw
Flat Washer
Hanger
Bracket
Assembly
1.5" Wood Screw
Screw, Low
Profile
Canopy Screw
Setscrew
Mounting Isolator
Screw, Blade
Iron Armature
Blade
Assembly
Screw, Blade
Assembly
Blade
Grommet
Screw, Switch
Housing Assembly
Light/
Speaker
Assembly
Screw,
Machine, 6-32
Fan Parts
(Not Drawn to Scale)
PARTS GUIDE
PARTS GUIDE
Using this Parts Guide, make sure all Using this Parts Guide, make sure all Using this Parts Guide, make sure all
parts are included in the box. parts are included in the box. parts are included in the box.
If parts are missing, DO NOT RETURN If parts are missing, DO NOT RETURN If parts are missing, DO NOT RETURN
THIS ITEM TO THE STORE, call 888-830-1326 for assistance. THIS ITEM TO THE STORE, call 888-830-1326 for assistance. THIS ITEM TO THE STORE, call 888-830-1326 for assistance.
THIS PARTS GUIDE IS FOR REFERENCE ONLY. THIS PARTS GUIDE IS FOR REFERENCE ONLY. THIS PARTS GUIDE IS FOR REFERENCE ONLY.
REFER TO THE INSTALLATION MANUAL FOR FULL ASSEMBLY INSTRUCTIONS. REFER TO THE INSTALLATION MANUAL FOR FULL ASSEMBLY INSTRUCTIONS. REFER TO THE INSTALLATION MANUAL FOR FULL ASSEMBLY INSTRUCTIONS.
Model #

Parts List

Asm. Dwg. #
Finish
Item Name Qnty
* Hanging System Kit 1
Ceiling Plate
Canopy
Canopy Trim Ring
Hanger Ball / Downrod Assembly
Setscrew
Low Profile Washer
Canopy Screw
Wood Screw
Flat Washer
Mounting Isolator
* Screw, Low Profile
Switch Housing Assembly 1
Light/Speaker Assembly 1
Globe/Shade 1
Finial 1
Maestro™ 1
AC Adaptor 1
Remote Control Assembly 1
Blade Iron Set 1
Blade Set 1
Screw, Blade Iron Armature 11
Hardware Kit 1
Blade Grommet
Blade Assembly Screw
Screw, Machine, 6-32
Wire Connector
Screw, Switch Housing Assembly
Balancing Kit 1
Pull Chain Pendant 1
Pull Chain 1
Pull Chain Guide 1
Light bulb / Bulb 3
Hunter Fan Company • 7130 Goodlett Farms Pkwy # 400 • Memphis, TN 38016 • www.hunterfan.com • 98000-01-984 06-25-2009 •
21623
99251-01
New Bronze
Part #
98135-08
99261-08
99174-02
87849-04
88921-02
89001-01
77318-01
89005-01
98832-05
76697-82
63755-06
99251-00-860
07570-01
74393-08
63756-30
88973-01
77646-03
2009
©
