Summary of Contents for Central Pneumatic 42321
- Page 3 Do not overreach. Keep proper footing and balance at all times. SKU 42321 For technical questions, please call 1-800-444-3353. WORK AREA...
-
Page 4: Specific Safety Rules
CAUTION! Prior to its first use, and thereafter prior to each subsequent use, make sure to fill the Air Compressor with a premium quality, 30 weight, non-detergent oil to the specified level. Running the Air Compressor with no oil or with low oil will SKU 42321 For technical questions, please call 1-800-444-3353. - Page 5 Refer to the “Operating Instructions” section for details on filling the Air Compressor with oil. When filling the Air Compressor with oil, make sure to unscrew (do not pull) the Oil Fill Cap to remove.
- Page 6 Maintain labels and nameplates on the Air Compressor. These carry important information. If unreadable or missing, contact Harbor Freight Tools for a replacement. WARNING! People with pacemakers should consult their physician(s) before using this product. Electromagnetic fields in close proximity to a heart pacemaker could cause interference to or failure of the pacemaker.
- Page 7 Air Flow Valve (A-8). For easy connection or removal, a quick coupler should be installed on the end of the air output. Note: Use pipe thread seal tape on all threaded connections. SKU 42321 For technical questions, please call 1-800-444-3353. Setup...
- Page 8 When it is in the middle, it is open. Turn the Air Flow Valve to the appropriate pressure. Warning: Do not make any repairs, adjustments, or maintenance on the air compressor unless it is disconnected from the electrical power and the tank pressure is released.
- Page 9 BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. SKU 42321 For technical questions, please call 1-800-444-3353. Parts List “A”...
- Page 11 SKU 42321 For technical questions, please call 1-800-444-3353. Parts List “B” NOTE: Some parts are listed and shown for illustration purposes only and are not available individually as replacement parts...
- Page 12 Assembly Drawing “B” When ordering parts on this page, add the prefix “B” to the part number (Example: B-1 is a Screw) REV 02/04 SKU 42321 For technical questions, please call 1-800-444-3353. Page 12...
