Key Features - Samsung HLR5078WX Service Manual

Product Specification

2-2 Key Features

Model
Voltage
Frequency of Operation
Power Consumption
Dimensions
46.54 x 13.98 x 34.24 inches
(W x D x H)
Weight
■ H/W Configuration
- DMD Panel : 0.85" (1920 x1080p, TI)
- 1 Optical Engine for the Panel : Slim and Cost-effective
- Color Wheel : R/G/B Color Implementation
- Lamp : 120W : 50", 56", 61"
132W : 71"
- 2 NTSC/ATSC/QAM Tuners : NTSC/DTV Reception, Gemstar EPG & IR Transmitter
- Support HDMI Interface : Adopts DVI/HDMI systems for digital HDs including STB.
- DNIe4 : High quality image implementation
- AnyNet Feature : An enhanced interface for various external devices
- USB Interface : Use the USB interface for service purposes (S/W Upgrade)
■ S/W Configuration
- MCU : Built-in 300 MHz MIPS X226B CPU
- 4-Layered Architecture : Device Driver/OS/Hardware Abstraction/Application
- OSD : 32Bit True Color Graphics OSD
- Enhanced system stability by separating the DTV control and the application control systems into multi-processes.
■ Picture
- DMD Panel
＊Panel Size : 0.85"
＊Panel Resolution : 1920 x 1080
- Tuner : Integrated HDTV Tuner (NTSC/ATSC/QAM TUNER Embbeded)
- Display Format : 1920 x 1080
■ Sound
- Sound System : TruSurround XT,Dolby Digital
- Amp/Channel : 2 Channel Digital Amp
- Speaker System & Output(RMS)
＊Main L/R : 15W + 15W
＊Sound (RMS) : 15W + 15W
■ In/Out Terminals
- Rear : 2 RF In, 3 CVBS In, 3 S-VHS In, 2 Component In, 1 PC D-SUB In,
2 HDMI In(DVI Comportable With Adaptive Jack Only), 1 Anynet port, 2 IEEE1394, 1 Gemstar IR out, 1 Optical audio,
1 POD Card slot, 1 RS-232C port
2-2
HL-R5078W
AC 110 - 120V~ AC 110 - 120V~
60Hz
230 watts
52.36 x 15.30 x 37.86 inches
1182 x 355 x 869.7 mm 1330 x 388.5 x 961.7 mm
34.3 Kg / 75.62 lbs 38.5 Kg / 84.77 lbs
HL-R5678W HL-R6178W
AC 110 - 120V~
60Hz
230 watts 230 watts
56.93 x 18.40 x 41.58 inches
1446 x 467.4 x 1056.2 mm
45 Kg / 99.21 lbs
HL-R7178W
AC 110 - 120V~
60Hz 60Hz
230 watts
65.79 x 20.43 x 46.81 inches
1671 x 519 x 1189 mm
58.9 Kg / 116.6 lbs
Samsung Electronics
