MODEL T10222
ROUTER TABLE ATTACHMENT
OWNER'S MANUAL
Copyright © MArCh, 2010 By grizzly industriAl, inC., rEVisEd noVEMBEr, 2010 (ts)
WARNiNg: NO pORTiON Of THiS MANUAL MAy BE REpRODUCED iN ANy SHApE
OR fORM WiTHOUT THE WRiTTEN AppROvAL Of gRizzLy iNDUSTRiAL, iNC.
For ModEls MAnuFACturEd sinCE 12/09 #ts13341 printEd in ChinA

Advertisement

Table of Contents
loading

Related Manuals for Grizzly T10222

Summary of Contents for Grizzly T10222

  • Page 1 MODEL T10222 ROUTER TABLE ATTACHMENT OWNER'S MANUAL Copyright © MArCh, 2010 By grizzly industriAl, inC., rEVisEd noVEMBEr, 2010 (ts) WARNiNg: NO pORTiON Of THiS MANUAL MAy BE REpRODUCED iN ANy SHApE OR fORM WiTHOUT THE WRiTTEN AppROvAL Of gRizzLy iNDUSTRiAL, iNC.
  • Page 2 This manual provides critical safety instructions on the proper setup, operation, maintenance, and service of this machine/tool. Save this document, refer to it often, and use it to instruct other operators. Failure to read, understand and follow the instructions in this manual may result in fire or serious personal injury—including amputation, electrocution, or death.

  • Page 3: Table Of Contents

    • if your saw table or wing does not have mounting holes that match those in the Model t10222, you will need to drill and tap new holes in the saw table or wing.

  • Page 4: Manual Accuracy

    Your Machine For your convenience, we post all available man- uals and manual updates for free on our website at www.grizzly.com. Any updates to your model of machine will be reflected in these documents as soon as they are complete.

  • Page 5: Specifications

    © Grizzly Industrial, Inc. • Customer Service: (800) 523-4777 • Website: www.grizzly.com RoUTeR TABle ATTACHmeNT product Dimensions: Weight ... 82 lbs. table size ... 20" x 27" Shipping Dimensions: type ...Cardboard Content ... table saw Accessory Weight ... 88 lbs.

  • Page 6: Section 1: Safety

    Extended exposure to this noise without hearing protection can cause permanent hearing loss. MENTAL ALERTNESS. Be mentally alert when running machinery. Never operate under the influence of drugs or alcohol, when tired, or when distracted. Model t10222 (Mfg. since 12/09)
  • Page 7 FEED DIRECTION.­Unless­otherwise­noted,­feed­ work­ against­ the­ rotation­ of­ blades­ or­ cutters.­ Feeding­in­the­same­direction­of­rotation­may­pull­ your­hand­into­the­cut. Model t10222 (Mfg. since 12/09) FORCING MACHINERY.­Do­not­force­machine.­ It­ will­ do­ the­ job­ safer­ and­ better­ at­ the­ rate­ for­ which­it­was­designed. GUARDS & COVERS.­ Guards­ and­ covers­ can­...

  • Page 8: Additional Safety For Router Tables

    Always consider safety first, as it applies to your individual working conditions. Use this tool and other machinery with caution and respect. failure to do so could result in seri- ous personal injury, damage to equipment, or poor work results. Model t10222 (Mfg. since 12/09)

  • Page 9: Section 2: Setup

    This tool and its compo- nents are very heavy. Get lifting help to move heavy items. Model t10222 (Mfg. since 12/09) Needed for Setup the following are needed to complete the setup process, but are not included with your tool.

  • Page 10: Inventory

    Sometimes parts are pre-installed for shipping, or they become hidden by packaging materials. figure 3. shipping inventory items A–B. figure 4. shipping inventory items C–K. figure 5. shipping inventory items l–t. Model t10222 (Mfg. since 12/09)

  • Page 11: Assembly

    Assembly the Model t10222 mounts on most table saws that have 27" deep tables. if your table saw does not have mounting holes for the installation of the router table, you will need to drill and tap these holes. Also, you may have to modify the fence rails to allow access for the router table t-slots.
  • Page 12 (see figure 11). Cut-Out figure 11. Masking tape to shift the table up. saw. Tape Model t10222 (Mfg. since 12/09)
  • Page 13 Bars figure 13. t-slot bars installed. Model t10222 (Mfg. since 12/09) 10. place the fence assembly over the studs of the t-slot bars, then secure the fence in place by threading the knurled handles onto the studs, as shown in figure 14.
  • Page 14 13. Attach the plastic router guard to the guard bracket with the (2) star knob bolts, as shown in figure 18. star Knobs router guard figure 18. router guard installed. Model t10222 (Mfg. since 12/09)

  • Page 15: Router Installation

    Router installation the Model t10222 will support a router with a base thickness between ⁄ " and 2 To install a router: disConnECt thE sAW And routEr FroM poWEr! slide three of the router hold-down assem- blies into the t-slots underneath the router table so that they allow room for the router base, as shown in figure 19.

  • Page 16: Section 3: Operations

    WE STRONgLy RECOM- MEND that you read books, review industry trade magazines, or get formal training before beginning any projects. Regardless of the content in this section, grizzly industrial will not be held liable for accidents caused by lack of training. -14-...

  • Page 17: Workpiece Inspection

    Always visually inspect your workpiece for these items. if they can't be removed, do not cut the workpiece. Model t10222 (Mfg. since 12/09) Large/Loose Knots: loose knots may • dislodge during a cutting operation. Knots can cause kickback and machine damage.

  • Page 18: Edge Jointing

    (see figure 22). Top View Shim Cutting Direction figure 22. Edge jointing (guard removed for clarity). Model t10222 (Mfg. since 12/09) Infeed Fence Board Straight Router Bit Workpiece...

  • Page 19: Groove Cutting

    (see the illustrations in figures 23–24). Top View Depth-of-Cut figure 23. groove cutting setup, top view (guard removed for clarity). Model t10222 (Mfg. since 12/09) Depth-of-Cut Side View Table figure 24. groove cutting setup, side view (guard removed for clarity).

  • Page 20: Free-Hand Routing

    MUST be used. Starting Pin Collar Feed Direction figure 26. illustration of free-hand routing using a starting pin (guard not shown for clarity). Model t10222 (Mfg. since 12/09) Swing Workpiece...
  • Page 21 Glue can be used as an alternative. Model t10222 (Mfg. since 12/09) remove the fence assembly from the table. if possible, fabricate and mount a custom guard over the bit that safely protects your hands from the spinning cutter.

  • Page 22: Section 4: Maintenance

    For long term storage you may want to consider products like Boeshield t-9™. Cleaning & protecting Model t10222 (Mfg. since 12/09)

  • Page 23: Section 5: Parts

    PT10222004 THREADED STUD M8-1.25 X 40 PT10222005 SUPPORT LEG PN03M HEX NUT M8-1.25 PT10222007 FOOT PAD PB82M HEX BOLT M8-1.25 X 80 Model t10222 (Mfg. since 12/09) Table parts REF PART # PCAP13M PLW04M PW01M PT10222012 PT10222013 PN01M PB08M PT10222016 DESCRIPTION CAP SCREW M8-1.25 X 30...

  • Page 24: Fence Parts

    CAP SCREW M6-1 X 12 SQUARE NUT M6-1 CAP SCREW M6-1 X 16 FLAT HD SCR M6-1 X 25 TEFLON FLAT WASHER 8MM FLAT HD SCR M5-.8 X 8 PVC PAD FENCE BOARD SHIM 1.5MM INJURY HAZARD WARNING LABEL Model t10222 (Mfg. since 12/09)
  • Page 25 Do you think your machine represents a good value? Would you recommend Grizzly Industrial to a friend? Would you allow us to use your name as a reference for Grizzly customers in your area? Note: We never use names more than 3 times.
  • Page 26 FOLD ALONG DOTTED LINE FOLD ALONG DOTTED LINE Send a Grizzly Catalog to a friend: Name_______________________________ Street_______________________________ City______________State______Zip______ GRIZZLY INDUSTRIAL, INC. P.O. BOX 2069 BELLINGHAM, WA 98227-2069 TAPE ALONG EDGES--PLEASE DO NOT STAPLE Place Stamp Here...

  • Page 27: Warranty And Returns

    WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance.
