Read the Label and the Installation and Operation Manual of the chlorine generating device COMMANDER III Model JC7 before using. Competition Inc., 12775 rue Brault, Mirabel, Québec, Canada J7J 0C4 Tel: 450-437-2420 (COMMANDER III JC7 Cell label - English)
Page 2
PRODUCTS ACT COMMANDER III Model JC7 Chlorine PRODUCTS ACT COMMANDER III Model JC7 Chlorine Generating Device Generating Device One Commander III JC7 unit can treat a One Commander III JC7 unit can treat a maximum of 153,000 Liters of swimming maximum of 153,000 Liters of swimming pool water.
Page 3
COMMANDER III MODEL JC7 by Jacuzzi DOMESTIC Chlorine Generating Device Installation and Operation Manual COMMANDER III Model JC7 REGISTRATION NUMBER 27844.01 PEST CONTROL PRODUCTS ACT Maximum Output Equivalent To 0.82 Kg. Of Free Available Chlorine Per Day One Commander III Model JC7 Unit Can Treat a Maximum Of 153,000 Litres Of Swimming Pool...
Section 1a – GENERAL PRODUCT INFORMATION COMMANDER III MODEL JC7 by Jacuzzi Record The Following Information Installer: _____________________________Date of Installation: __________________________ Control Unit Control Unit Model Number: Commander III______ Serial Number: # ____________________________ Cell Cell Model: # JC7 Serial Number: # ____________________________ Factory Direct Customer Assistance…...
Section 1b – GENERAL PRODUCT INFORMATION IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS INSTALLATION AND EQUIPMENT RELATED Installation of all Commander III models: When installing and using your Commander III Model JC7 Control Box, basic safety precautions must always be followed, including the following: 1.
Section 1c – GENERAL PRODUCT INFORMATION Table of Contents COMMANDER III MODEL JC7 Section 1 GENERAL INFORMATION Product Information and Contact Numbers ............1 Important Safety Instructions................... 2 Table of Contents ....................... 3 Section 2 INSTALLATION Main Components ...................... 4 Control Box Connections...................
Input Power: 115 VAC (3.0 AC amps) Maximum Output:Equivalent to 0.82 kg (1.80 lbs) of free available chlorine/day 230 VAC (1.5 AC amps) Commander III JC7 Cell@ Power Level 3 (8 amps DC) 50/60 Hz Cell Life Expectancy: A minimum of 15,000 ampere/hours Output Power: Cell Power 1 (5.0* DC amps) Agency Approvals: NSF, ETL us, ETL c, CE...
Section 2b – INSTALLATION Control Box Connections Electrical Connections Autopilot recommends that a licensed electrician or certified electrical contractor perform the electrical connections. DANGER: ensure that the electrical panel or filter pump circuit breaker is turned OFF before wiring this unit. Your Commander III Model JC7 Control Box comes pre-wired from the factory for 230VAC (1.5 amps max draw) and can also operate on 115 VAC, (3.0 amps max draw) at 50/60Hz.
Section 2b – INSTALLATION Cell and Manifold Installation Your Commander III Model JC7 System is adaptable for use with the 7 blade (JC7) cell. The manifold must be located as the last accessory in the POOL RETURN LINE only. For special plumbing configurations, please contact your representative for assistance in locating the manifold.
Section 3a – OPERATION Key Features The Commander III Model JC7 display will show the SANITIZER OUTPUT LEVEL (in percent %) and whether the system is in BOOST or SUPER-BOOST Mode on the first line of the two line alphanumeric display. The second line will display the current TIME in either 12 or 24-hr mode, the TEMPERATURE in either Fahrenheit or Celsius, whether the cell is powered or not, shown as ON or OFF and Polarity Direction, shown as a “.”...
Page 11
Section 3a – OPERATION Key Features – continued COMMANDER III MODEL JC7 Digital S a n i t i z e r 100% 12:00P Check System Boost Menu Select Pump The MENU Button allows you to enter the programming and monitoring functions. Use UP/DOWN ARROW and SELECT to scroll through the Main menu and Sub-menu: Main Menu 1.0 Test Pool Pilot...
Page 12
Section 3a – OPERATION Key Features – continued COMMANDER III MODEL JC7 Digital S a n i t i z e r 100% 12:00P Check System Boost Menu Select Pump 3.0 MAINTENANCE MENU Use UP/DOWN ARROW and SELECT to scroll through the sub-menu. After completing a step, it displays the next step: 3.1 Test: same as 1.0 above plus cell Amp-hrs –...
Section 3b – OPERATION Pool Water Preparation Salt Requirements It is important that with typical pools, a salt residual of 2.8 – 3.2 gm/l (2800 to 3200 ppm) be maintained at all times for peak efficiency. NOTE: Maintaining high salt levels above recommended range can contribute to corrosion of pool/spa equipment. Salt levels exceeding the recommended concentration can be reduced by diluting the pool/spa with fresh water.
Section 3c – OPERATION Monitoring and Maintenance Water Chemistry Parameters - VERY IMPORTANT NOTE! Your Commander III Model JC7 is designed to provide Sanitizer on a daily basis. We recommend the following water chemistry ranges and periodic checks to monitor your systems efficiency. Always follow local health requirements.
Section 3c OPERATION (cont’d) Additional notes: For proper sanitation, spa must be completely drained periodically. The number of days between COMPLETE SPA DRAINAGE is equal to the volume of spa water in liters, divided by 10 times the maximum number of daily spa users.
Section 4b –SERVICE and MAINTENANCE Cell The Cell is installed with Unions on each end of the cell to allow quick and easy removal. Loosen the unions and remove the cell from the plumbing. Side View of Cell and Unions VISUAL CELL INSPECTION: The titanium Cell blades, seen inside the Cell body, should be straight and clear of any debris between the blades.
Section 4c –SERVICE and MAINTENANCE Parts Explosion Manifold Assembly: Manifold Union w/Strainer: (#941) (#19065) TRI-SENSOR Union Nut Union O-Ring (#19014) Strainer (#19064) CELL w/ UNIONS MANIFOLD UNION w/Strainer MANIFOLD BASE w/Check Valve Electrolytic Cell: (Cell Unions and Cord ordered separately) Red Cap Plug for JC7 cell cord (#19050) 12 ft.
Section 5a – TROUBLESHOOTING TROUBLESHOOTING PROBLEM CAUSE SOLUTION Insufficient Sanitizer Production. A) The test kit reagents or test strips are old or expired. A) Retest with new Reagents or Strips. B) The unit is set too low in relation to sanitizer demand. B) Increase the Sanitizer % output.
