TECHNICAL COMMUNICATION
OmniPCX Enterprise
URGENT
NOT URGENT
SUBJECT : INSTALLATION PROCEDURE FOR VERSION J1.410.34.C – RELEASE 10.0
This is the technical release of OmniPCX Enterprise with the version J1.410.34.c. It corresponds to
Release 10.0.
It is available on Alcatel-Lucent Business Portal (https://businessportal.alcatel-lucent.com) and on DVD
with the references 3BA 27740 AAAB (non secured version) and 3BA 27741 AAAB (secured version).
Technical modes to change the release, new features, registered restrictions and controlled features
are described in the installation procedure for version J1.410.34.c.
No. TC1449
Nb of pages : 108
TEMPORARY
1
Ed. 02
Date : 22 June 2011
PERMANENT
