Power Wheels P5064 Owner's Manual

Ford motor company motorized toy car user manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Please read this manual and save it

with your original sales receipt.

Tools needed for assembly: Phillips screwdriver

(not included); Assembly Wrenches (included).

Use only with a Power Wheels

Rechargeable Battery with A-Style Connector

and Built-In Thermal Fuse and Power Wheels

Super 6 Volt Charger (both included).

Product features may vary

from the picture above.

Owner's Manual

with Assembly Instructions

For Model P5064

For Model K3033

6 Volt

Table of Contents

Summary of Contents for Power Wheels POWER WHEELS P5064

Page 1 Please read this manual and save it Please read this manual and save it with your original sales receipt. with your original sales receipt. Tools needed for assembly: Phillips screwdriver Tools needed for assembly: Phillips screwdriver (not included); Assembly Wrenches (included). (not included);...
Page 2: Table Of Contents
Important Information ..................2 Parts .
Page 3 IMPORTANT INFORMATION ELECTRICAL HAZARD To prevent electric shock, do not immerse in water; wipe clean with a damp cloth. • Battery can fall out and injure a child if vehicle tips over. Always use the battery retainer. • PREVENT FIRE - N ever modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system. - U se of the wrong type battery or charger could cause a fire or explosion resulting in serious injury. - U se of Power Wheels components in products other than Power Wheels ® cause overheating, fire or explosion. • T he battery must be handled by adults only. The battery is heavy and contains sulfuric acid (electrolyte). Dropping the battery could result in serious injury. • Never allow children to charge the battery. Battery charging must be done by adults only. A child could be injured by the electricity involved in charging the battery. • Never lift or carry the battery by the wires or connector. This can damage the battery and possibly cause a fire resulting in serious injury. Lift and carry the battery by the case only. • Read the safety instructions on the battery. • Examine the battery, charger and their connectors for excessive wear or damage each time you charge the battery. If damage or excessive wear is detected, do not use the charger or the battery until you have replaced the worn or damaged part. • HOT motors. Handle carefully. RIDING HAZARD • Prevent Injuries and Deaths • Direct Adult Supervision Required.
Page 4: Parts
• If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. • Metal parts have been coated with a lubricant to protect them during shipment. Wipe all metal parts with a paper towel to remove any excess lubricant. Vehicle Pretend Motor Windshield PARTS Steering Linkage Seat Hood P5064pr-0922...
Page 5 PARTS Steering Column Steering Wheel Cover 2 Side Mirrors 4 Wheels 4 Hubcaps Steering Wheel 4 Hubcap Covers Rear Axle 2 Rear Wheel Drivers 2 Side Windows P5064pr-0922...
Page 6 2 Bushings Wrench - 2 6 Volt Battery Super 6 Volt Charger Part not shown: Label Sheet - 2 PARTS " -16 Hex Nut - 5 " Washer - 2 #8 x " Screw - 11 1" Bolt - 2 #12- 32 x 1 For your convenience, we included extra fasteners! Note: Tighten and loosen all screws with a Phillips...
Page 7: Parts Picture
Note: Some parts shown are assembled on both sides of the vehicle. Vehicle Bushing - 2 Seat Wheel - 4 Hood Hubcap - 4 Windshield Hubcap Cover - 4 Pretend Motor Steering Wheel 6 Volt Battery Steering Wheel Cover Steering Linkage Steering Column Side Mirror - 2 P5064pr-0922...
Page 8: Battery Charging
ELECTRICAL HAZARD WARNING • Battery can fall out and injure a child if vehicle tips over. Always use the battery retainer. • PREVENT FIRE - N ever modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system. - U se of the wrong type battery or charger could cause a fire or explosion resulting in serious injury. - U se of Power Wheels in products other than Power Wheels vehicles could cause overheating, fire or explosion. • T he battery must be handled by adults only. The battery is heavy and contains sulfuric acid (electrolyte). Dropping the battery could result in serious injury. • Never allow children to charge the battery. Battery charging must be done by adults only. A child could be injured by the elec- tricity involved in charging the battery. • Never lift or carry the battery by the wires or connector. This can damage the battery and possibly cause a fire resulting in serious injury. Lift and carry the battery by the case only.
Page 9: Assembly
BATTERY CHARGING Power Indicator Battery Connector INCORRECT • Plug the battery connector into the charger connector Push firmly to make sure the connectors are completely joined. • Plug the charger into a standard wall outlet Notes: - Use the charger only in a wall outlet. Do not plug into a ceiling outlet. - If power flow to the wall outlet is controlled by a switch, make sure the switch is “ON”. - The power indicator on the charger does not indicate the charge status of your battery.
Page 10 Seat Vehicle FRONT VIEW • Rotate the seat back and lift to remove from the vehicle. TOP VIEW • Locate the motors inside the vehicle. • Make sure each motor is positioned in the rectangular recesses inside the vehicle. ASSEMBLY Rear Axle Assembly • Slide the rear axle assembly through the hole in one motor, the Motors back end of the vehicle and then out through the other motor. Wheel (Rib Side In) Hubcap (Peg Side In) • Turn the vehicle upside-down.
Page 11 Wrench " -16 Hex Nut Rear Wheel Assembly • Fit a " -16 hex nut onto the end of the rear wheel assembly. • Tighten the hex nuts on both sides of the rear wheel assembly with the wrench. Hint: An extra wrench has been provided to hold the hex nut on one side of the rear axle while tightening the hex nut on the other side.
Page 12 Front Axle (Rib Side In) • Fit a wheel, rib side in, onto the front axle. • Slide a hubcap, peg side in, onto the front axle. " -16 Hex Nut • Fit a " -16 hex nut onto each end of the front axle. Tighten both hex nuts with the wrench. ASSEMBLY Hubcap (Peg Side In) Wheel • Fit and snap a hubcap cover to the hubcap. • Repeat Assembly steps 10-13 to assemble a washer, bushing, wheel, hubcap, hex nut and hubcap cover to the other front axle. Front Axle Wrench • Turn the vehicle upright. • Insert the tabs on the front edge of the seat into the floor of the vehicle.
Page 13 • Insert four #8 x " screws into the seat. • Tighten the screws with a Phillips screwdriver. Straight End of Steering Column BOTTOM VIEW • Lift the front end of the vehicle. • Insert the straight end of the steering column through the hole in the vehicle and out through the hole in the dashboard. • Hook the curved end of the steering column into the hole in the steering linkage. P5064pr-0922 ASSEMBLY Label #5 • Lower the front end of the vehicle. • Apply label #5 to the dashboard, as shown.
Page 14 Wrench " -16 Hex Nut Steering Column • Fit a " -16 hex nut on the end of the steering column. • Tighten the hex nut with the wrench. Steering Wheel Cover Steering Wheel • At an angle, fit the tabs on one side of the steering wheel cover into the slots in the steering wheel. • Press to “snap” the tabs on the other side of the steering wheel cover into the slots in the steering wheel. ASSEMBLY • Insert and “snap”...
Page 15 • Fit a side mirror to the side of the vehicle. #8 x " Screws RIGHT SIDE VIEW • From the inside of the vehicle, insert two #8 x through the vehicle and into the side mirror. • Tighten the screws. • Repeat Assembly steps 23 and 24 to assemble the other side mirror. P5064pr-0922 ASSEMBLY Side Mirror • Insert and “snap” the tabs at the top of the windshield into the slots in the top edge of the vehicle.
Page 16: Vehicle Care
ASSEMBLY Pretend Engine Hint: Before assembling the pretend engine, you may want to install the battery. Please refer to page 19, steps 2 and 3. • Fit the pretend engine into the front end of the vehicle. • Insert two 1" bolts into the pretend engine. • Tighten the screws. • Fit a peg on the hood into a slot in the front end of the vehicle. • Flex the hood slightly and then insert the other hood peg into the other slot in the front end of the vehicle. • Lower the hood. Push down near the front of the hood to “snap”...
Page 17: Decoration
Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. • Place the labels exactly as shown in the illustrations. • For best results, avoid repositioning a label once it has been applied to the vehicle. • After applying a label, rub the label firmly with a clean, dry cloth to make sure the label is adhered to your vehicle. Start at the center of a label, and smooth towards the outer edges to remove air bubbles. P5064pr-0922 DECORATION FRONT VIEW (Larger Label) (Smaller Label) REAR VIEW...
Page 18 DECORATION RIGHT SIDE LEFT SIDE P5064pr-0922...
Page 19: Battery Installation
BATTERY INSTALLATION IMPORTANT! Use only a Power Wheels ® rechargeable battery. Use of any other battery will damage your vehicle. Make sure you charge the battery for at least 18 hours using the enclosed Power Wheels charger before operating your vehicle for the first time. Charge the battery for at least 14 hours after each use of the vehicle. Never charge the battery longer than 30 hours.
Page 20: Battery Care And Disposal
BATTERY CARE AND DISPOSAL Care If a battery leak develops, avoid contact with the leaking acid and place the damaged battery in a plastic bag. See information below for proper disposal. If acid comes in contact with skin or eyes, flush with cool water for at least 15 minutes and call a physician.
Page 21: Safe Driving Rules
SAFE DRIVING RULES RIDING HAZARD WARNING • Prevent Injuries and Deaths • Direct Adult Supervision Required • Never Ride at Night. • K eep Children Within Safe Riding Areas. These areas must be: - away from swimming pools and other b odies of water to prevent drownings - generally level to prevent tipovers - away from steps, cars, steep inclines, roads and alleys. • Riding Rules Make sure children know and follow these rules for safe driving and riding. - Always sit on the seat. - Always wear shoes. - Only 1 (one) rider at a time. Use on generally level ground ONLY! P5064pr-0922 Teach Safety Rules to Children While children can quickly develop the skill necessary to drive this vehicle, it is important to remember that their judgment skills are still very immature.
Page 22: Vehicle Operation
IMPORTANT! Use this vehicle ONLY outdoors. Most interior flooring can be damaged by riding this vehicle indoors. Fisher-Price will not be responsible for damage to the floor ® if the vehicle is used indoors. Drive Forward • Press the FORWARD button below the seat. • Press the foot pedal. The vehicle will drive forward at a maximum of 3.5 mph.
Page 23: Limited Warranty
*One year limited warranty from the date of purchase on the Power Wheels Six month limited warranty on the 6 volt battery. For the original purchaser, this one year limited warranty covers the Power Wheels against defects in materials and workmanship. The six month limited warranty applies only to the 6 volt battery included by Power Wheels with the original purchase of the vehicle.
Page 24: Problems And Solutions Guide
PROBLEMS AND SOLUTIONS GUIDE IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels (EST) Monday through Friday, and 11 AM - 5 PM (EST) Saturday. Or, contact your local Power Wheels For the location nearest you, please visit us on-line at www.powerwheels.com, or call 1-800-348-0751. PROBLEM Vehicle does not run Consumer Relations, toll-free at 1-800-348-0751 between 9 AM and 7 PM ® POSSIBLE CAUSE Undercharged battery Charger is not working Tripped thermal fuse Loose wire or loose connectors Dead battery Electrical switch damage Motor damage authorized service center. ® SOLUTION Charge the battery. A new battery should have been charged for at least 18 hours before using the vehicle for the first time. After first-time use, recharge the battery for at least 14 hours after each use. Never charge the battery longer than 30 hours. Check all connectors. Make sure the charger connector is plugged into the battery connector, and that the charger is plugged into the wall. Make sure power flow to the wall outlet is “ON” . There is no sure way to tell if your charger is working unless you have a volt meter. If you suspect there is a problem with your ®...
Page 25 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE Vehicle was running but Loose wire or loose connectors suddenly stopped Tripped thermal fuse Short run time (Less than Undercharged battery 1 - 3 hours per charge) Overcharged battery Battery is old and will not accept full charge Tripped thermal fuse P5064pr-0922 SOLUTION Check all wires and connectors. Make sure the motor harness connector is plugged into the battery connector, and that there are no loose wires around the motors. ® Each Power Wheels 6 volt battery has a built-in thermal fuse. A thermal fuse may "trip" and shut down operation of the vehicle if the vehicle is overloaded or the driving conditions too severe. Once a fuse has "tripped", remove your foot from the pedal and wait 25 seconds before operating the vehicle again. To avoid repeated automatic shutdowns, do not overload the vehicle by exceeding the 65 lb. maximum weight capacity or by towing anything behind the vehicle. Do not drive up hills or run into fixed objects, which can cause the wheels to stop spinning while power is still being supplied to the motors. If a thermal fuse continually trips, contact your local Power Wheels ® authorized service center. Charge the battery. A new battery should have been charged for at least 18 hours before using the vehicle for the first time. After first-time use, recharge the battery for at least 14 hours after each use. Never charge the battery longer than 30 hours.
Page 26 PROBLEMS AND SOLUTIONS GUIDE PROBLEM Vehicle runs sluggishly Sometimes the vehicle doesn’t run, but other times it does POSSIBLE CAUSE Undercharged battery Battery needs charging Battery is old and will not accept full charge Vehicle is overloaded Driving conditions are too stressful Loose wire or connector Motor or electrical switch damage SOLUTION Charge the battery. A new battery should have been charged for at least 18 hours before using the vehicle for the first time. After first-time use, recharge the battery for at least 14 hours after each use. Never charge the battery longer than 30 hours. Check all connectors. Make sure the charger connector is plugged into the battery connector, and that the charger is plugged into the wall. Make sure power flow to the wall outlet is “ON” . Be sure to charge the battery after each use. Even with proper care, a rechargeable battery does not last forever. Average battery life is 1 to 3 years depending on the vehicle use and use conditions. Replace the battery with a new ® Power Wheels 6 volt rechargable battery. Do not substitute parts. Make sure you do not overload the vehicle by allowing more than one rider at one time, by exceeding the 65 lb. maximum weight capacity, or by towing objects behind the vehicle. Use only on generally level ground. Check all wires around the motors and all connectors to make sure they are tight.
Page 27 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE When the go foot pedal is Loose wire or connector pressed, the vehicle won’t run without a push “Dead Spot” on motor Loud clacking or grinding noise Broken gears from a motor-gearbox Charger gets warm during use It is normal for some chargers to get warm during use and is not reason for concern. Battery makes a sizzling or It is normal for some batteries to make gurgling noise when charging noise and swell slightly while charging and is not reason for concern. If, after reviewing the Problems and Solutions Guide, the vehicle still fails to operate, please contact your nearest authorized service center or contact Power Wheels ® Consumer Relations toll-free at 1-800-348-0751. P5064pr-0922 SOLUTION Check all wires around the motors and all connectors to make sure they are tight. ®...
Page 28 Charge the battery immediately after each use. Charge the battery once a month, even if the vehicle is not used or stored. Do not return your vehicle to the store! We're a toll-free phone call away, and we can help. If you are missing parts or need assistance, please call: 1-800-348-0751 Or contact your local independently owned and operated Power Wheels Authorized Service Center. ® For the location nearest you, visit us on-line at www.powerwheels.com. Ford Oval and F-150 are registered trademarks owned and licensed by Ford Motor Company. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A. ©2009 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc., unless otherwise stated. PRINTED IN MEXICO P5064pr-0922...
