Owner's Manual
Bass Amplifier
KATANA-110 BASS
KATANA-210 BASS
This Owner's Manual applies to the KATANA-110 BASS and
KATANA-210 BASS.
Explanations for specific models are distinguished by an icon (example:
KATANA-110 BASS
).
KATANA-210 BASS only
KTN110B
60 W output, 25 cm (10 inch) woofer, tweeter
KATANA-210 BASS
KTN210B
160 W output, 25cm (10inch) woofer ×2, tweeter
Advertisement
Table of Contents
Related Manuals for Boss KATANA-110 BASS
Summary of Contents for Boss KATANA-110 BASS
- Page 1 Owner’s Manual Bass Amplifier KATANA-110 BASS KATANA-210 BASS This Owner’s Manual applies to the KATANA-110 BASS and KATANA-210 BASS. Explanations for specific models are distinguished by an icon (example: KATANA-110 BASS KATANA-210 BASS only KTN110B 60 W output, 25 cm (10 inch) woofer, tweeter...
-
Page 2: Using The Unit Safely
USING THE UNIT SAFELY Before using this unit, carefully read “IMPORTANT SAFETY INSTRUCTIONS” (inside front cover), “USING THE UNIT SAFELY” (p. 2), and “IMPORTANT NOTES” (p. 3). After reading, keep the document(s) where it will be available for immediate reference. ©... -
Page 3: Important Notes
¹ Any data stored within the unit can be lost as the devices, such as cell phones, are operated in the ¹ Roland, BOSS, , KATANA are either registered result of equipment failure, incorrect operation, vicinity of this unit. Such noise could occur when trademarks or trademarks of Roland Corporation in etc. -
Page 4: Panel Descriptions
Panel Descriptions Top Panel INPUT jack EQUALIZER Connect your electric bass here. [BASS] knob INPUT EFX Adjusts the sound level of the low-frequency range. Here you can make settings for the built-in effects installed in the [LOW MID] button input section. For details on the effect types and settings for each knob, refer to “Using the Effects”... -
Page 5: [Panel] Button
Panel Descriptions MEMO To switch between BANK A and BANK B, hold down the [PANEL] button for approximately one second when any one of the [CH 1]– [CH 3] buttons are selected. The selected [CH1]–[CH3] button blinks, and the bank switches between BANK A and BANK B. -
Page 6: Rear Panel
Download the USB driver from the Roland website. For details, able to mitigate the problem by switching the position of the refer to Readme.htm which is included in the download. [GND LIFT] switch. The [GND LIFT] switch should be normally set http://www.boss.info/support/ to OFF. AUX IN jack Switch... -
Page 7: Foot Control
BANK A and BANK B and CH 1 and CH 2. If you connect an expression pedal (sold separately: Roland EV-5, BOSS EV-30, BOSS FV-500L, BOSS FV- 500H), you can use your foot to vary the volume. -
Page 8: Connecting A Footswitch
Connecting a Footswitch If you connect an expression pedal (sold separately: Roland EV-5, BOSS EV-30, BOSS FV-500L, BOSS FV-500H), you can use the pedal to Connecting a footswitch (sold separately: BOSS FS-6, FS-7, or vary the volume or control an effect such as WAH. -
Page 9: Turning The Power On/Off
Panel Descriptions Turning the Power On/Off * Once everything is properly connected (p. 4–p. 7), be sure to follow the procedure below to turn on their power. If you turn on equipment in the wrong order, you risk causing malfunction or equipment failure. -
Page 10: Using The Effects
¹ Back up effects and other internal settings, or restore settings from a backup. FX2 depth FX1 depth You can easily download the dedicated software from our BOSS (inside) (outside) TONE CENTRAL (http://bosstonecentral.com/) website. For details on how to use the software, refer to the Readme.htm file... -
Page 11: Registering A Mobile Device (Pairing)
Attach the BT-DUAL (sold separately) to the unit to wirelessly play back music on your mobile device, or to edit the effects of this unit from the app on your mobile device. * Note that the KATANA-110 BASS and KATANA-210 BASS does not offer Bluetooth functionality. You’ll need to attach the BT-DUAL (sold separately) to use Bluetooth. - Page 12 MEMO ¹ If you were unable to connect using the steps above, tap “KTN- Use the “BOSS TONE CENTRAL” app to edit effects and save settings BASS Audio, ” displayed in the Bluetooth device screen of the on this unit.
-
Page 13: Block Diagram
Block Diagram TYPE SWITCH ･VINTAGE TWEETER POWER ･FLUT ON/OFF CONTROL ･MODERN -Secondary (Windows) -Primary (Windows) -Input/Output (Mac) -Input 1,2/Mono Out (1,2) (Mac) TWEETER No signal from the USB will be TWEETER POWER AMP output from the speaker. BLEND WOOFER Input FOOT MASTER PREAMP... -
Page 14: Main Specifications
Main Specifications KATANA-210 BASS KATANA-110 BASS Rated Power Output 160 W 60 W INPUT: -10 dBu (1 MΩ) INPUT: -10 dBu (1 MΩ) POWER AMP IN: -10 dBu (20 kΩ) POWER AMP IN: -10 dBu (20 kΩ) Nominal Input Level AUX IN: -10 dBu (20 kΩ) - Page 15 Main Specifications KATANA-210 BASS KATANA-110 BASS COMP COMP DRIVE DRIVE SHAPE SHAPE BLEND BLEND LOW MID LOW MID HIGH MID HIGH MID Indicators PANEL PANEL TWEETER TWEETER INPUT jack: 1/4-inch phone type INPUT jack: 1/4-inch phone type POWER AMP IN jack: 1/4-inch phone type...
