The Ranger Edge Receiver, a unique member of the Ranger line of long-range Receivers, offers single location point of control with all set-up and
configuration done directly on the unit, eliminating the requirement for separate mobile smartphone or PC programming devices.
The Edge Receiver offers 512 separate enrollment locations, ranging from zero to 511. Each enrollment location may store a unique credential,
such as a Transmitter—or with the addition of a Wiegand-output reader, a card or tag. Dip switch positions 1 thru 9 of the 12-Position Slide Style
Dip Switch are used to select specific individual enrollment locations. Each specific selection represents a binary number. Below are examples of
individual enrollment locations, along with their equivalent binary and decimal number representations.
EXAMPLES:
H
ADDRESS
H
ADDRESS
H
ADDRESS
L
ADDRESS
L
1
1
7
9
6
8
5
7
9
4
6
8
3
5
7
9
2
4
6
8
1
3
5
7
2
4
6
1
3
5
2
4
0
0
A. Enrollment Location 3
Set dip switches 3, 4, 5, 6, 7,
8 and 9 to the 0-position, and
dip switches 1 and 2 to the
1-position. (000000011
binary, 3 decimal)
Enrollment locations and their equivalent dip switch settings can be confirmed and documented on the
The dip switches are set to the 0-position by default.
1.0 Selecting Transmitter Button To Operate Relay
Dip switches 10 and 11 select which button on a Transmitter will
operate the relay (see below). It is only possible to select a single
Transmitter button per Edge Receiver (Button 1, 2, 3 or 4). The button
selected for relay operation will be the same for all Transmitters
enrolled in that specific Edge Receiver.
11 10
11 10
Transmitter
Transmitter
Button 1
Button 2
2.0 Enrolling Transmitters
1. Move dip switch 12 to the Program position. The
Program/Run LED will change from off to red.
2. Use dip switches 10 and 11 to select the button
on a Transmitter that will operate the relay.
3. Use dip switches 1 through 9 to select the
enrollment location of the Transmitter.
4. Press the Select Button once. The Status LED
will change from yellow to blue.
5. Within range of the Edge Receiver, press the
selected button on the Transmitter to be enrolled.
The Status LED will change from blue to yellow.
6. To enroll additional Transmitters, repeat 3, 4 and 5.
EDGE RECEIVER CONFIGURATION
L
H
L
H
ADDRESS
H
ADDRESS
H
ADDRESS
L
1
1
1
3
2
9
1
8
7
9
6
8
5
7
9
4
6
8
3
5
7
9
2
4
6
8
1
3
5
7
0
0
B. Enrollment Location 21
Set dip switches 2, 4, 6, 7, 8
and 9 to the 0-position, and
dip switches 1, 3 and 5 to the
1-position. (000010101
binary, 21 decimal)
11 10
11 10
Transmitter
Transmitter
Button 3
Button 4
PROGRAM
ADDRESS
L
L
H
L
H
ADDRESS
H
ADDRESS
1
1
1
1
2
4
6
1
3
5
2
4
1
3
2
9
1
8
7
9
6
8
5
7
9
4
6
8
0
0
0
0
C. Enrollment Location 247
Set dip switches 4 and 9 to
the 0-position, and dip
switches 1, 2, 3, 5, 6, 7 and 8
to the 1-position. (011110111
binary, 247 decimal)
7. To finish enrolling, move dip switch 12 to the Run position. The
Program/Run LED will change from red to off.
8. To test enrollment of an enrolled Transmitter, press the selected
Transmitter button. The Status LED and Relay LED will turn green
for the active relay time.
3.0 Deleting Transmitters
1. Move dip switch 12 to the Program position. The Program/Run LED
will change from off to red.
2. Use dip switches 1 through 9 to select the desired enrollment
location of the Transmitter to be deleted.
3. Press the Select Button twice in succession. The Status LED will
change from yellow to blue then red.
4. To delete additional enrolled Transmitters, repeat 2 and 3.
5. To finish deleting, move dip switch 12 to the Run position. The
Program/Run LED will change from red to off.
6. To test deletion of a previously enrolled Transmitter press the
Transmitter button that had been deleted. The Status LED will
change from yellow to red.
12
12
12
12
4.0 Enrolling Credentials
1. Connect a reader supporting the credentials to be enrolled via the
Wiegand interface.
RUN
2. Move dip switch 12 to the Program position. The Program/Run LED
Position
Position
will change from off to red.
3. Use dip switches 1 through 9 to select the enrollment location of
SW1
the credential.
4. Press the Select Button once. The Status LED will change from
SELECT
yellow to blue.
Select Button
H
ADDRESS
L
ADDRESS
L
L
H
L
H
1
1
1
3
5
7
9
2
4
6
8
1
3
5
7
2
4
6
1
3
5
2
4
1
3
2
9
1
8
7
9
0
0
0
D. Enrollment Location 500
Set dip switches 1, 2 and 4 to
the 0-position, and dip
switches 3, 5, 6, 7, 8 and 9 to
the 1-position. (111110100
binary, 500 decimal)
Credential Location
ADDRESS
H
ADDRESS
H
ADDRESS
L
ADDRESS
L
L
1
1
1
6
8
5
7
9
4
6
8
3
5
7
9
2
4
6
8
1
3
5
7
2
4
6
1
3
5
2
4
1
0
0
0
Worksheet.
1
3
2
0
