Summary of Contents for Eizo L761T-C

  • Page 2: Fcc Declaration Of Conformity

    Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord - Shielded Signal Cable This Class B digital apparatus complies with Canadian ICES-003.
  • Page 3 User’s Manual Touch Panel Color LCD Monitor It shall be assured that the final system is in compliance to IEC60601-1-1 requirements.
  • Page 4: Safety Symbols

    EIZO NANAO CORPORATION. EIZO NANAO CORPORATION is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO NANAO CORPORATION's receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.
  • Page 5: Table Of Contents

    TABLE OF CONTENTS PRECAUTIONS ... 4 1. INTRODUCTION ... 9 1-1. Features ...9 1-2. Package Contents...9 1-3. Controls & Connectors ...10 2. CABLE CONNECTION ... 12 2-1. Before connecting ...12 2-2. Connecting the signal cable ...13 2-3. Touch Operation...15 2-4. Connecting two PCs to the monitor...15 3.
  • Page 6: Precautions

    English PRECAUTIONS IMPORTANT • This product has been adjusted specifically for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specified in the specifications. • To ensure personal safety and proper maintenance, please read carefully this section and the caution statements on the monitor.
  • Page 7 WARNING If the unit begins to emit smoke, smells like something is burning, or makes strange noises, disconnect all power connections immediately and contact your dealer for advice. Attempting to use a malfunctioning unit may result in fire, electric shock, or equipment damage.
  • Page 8 English WARNING To avoid danger of suffocation, keep the plastic packing bags away from babies and children. Use the enclosed power cord and connect to the standard power outlet of your country. Be sure to remain within the rated voltage of the power cord. Not doing so may result in fire or electric shock.
  • Page 9 WARNING Do not touch a damaged LCD panel directly with bare hands. The liquid crystal that may leak from the panel is poisonous if it enters the eyes or mouth. If any part of the skin or body comes in direct contact with the panel, please wash thoroughly.
  • Page 10: Notice For This Monitor

    English Notice for this monitor This product is suited to creating documents, viewing multimedia content, and other general purposes. In order to suppress the luminosity change by long-term use and to maintain the stable luminosity, use of a monitor in lower brightness is recommended. The LCD panel is manufactured using high-precision technology.
  • Page 11: Introduction

    1. INTRODUCTION Thank you very much for choosing an EIZO Color Monitor. 1-1. Features • Dual inputs compliant • DVI (p.34) Digital input (TMDS (p.35)) compliant. • Horizontal scanning frequency: Vertical scanning frequency: Resolution: • Auto Adjustment compliant • Support to sRGB (p.35) standard •...
  • Page 12: Controls & Connectors

    English 1-3. Controls & Connectors Front Control Panel SIGNAL MODE 1 - 2 (3) (4) (5) ® (1)ScreenManager (2)SIGNAL1-2 (3)MODE (4)AUTO (5)ENTER 1. INTRODUCTION AUTO ENTER Monitor Adjustment menu (p.16) Input Signal Switch the input signals when connecting 2 Selection Button PCs.
  • Page 13 Rear (13) (14) Bottom Power Connector (10) DVI-D Connector (SIGNAL1) D-Sub mini 15 pin (11) Connector (SIGNAL2) (12) USB port (Up) (13) Hole for TP1 Security Lock Slot (14) (15) Stand (Detachable) (15) (10) (11)(12) Connect the power cord. Connect the optional digital cable. Connect the enclosed analog cable (MD- C87) Connect the USB cable (MD-C93)
  • Page 14: Cable Connection

    English 2. CABLE CONNECTION 2-1. Before connecting Before connecting your monitor to the PC, change the display screen settings (resolution (p.35) and frequency) in accordance with the charts below. NOTE • The lower display modes like 640x 480, automatically enlarge to the maximum display mode (1280 x 1024), and some lines of the characters may become fuzzy.
  • Page 15: Connecting The Signal Cable

    2-2. Connecting the signal cable NOTE • Be sure that the power switches of both the PC and the monitor are OFF. Plug the signal cable into the connector at the rear of the monitor and the other end of the cable into the video connector on the PC. After connecting, secure the connection with the screw-in fasteners.
  • Page 16 English Plug the power cord into the power connector on the rear of the monitor. Then, plug the other end of the cord into a power outlet. WARNING Use the enclosed power cord and connect to the standard power outlet of your country. Be sure to remain within the rated voltage of the power cord.
  • Page 17: Touch Operation

    2-3. Touch Operation Point and touch with one finger only. NOTE • Do not touch the screen while turning on the PC and the monitor. Touch the screen five seconds later after appearing the image. • Touch the screen five seconds later after connecting the USB cable. •...
  • Page 18: Screenmanager

    English 3. ScreenManager 3-1. How to use the ScreenManager Entering the ScreenManager Press the Enter Button once to display the main menu of the ScreenManager. Making Adjustments and Settings (1) Select the desired sub menu icon using the Control Buttons and press the Enter Button.
  • Page 19: Adjustments And Settings

    3-2. Adjustments and Settings The following table shows all the ScreenManager’s adjustment and setting menus. “*” indicates adjustments of analog input only. Main menu Screen Color Others Information Language Due to the inspection on the factory, the usage time may not “0 hour” at shipping. Sub menu Clock 4-1.
  • Page 20: Useful Functions

    English 3-3. Useful Functions Adjustment Lock Use the “Adjustment Lock” function to prevent any accidental changes. Locked function Unlocked function [To lock] (1) Switch off the monitor’s power by the power switch on the control panel. (2) Press on the Auto adjustment button while switching on the monitor’s power. [To unlock] (1) Switch off the monitor’s power by the power switch on the control panel.
  • Page 21: Automatically Selecting The Input Signal Function

    English EIZO Logo display Enables to display the EIZO logo for a while when switching on the monitor (Default is no logo). If you desire to display or undisplay this logo, use this function. [To display] (1) Switch off the monitor’s power by the Power switch on the control panel.
  • Page 22: Adjustment

    English 4. ADJUSTMENT The monitor displays the digital input image correctly based on its pre-setting data. Adjust the brightness (p.23). 4-1. Screen Adjustment Screen adjustments for the LCD monitor should be used in suppressing screen flickering and also for adjusting the screen to its proper position. There is only one correct position for each display mode.
  • Page 23 NOTE • More precise adjustment is available for using the “Screen Adjustment program” utility software. It can be downloaded from the EIZO homepage (http://www.eizo.com/). Adjust by using <Screen> menu in the ScreenManager. (1) Vertical bars appear on the screen →...
  • Page 24 English (3) The screen position is incorrect. → Use the <Position> adjustment. The correct displayed position of the monitor is decided because the number and the position of the pixels are fixed. The “Position” adjustment moves the image to the correct position. Select <Position>...
  • Page 25: Color Adjustment

    4-2. Color Adjustment In the analog input, perform the “Range Adjustment” (p.22) before making the color adjustments. The <Color> menu in the ScreenManager enables to change the color of the screen. By using the <Color Mode>, the adjustment mode can be selected from <Custom mode> (to adjust the color settings according to your preference) and <sRGB>...
  • Page 26 English Menu Color Mode Custo √ Gamma (p.34) √ Saturation √ √ Gain (p.34) √ Reset 4. ADJUSTMENT Function Descriptions sRGB To set the gamma value NOTE • If setting the gamma value, the using the monitor in the digital signal input is recommended. If using the monitor in the analog input signal, set the gamma value from 1.8 to 2.2.
  • Page 27: Attaching A Stand

    5. ATTACHING A STAND The LCD monitor can be used with other stand by removing the tilt stand and attaching the stand to the LCD monitor. NOTE • When attaching an arm or stand, follow the instructions of their user’s manual. •...
  • Page 28: Troubleshooting

    English 6. TROUBLESHOOTING If a problem persists even after applying the suggested remedies, contact an EIZO dealer. The latest FAQ information is supplied on EIZO homepage (http://www.eizo.com/). • No Picture Problems Problems 1. No picture • Indicator status: Off • Indicator status: Blue •...
  • Page 29 • Imaging problems Problems 3. Display position is incorrect. 4. Vertical bars of distortion appear. 5. Horizontal bars of distortion appear. 6. Letters and lines appear blurred. 7. The screen is too bright or too dark. 8. Afterimages appear. 9. The screen has defective pixels (e.g.
  • Page 30 English • Other problems Problems 10. The <Smoothing> cannot be selected. 11. The Enter Button does not operate. 12. The Auto Adjustment Button does not operate. • Touch Panel Problems Problems 13. Cursor is jittery. / Drawing lines are not straight and smooth. 6.
  • Page 31 Problems 14. Cursor position is not correct. / Cursor jumps. 15. No touch sound. Points to check with possible solutions When cursor position is incorrect or cursor jumps, turn off and on the monitor. If the symptom is not improved, perform the calibration on the monitor.
  • Page 32: Cleaning

    English 7. CLEANING Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime. NOTE • Never use any solvents or chemicals, such as thinner, benzene, wax, alcohol, disinfectant, and abrasive cleaner, which may damage the cabinet or panel. •...
  • Page 33: Specifications

    8. SPECIFICATIONS LCD Panel Dot Pitch Horizontal Scan Frequency Vertical Scan Frequency Resolution Dot Clock (Max.) Display Colors Display Area Touch Panel Communication protocol Communication speed Detective method Power Supply Power Consumption Input Connector Analog Input Signal (Sync) Analog Input Signal (Video) Input Signal (Digital) Signal registration Plug &...
  • Page 34 English Classification of Equipment Default settings Brightness Smoothing Temperature Input Signal Off Timer Language Optional Touch Panel Pointer Dimensions 8. SPECIFICATIONS Type of protection against electric shock: Class I EMC class: EN60601-1-2:2001+A1:2006 Group1 Class B Classification of medical device (MDD 93/42/EEC): Class I 100% Off (normal white: approx.
  • Page 35: Pin Assignment

    Pin Assignment D-Sub mini 15 pin connector DVI-D Connector 1 2 3 4 5 6 7 8 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 USB Port Contact No. Upstream Series B connector Signal Signal Red video...
  • Page 36: Glossary

    English 9. GLOSSARY Clock With the analog input signal display, the analog signal is converted to a digital signal by the LCD circuitry. To convert the signal correctly, the LCD monitor needs to produce the same number clock pulse as the dot clock of the graphics system. When the clock pulse is not correctly set, some vertical bars of distortion are displayed on the screen.
  • Page 37 Range Adjustment The Range Adjustment controls the level of output signal range to display the whole color gradation. Resolution The LCD panel consists of numerous pixels of specified size, which are illuminated to form images. The display panel of this monitor consists of 1280 horizontal pixels and 1024 vertical pixels.
  • Page 38: Appendix/Anhang/Annexe

    APPENDIX/ANHANG/ANNEXE Preset Timing Chart for Analog input Timing-Übersichten für Analog Eingang Synchronisation des Signaux pour Analog numerique Based on the signal diagram shown below factory presets have been registered in the monitor's microprocessor. Der integrierte Mikroprozessor des Monitors unterstützt werkseitige Standardeinstellungen (siehe hierzu die nachfolgenden Diagramme).
  • Page 39: Emc Information

    Guidance and manufacturer’s declaration - electromagnetic emissions The FlexScan L761T-C is intended for use in the electromagnetic environment specified below. The customer or the user of the FlexScan L761T-C should assure that it is used in such an environment. Emission test...
  • Page 40 Guidance and manufacturer’s declaration - electromagnetic immunity The FlexScan L761T-C is intended for use in the electromagnetic environment specified below. The customer or the user of the FlexScan L761T-C should assure that it is used in such an environment. Immunity test...
  • Page 41 Guidance and manufacturer’s declaration - electromagnetic immunity The FlexScan L761T-C is intended for use in the electromagnetic environment specified below. The customer or the user of the FlexScan L761T-C should assure that it is used in such an environment. Immunity test...
  • Page 42 Recommended separation distances between portable and mobile RF communications equipment and the FlexScan L761T-C The FlexScan L761T-C is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the FlexScan L761T-C can help prevent...
  • Page 43 Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor Dieser Monitor ist für Bildschirmarbeitsplätze vorgesehen. Wenn nicht der zum Standardzubehör gehörige Schwenkarm verwendet wird, muss statt dessen ein geeigneter anderer Schwenkarm installiert werden. Bei der Auswahl des Schwenkarms sind die nachstehenden Hinweise zu berücksichtigen: Der Standfuß...
