2-2 PCM30 line drawer maintenance

PCM30 line drawer maintenance description

The existing standard line drawer (SLD) maintenance has been extended to
support the maintenance of the PCM30 line drawer (PLD), specifically the
PCM30 interface card (PIC), which is an integral part of the PLD.
Maintenance is performed by the line concentrating module (LCM) drawer
maintenance, which is part of the LCM maintenance, and includes
maintenance of the PIC. Therefore, the automatic and manual maintenance
procedures executed on the PLD are similar to those executed on the SLD.
The codes that indicate the state of the PLD are similar to the codes for the
SLD. The codes are listed below with a brief description. The state of a
drawer is changed either automatically by the system, or manually by
inputting commands at the MAP terminal. Log report PM181 is generated to
indicate the state changes, for example, ManB from SysB.
Table 2-1xxx
PLD drawer states
Code
. (dot)
M
O
S
-
297-2101-504 Standard 02.01 December 1991
Description
The PLD is in service and is available for call processing.
The PLD has been manually busied for maintenance
purposes and is unavailable for call processing.
The PLD is offline for maintenance purposes and is
unavailable for call processing.
The PLD has been automatically taken out of service for
maintenance purposes and is unavailable for call processing.
The PLD is unequipped and is unavailable for call
processing.
