- Page 1 Managed 4-Port ECB With Bonded MoCA Model # ECB5240M User Guide xxxx-xxxx-000 rev. 1...
-
Page 2: Table Of Contents
Table of Contents Getting Started Introduction Package Contents Requirements Features Connecting the Adapter Connecting an Adapter Connecting Additional Adapters Accessing the Adapter’s GUI Status Advanced Setup Specifications Notices Warranty Important Safety Instructions FCC Class B Equipment Technical Support... -
Page 3: Getting Started
Getting Started Introduction Congratulations for purchasing the Actiontec ECB5240M Managed 4- Port ECB with Bonded MoCA Adapter. The Adapter is a simple, flexible solution for extending a home network. By leveraging the ubiquity of coaxial cabling within the modern home, the Adapter provides multiple Ethernet Internet ports anywhere a coaxial connection is available. -
Page 4: Package Contents
Managed 4-Port ECB with Bonded MoCA Package Contents • ECB5240M Managed 4-Port ECB with Bonded MoCA Adapter • Coaxial cable • Power adapter • Ethernet cable • Quick Start Guide Requirements • Available coaxial port in installation areas • Available electrical wall socket in installation areas Features •... -
Page 5: Connecting The Adapter
4. Plug one end of an Ethernet cable into one of the Adapter’s four Ethernet ports. 5. Locate a device to connect to the Internet. Plug the other end of the Ethernet cable into an Ethernet port on the device. External; 12V DC, 1.5A; made by Actiontec; model no. KSASB0241200150HU... - Page 6 If the Coax LED does not turn green, there is no Internet signal transmitting across the coaxial network, or the router does not support MoCA. When complete, the setup should look similar to the figure below: ECB5240M Power Coax Coaxial...
- Page 7 7. Plug one end of an Ethernet cable into the Ethernet port on the side of the Adapter. 8. Locate the device to connect to the Internet. Plug the other end of the Ethernet cable into an open Ethernet port on the device. External; 12V DC, 1.5A; made by Actiontec; model no. KSASB0241200150HU...
-
Page 8: Connecting Additional Adapters
When finished, the setup should look like the figure on page 5, except for the coaxial connections, which should look like the figure below: wer Coax If Coaxial Port is Being Used by Another Device: Coax In To Coax In Port on Coaxial ECB6240 ECB5240M Cable Coaxial Cable 6240 Coaxial 2-Way Cable Splitter... -
Page 9: Accessing The Adapter's Gui
Accessing the Adapter’s GUI The Adapter features an onboard graphical user interface (GUI) that includes user-configurable settings. Some of these settings should be accessed by experienced network technicians only. To configure the network settings of the Adapter: 1. Ensure that the Adapter is powered up and connected to a computer via an Ethernet cable. -
Page 10: Status
Managed 4-Port ECB with Bonded MoCA Status The first GUI screen that appears is the Status screen (see figure on previous page), which can also be generated by clicking the Status icon in the menu bar. This screen contains basic information about the Adapter’s network stations, as well as relevant product information. - Page 11 Accessing the Adapter’s GUI Change Password The Change Password screen allows the user to change the password that allows access to the GUI. To change, enter the current password, enter and re-enter the new password, then click Apply. Be sure to write the password down and keep it somewhere safe, as it will be needed to access the Adapter’s GUI in the future.
- Page 12 Managed 4-Port ECB with Bonded MoCA Factory Default The Factory Default screen allows the Adapter’s factory default settings to be reapplied, erasing all current settings. Click Restore Default Settings to restore the Adapter to its factory default state. Firmware Restore The Firmware Restore screen lists the active and backup firmware versions available on the Adapter.
- Page 13 Accessing the Adapter’s GUI Firmware Upgrade Actiontec periodically posts firmware upgrades that may include enhancements and/or bug fixes for the Adapter. To upgrade the Adapter’s firmware: 1. Go to www.actiontec.com/support for information about the latest firmware available for the Adapter. If the version is the same as the current version applied to the Adapter, there is no need to upgrade the firmware.
-
Page 14: Specifications
Specifications Model Number ECB5240M (Managed 4-Port ECB with Bonded MoCA) LAN MoCA (v. 2.0; up to 1 Gbps throughput) LAN Ethernet Port 10/100/1000 (4) LAN Connections Coax In Frequency Range: Extended D-band: 1125MHz ~ 1675MHz; Full Port Range: 5MHz ~ 2150MHz... - Page 15 Bonded MoCA Network Adapter With 4 Ethernet Ports Environmental Ambient temperature: 0ºC to 40ºC (32ºF to 104ºF) Storage temperature: -20ºC to 85ºC (-4ºF to 185ºF) Operating humidity: 10% to 85% non-condensing Storage humidity: 5% to 90% non-condensing Note: Specifications are subject to change without notice.
-
Page 16: Notices
Statement shall be deemed modified to be consistent with such local law. Under such local law, certain disclaimers and limitations of this Warranty Statement may not apply to the customer. Go to http://www.actiontec.com/products/warranty.php for more information. -
Page 17: Important Safety Instructions
Managed 4-Port ECB with Bonded MoCA Important Safety Instructions Basic safety precautions should always be followed to reduce the risk of fire, electrical shock, and personal injury, including the following: • Do not use this product near example, near a bathtub, water–for kitchen sink, laundry tub, or swimming pool, or in a wet basement;... -
Page 18: Fcc Class B Equipment
Notices FCC Class B Equipment This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 19 The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Actiontec Electronics, Inc., may void the user’s authority to operate the equipment. Declaration of Conformity for Products Marked with the Industry Canada (IC)–Canada only...
-
Page 20: Technical Support
Notices Technical Support Go to www.actiontec.com/support for product support, updates, and additional information, including: • Firmware updates • Troubleshooting • Registration • FAQs Technical Support Phone Number United States: 1 (888) 436-0657...
