Page 1: Hedge Clipper
Hedge Clipper Operator's Manual MODEL WARNING Read rules for safe operation and all instructions carefully. ECHO provides this Operator's Manual and a Safety Manual. Both must be read and under- stood for proper and safe operation. X7502256602 HC-225 X750011532 03/10... -
Page 2: Table Of Contents
Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the- job dependability. Read and understand this manual. You will find it easy to use and full of helpful operating tips and SAFETY messages. -
Page 3: Safety
afety manual safety symbols and Important InformatIon Throughout this manual and on the product itself, you will find safety alerts and helpful, informational messages pre- ceded by symbols or key words. The following is an explanation of those symbols and key words and what they mean to you. -
Page 4: Personal Conditions And Safety Equipment
Gloves also reduce the transmission of machine vibration to your hands. Hearing Protection ECHO recommends wearing hearing protection whenever unit is used. Extended Operation/Extreme Conditions It is believed that a condition called Raynaud’s Phenomenon, which affects the fingers of certain individuals, may be brought about by exposure to vibration and cold. - Page 5 Repetitive Stress Injuries It is believed that overusing the muscles and tendons of the fingers, hands, arms, and shoulders may cause soreness, swelling, numbness, weakness, and extreme pain in those areas. Certain repetitive hand activities may put you at a high risk for developing a Repetitive Stress Injury (RSI).
-
Page 6: Equipment
Use only ECHO approved attachments. Serious injury may result from the use of a non-approved attachment combi- nation. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual and safety manual. -
Page 7: Description
Locate the safety decals on your unit. Make sure the decals are legible and that you understand and follow the instruc- tions on them. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDERING instructions for specific information. - Page 8 bLADEs - Double reciprocating single side blades mounted to a blade support bar. sUPPORT HANDLE WITH GUARD - FOR RIGHT HAND - Rubber non-slip grip, guard protects hand from the blades. Warning decals are located on guard. sPARK PLUG - Provides spark to ignite fuel mixture. PURGE bULb - Pumping purge bulb before starting engine draws fresh fuel from the fuel tank, purging air from the carburetor.
-
Page 9: Contents
The ECHO product you purchased has been factory pre-assembled for your convenience. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts. -
Page 10: Operation
Read and follow instructions in the Storage WARNING Alternative fuels, such as E-15 (15% ethanol), E-85 (85% ethanol) or any fuels not meeting ECHO requirements are NOT approved for use in ECHO 2-stroke gasoline engines. Use of alternative fuels may cause performance problems, loss of power, overheating, fuel vapor lock, and unintended machine operation, including, but not limited to, improper clutch engagement. -
Page 11: Handling Fuel
Handling Fuel DANGER Fuel is VERY flammable. Use extreme care when mixing, storing or handling or serious personal injury may result. • Use an approved fuel container. • DO NOT smoke near fuel. • DO NOT allow flames or sparks near fuel. •... -
Page 12: Starting Cold Engine
If blades move, readjust carburetor according to “Carburetor Ad- justment” instructions in this manual or see your ECHO Dealer. 6. Throttle Trigger After engine warm-up, grip the throttle handle with left hand and support handle with right hand. -
Page 13: Starting Warm Engine
Periodic carburetor adjustment may be necessary to as- sure blades do not move at idle. If blades move, readjust carburetor according to “Carburetor Ad- justment” instructions in this manual or see your ECHO Dealer. 1. Stop Switch Move stop switch (A) away from the STOP position. -
Page 14: Hedge Trimming
ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the ECHO Dealer do it, each maintenance task has been graded. If task is not listed, see your ECHO Dealer for repairs. -
Page 15: Skill Levels
Level 1 = Easy to do. Common tools may be required. Level 2 = Moderate difficulty. Some specialized tools may be required. ECHO offers REPOWER Maintenance Kits and Parts to make your maintenance job easier. maIntenance Intervals MAINTENANCE COMPONENT/SYSTEM... -
Page 16: Air Filter
aIr fIlter Level 1. Tools required: 25 or 50 mm (1 or 2 in.) cleaning brush Parts required: REPOWER AIR & FUEL FILTER KIT. 1. Close choke (Cold Start Position [ entering the carburetor throat when the air filter is removed. Brush accumulated dirt from air cleaner area. -
Page 17: Spark Plug
spark plug Level 2. Tools required: T-wrench, Feeler gauge, Soft metal brush Parts required: REPOWER Tune-Up Kit IMPORTANT Use only NGK BPM-8Y spark plug (BPMR-8Y in Canada) other- wise severe engine damage may occur. 1. Remove spark plug and check for fouling, worn and rounded center electrode. -
Page 18: Exhaust System
1. Remove muffler cover (A). 2. Remove starter cover (B) and clean dirt and dust from fins. IMPORTANT DO NOT use a metal scraper to remove dirt from the cylinder fins. 3. Assemble components in reverse order. exhaust system Spark Arrestor Screen Level 2. -
Page 19: Carburetor Adjustment
Periodic carburetor adjustment may be necessary to as- sure blades do not move at idle. If blades move, readjust carburetor according to these instructions, or see your ECHO Dealer Engine Break-In New engines must be operated a minimum duration of two tanks of fuel break-in before carburetor adjustments can be made. -
Page 20: High Altitude Operation
Every unit is run at the factory and the carburetor is set in compli- ance with emission regulations. Carburetor adjustments, other than idle speed, must be performed by an authorized ECHO dealer. 1. Before adjusting the carburetor, clean or replace the air filter and spark arrestor screen. -
Page 21: Lubrication
lubrIcatIon Blades Level 1. Tools required: Clean rag, 25 or 50 mm (1 or 2 in.) cleaning brush Parts required: 20W Engine Oil (lubrication), 50-50 mixture of kerosene and 20W oil (cleaning). WARNING Hedge Clipper blades are very sharp. Touching them may lead to severe personal injury. -
Page 22: Sharpening Blades
Gear Box Assembly Level 1. Tools required: Grease Gun P/N 91016, Clean rag Parts required: POWER BLENDX Base Grease 1. Clean all loose debris from gear box. 2. Remove plug (A) and check level of grease. 3. Add grease if necessary. DO NOT over-fill. sharpenIng blades Level 3. -
Page 23: Blade Adjustment
IMPORTANT Blades should only be removed and reinstalled by an Authorized ECHO Servicing Dealer, otherwise premature wear or internal damage may occur. 1. Tighten blade bolts until snug, then loosen blade bolts 1/2 turn. 2. Hold blade bolts from turning using 10 mm socket, and tighten blade lock nuts with other 10 mm socket. -
Page 24: Troubleshooting
roubleshootIng r o t i l y s t r / d r t ' n t r a e r i l i f r e t l i f r e t r o t y l r i l o r o t WARNING... -
Page 25: Storage
torage WARNING During operation the muffler or catalytic muffler and surrounding cover become hot. Always keep exhaust area clear of flammable debris during transportation or when storing, otherwise serious personal injury may result. Long Term Storage (over 30 days) Do not store your unit for a prolonged period of time (30 days or longer) without performing protective storage mainte- nance which includes the following: 1. -
Page 26: Specifications
MODEL ---------------------------------------------------- HC-225 Length ------------------------------------------------------ 1,086 mm (42.8 in.) Width -------------------------------------------------------- 251 mm (9.9 in.) Height ------------------------------------------------------- 205 mm (8.07 in.) Weight, dry ------------------------------------------------- 5.54 kg (12.2 lb.) Type of Engine --------------------------------------------- Air cooled, two-stroke, single cylinder, gasoline engine Displacement ----------------------------------------------- 21.2 cc (1.29 cu.in.) -
Page 27: Warranty Statements
The owner shall demonstrate reasonable care and use, and follow preventative maintenance, storage, fuel and oil usage as prescribed in the operator’s manual. Should a product difficulty occur, you must, at your expense, deliver or ship your ECHO unit to an authorized ECHO servicing dealer for warranty repairs (within the applicable warranty period), and arrange for pick-up or return of your unit after the repairs have been made. - Page 28 89 octane or higher. Gasohol which contains a maximum 10% ethanol (grain alcohol) or 15% MTBE (methyl/tertiary/butyl/ether) is also approved. The prescribed mixing ratio of gasoline to oil is listed on the ECHO oil label and covered in your operator’s manual.
- Page 29 HOW WILL A COVERED PART BE CORRECTED? If there is a defect in a part covered by this warranty, any ECHO Inc. Authorized Service Dealer will correct the defect. You will not have to pay anything to have the part adjusted, repaired or replaced. This includes any labor and diagnosis for warranted repairs performed by the dealer. In addition, engine parts not expressly covered under this warranty but whose failure is a result of a failure of a covered part will be warranted.
- Page 30 notes...
- Page 31 edge lipper peratOr anual notes...
-
Page 32: Servicing Information
ECHO Inc., 400 Oakwood Road, Lake Zurich, IL 60047 (800-673-1558). Always check the ECHO Web Site for updated information. safety Videos are available from your Echo dealer. A $5.00 shipping charge will be required for each video. consumer product...
