S90 & PLG150-DX
Power User Plus Pack:
DX_DRIVER
64 DX Board Voices and 64 S90 Plug-in Voices using that data
PluginAllBulk file (DXDriver.w2b): Load this file through the FILE Type that matches your PLG150-
DX board. These are PLG150-DX BOARD Voices for bank 035/000
DX SIMULATOR file (DXDriver.dxc): Open with the DX Simulator program. Within the Simulator open
"DX EDIT LIST" view to see how the Voices were made.
ALL data file (DXALLS90.w4a): Load this file through the ALL FILE type. These are S90 level PLUG-IN
Voices that point to waveforms generated on the PLG150-DX board.
VOICE EDITOR for S90 file (DriverS1.w4e); (DriverS2.w4e); (DriverS3.w4e): Open the file for your
Slot (S1, S2 or S3) with the Voice Editor for S90 or load it directly to the S90 via the VOICE EDITOR
File type. Open this file in the Editor to see how the S90 parameters were applied to the Board Voices
to make the PLG User Voices.
Advertisement
Related Manuals for Yamaha S90
Summary of Contents for Yamaha S90
- Page 1 VOICE EDITOR for S90 file (DriverS1.w4e); (DriverS2.w4e); (DriverS3.w4e): Open the file for your Slot (S1, S2 or S3) with the Voice Editor for S90 or load it directly to the S90 via the VOICE EDITOR File type. Open this file in the Editor to see how the S90 parameters were applied to the Board Voices...
- Page 2 PLG150-DX Custom User Voice data output of one operator could be applied to the The DX synth engine is based on FM or Frequency input of another to create a more complex wave Modulation (yes, the same FM that is used for shape.
- Page 3 There is an fairly perfect sawtooth waveform. If you increase excellent tutorial on-line at the Yamaha Digital the ratio of the modulator so that it is 2:1 tuning Music World site – with a number of lessons...
- Page 4 RAM bank (035/000), and the generate a complex tone. This is why an item like second is the S90 level Voices that I created to the TX-Rack became so popular at over $4,000 – show off these sounds. Remember the DX7 had it could be expanded to house eight DX7 modules no effects processor of its own (they didn’t exist...
- Page 5 On the S90 parameter side, the INSERTION EFFECTS are the AMP SIMULATOR and 10 Retro Jam: This Voice can function as a bass the TEMPO DELAY 1. (Hint: to view the S90 level or as a unique E. Piano sound programming, press the INFORMATION button...
- Page 6 26 Devastated: Brassy Ensemble sound 47 Reflection: delicate sound 27 Reborn AT: Chromatic percussion sound with pitch bend on Aftertouch. This is added in the S90 48 Turmoil: Brassy, AT Control Sets. You have two S90 level Control Sets plus MW, AT and AC (assignable controller) to 49 ZOOM: 4-note poly;...
- Page 7 58 Flash Back: Sci-fi vintage keyboard sound 59 Reticulum: Musical Effect 60 Sagitta: Musical Effect 61 Perseus: 4-note poly; Musical Effect 62 Auriga: Musical Effect 63 Libra: Musical Effect 64 Grus: Musical Effect Phil Clendeninn Senior Product Specialist Technology Products ©Yamaha Corporation of America...
