Installation guide
(Canada version)
IS7121/IS7121-2/IS7121-22
DECT 6.0 cordless telephone
with wireless doorbell
Before using this product, read this Installation guide for instructions for
installing the telephone base, handset and doorbell. For basic settings
and operation instructions, see the provided Abridged user's manual.
Basic steps to install your phone and doorbell
Basic installation
Install telephone base & charger
Install handset battery
2
Install doorbell battery
3
Install telephone base wall mount bracket
4
Doorbell installation
Doorbell location testing
5
Doorbell wall mount installation
6
Advertisement
Related Manuals for VTech IS7121
Summary of Contents for VTech IS7121
- Page 1 Installation guide (Canada version) IS7121/IS7121-2/IS7121-22 DECT 6.0 cordless telephone with wireless doorbell Before using this product, read this Installation guide for instructions for installing the telephone base, handset and doorbell. For basic settings and operation instructions, see the provided Abridged user’s manual.
-
Page 2: Install Handset Battery
Install telephone base & charger Click! Plug! DSL filter Plug! Click! Plug! If you subscribe to telephone service from a cable company or a VoIP service provider, contact your cable/VoIP service provider for more information. Install handset battery Plug! Light on! Charge for at least 30 minutes before initial settings. - Page 3 Install telephone base wall mount bracket (optional) Plug! Click! Unplug! Unplug! Slide the bracket down!
- Page 4 Doorbell battery installation BASIC INSTALLATION COMPLETED! Keep reading for doorbell location testing.
- Page 5 Doorbell location testing Before mounting the doorbell on a wall, make sure you test if the location you install the doorbell is in range, and adjust the camera angle to best suit your needs. To test the location for installation: Hold the doorbell in the location where you want to install the doorbell, then follow the steps below to test the reception range and video capture angle.
- Page 6 To adjust the shooting area, you may either relocate the doorbell in different height level, or adjust the camera angle (see the section below). To adjust the camera angle: Angle Angle Adjustment Adjustment Angle Adjustment View View View View Rotate Rotate Right Left...
- Page 7 Doorbell wall mount installation Make sure you have done Step 5 above before you mount the doorbell on the wall. Use the two holes on the doorbell wall mount to mark the desirable installation location on the wall. If you drill the holes into a stud, go to Step 3. -OR- If you drill the holes into the wall, insert the wall anchors into the holes.
- Page 8 Align the wall mount and screws with the holes in the wall (or stud). Align Use a sharp object to open a hole on the soft plastic part on the doorbell wall mount, then route the power adapter cord through the hole.
- Page 9 Metallic plate Wire with red end Wire with black end If you already have a wired doorbell installed, see Installing the doorbell with an existing wired doorbell on pages 12 to 14 to install your new IS7121 doorbell unit.
- Page 10 Push the doorbell gently onto the wall mount until they are sealed tightly. This doorbell meets the IPX4 waterproof standard. Make sure the doorbell is tightly sealed with its wall mount in order to maintain its waterproof ability. Seal tightly Push Push Tighten the screw into the threaded socket at the bottom to secure.
- Page 11 Plug the adapter into the indoor domestic power supply. Plug! DOORBELL INSTALLATION COMPLETED! Refer to the Abridged user’s manual for common settings and operations.
- Page 12 (optional) If you already have a wired doorbell installed, follow the instructions below to install your new IS7121 doorbell unit. Turn off the power supply to the existing wired doorbell. Follow Step through Step 5 in Doorbell wall mount installation on pages to .
- Page 13 Using another wire, slide one end of the metal part underneath the metallic plate on the doorbell, then connect the other end to the Trans terminal of your chime/buzzer unit of the wired doorbell. Option 1: Ring the front doorbell of the IS7121 and existing wired doorbell simultaneously. Transformer...
- Page 14 Option 2: Ring the rear doorbell of the IS7121 and existing wired doorbell simultaneously. Transformer Transformer Rear Trans Front Chime/buzzer of wired doorbell If you do not connect domestic power supply nor install AA batteries to the IS7121 doorbell, only the existing wired doorbell will ring when being pressed.
