Panasonic LUMIX DMC-FX66EB Service Manual

Digital camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DMC-FX66EB
Model No.
DMC-FX66EE
DMC-FX66EF
DMC-FX66EG
DMC-FX66EP
DMC-FX66SG
DMC-FX68GC
DMC-FX68GD
DMC-FX68GH
DMC-FX68GK
DMC-FX68GN
DMC-FX68GT
Vol. 1
Colour
[ DMC-FX66 ]
(S)...........Silver Type (except EF)
(K)...........Black Type (except SG)
(A)...........Blue Type (except EB)
(N)...........Gold Type (only SG)
(P)...........Pink Type (only SG)
(V)...........Violet Type (except EE)
[ DMC-FX68 ]
(S)...........Silver Type (only GC/GH/GK)
(K)...........Black Type
(A)...........Blue Type (only GD/GH/GT)
(N)...........Gold Type (only GC/GK)
(P)...........Pink Type (except GN)
(V)...........Violet Type (only GC/GH/GT)
© Panasonic Corporation 2010 Unauthorized copy-
ing and distribution is a violation of law.
ORDER NO. DSC1002011CE
B26
Digital Camera

Advertisement

Table of Contents
loading

Related Manuals for Panasonic LUMIX DMC-FX66EB

Summary of Contents for Panasonic LUMIX DMC-FX66EB

  • Page 1 (V)...Violet Type (except EE) [ DMC-FX68 ] (S)...Silver Type (only GC/GH/GK) (K)...Black Type (A)...Blue Type (only GD/GH/GT) (N)...Gold Type (only GC/GK) (P)...Pink Type (except GN) (V)...Violet Type (only GC/GH/GT) © Panasonic Corporation 2010 Unauthorized copy- ing and distribution is a violation of law.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE PAGE 1 Safety Precautions -----------------------------------------------3 1.1. General Guidelines ----------------------------------------3 1.2. Leakage Current Cold Check ---------------------------3 1.3. Leakage Current Hot Check (See Figure 1.)--------3 1.4. How to Discharge the Capacitor on Flash Top P.C.B.----------------------------------------------------------4 2 Warning --------------------------------------------------------------5 2.1.

  • Page 3: Safety Precautions

    1 Safety Precautions 1.1. General Guidelines 1.3. Leakage Current Hot Check 1. IMPORTANT SAFETY NOTICE (See Figure 1.) There are special components used in this equipment 1. Plug the AC cord directly into the AC outlet. Do not use which are important for safety. These parts are marked by an isolation transformer for this check.

  • Page 4: How To Discharge The Capacitor On Flash Top P.c

    1.4. How to Discharge the Capacitor on Flash Top P.C.B. CAUTION: 1. Be sure to discharge the capacitor on FLASH TOP P.C.B.. 2. Be careful of the high voltage circuit on FLASH TOP P.C.B. when servicing. [Discharging Procedure] 1. Refer to the disassemble procedure and remove the necessary parts/unit. 2.

  • Page 5: Warning

    2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. The following techniques should be used to help reduce the incidence of component damage caused by electrostatic discharge (ESD).

  • Page 6: Caution For Ac Cord(For Eb/Gc

    A replacement fuse cover can be purchased from your local 2.2.2.3. How to Replace the Fuse Panasonic Dealer. 1. Remove the Fuse Cover with a screwdriver. If the fitted moulded plug is unsuitable for the socket outlet in your home then the fuse should be removed and the plug cut off and disposed of safety.

  • Page 7: How To Replace The Lithium Battery

    NOTE: This Lithium battery is a critical component. (Type No.: ML421 Manufactured by Energy Company, Panasonic Corporation.) It must never be subjected to excessive heat or discharge. It must therefore only be fitted in requirement designed specifically for its use.

  • Page 8: Service Navigation

    3 Service Navigation 3.1. Introduction This service manual contains technical information, which allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, the information will be followed by service manual to be controlled with original service manual. 3.2.

  • Page 9: How To Define The Model Suffix (Ntsc Or Pal Model)

    3.4. How to Define the Model Suffix (NTSC or PAL model) There are eight kinds of DMC-FX66/FX68, regardless of the colours. • a) DMC-FX66 (Japan domestic model), DMC-FX66SG • b) DMC-FX66EB/EF/EG/EP • c) DMC-FX66EE • d) DMC-FX68GT • e) DMC-FX68GK •...
  • Page 10 3.4.2. INITIAL SETTINGS: After replacing the MAIN P.C.B., be sure to perform the initial settings after achieving the adjustment by ordering the following pro- cedure in accordance with model suffix of the unit. 1. IMPORTANT NOTICE: Before proceeding Initial settings, be sure to read the following CAUTIONS. 2.
  • Page 11 [CASE 1. After replacing MAIN P.C.B.] When MAIN P.C.B. has just been replaced, all of the model suffix is displayed as follows. (Five pages in total) [CASE 2. Other than “After replacing MAIN P.C.B.”] • Step 5. Choose the model suffix in “INITIAL SETTINGS”: (Refer to “CAUTION 1”) [Caution: After replacing MAIN P.C.B.] The model suffix can been chosen, JUST ONE TIME.
  • Page 12 • Step 7. CONFIRMATION: Confirm the display of “PLEASE SET THE CLOCK” in concernd language when the unit is turned on again. When the unit is connected to PC with USB cable, it is detected as removable media. 1) As for your reference, major default setting condition is as shown in the following table. •...

  • Page 13: Specifications

    4 Specifications...

  • Page 14: Location Of Controls And Components

    21 Card/Battery door 22 Release lever 23 DC coupler cover When using an AC adaptor, ensure that the Panasonic DC coupler and AC adaptor are used. We recommend you use a battery with sufficient battery power or the AC adaptor when recording motion pictures.
  • Page 15 The only batteries suitable for use with this unit are genuine Panasonic products and batteries manufactured by other companies and certified by Panasonic. (Batteries which do not support this function cannot be used). Panasonic cannot in any way guarantee the quality, performance or safety of batteries which have been manufactured by other companies and are not genuine Panasonic products.

  • Page 16: Service Mode

    6 Service Mode 6.1. Error Code Memory Function 1. General description This unit is equipped with history of error code memory function, and can be memorized 16 error codes in sequence from the latest. When the error is occurred more than 16, the oldest error is overwritten in sequence. The error code is not memorized when the power supply is shut down forcibly (i.e.,when the unit is powered on by the battery, the battery is pulled out) The error code is memorized to FLASH-ROM when the unit has just before powered off.
  • Page 17 • 3. Error Code List The error code consists of 8 bits data and it shows the following information.

  • Page 18: Ics (Indication Of Additional Camera Settings When Picture Was Taken) Function

    Important notice about "Error Code List" 1) About "*" indication: The third digit from the left is different as follows. - In case of 0 (example: 18001000) When the third digit from the left shows "0", this error occurred under the condition of INITIAL SETTINGS has been completed.
  • Page 19 3. How to read 4. How to exit: Simply, turn the power off. (Since ICS function is executed under the condition of temporary cancellation of "INITIAL SETTINGS", it wake up with normal condition when turn off the power.)

  • Page 20: Service Fixture & Tools

    7 Service Fixture & Tools 7.1. Service Fixture and Tools The following Service Fixture and tools are used for checking and servicing this unit.

  • Page 21: When Replacing The Main P.c.b

    7.2. When Replacing the Main P.C.B. After replacing the MAIN P.C.B., be sure to achieve adjustment. The adjustment instruction is available at “software download” on the “Support Information from NWBG/VDBG-AVC” web-site in “TSN system”, together with Maintenance software. 7.3. Service Position This Service Position is used for checking and replacing parts.

  • Page 22: Disassembly And Assembly Instructions

    8 Disassembly and Assembly Instructions 8.1. Disassembly Flow Chart This is a disassembling chart. When assembling, perform this chart conversely. 8.2. P.C.B. Location...

  • Page 23: Disassembly Procedure

    8.3. Disassembly Procedure 8.3.1. Removal of the Rear Case Unit Item Removal Rear Case Unit (Fig.D1) Card Battery 4 Screws (A) 2 Screws (B) Bottom Ornament (Fig.D2) 1 Lock (A) 2 Locks (B) FP9003(Flex) FP9501(Flex) Rear Case Unit LCD Unit (Fig.D3) 4 Locking tabs LCD Unit...
  • Page 24 8.3.2. Removal of the LCD Unit (Fig.D3) 8.3.3. Removal of the Front Case Unit (Fig.D2) (Fig.D4)
  • Page 25 8.3.4. Removal of the Top Operation Unit (Fig.D5) 8.3.5. Removal of the Flash Top P.C.B. and Speaker (Fig.D7) (Fig.D6)
  • Page 26 8.3.6. Removal of the Lens Unit (Fig.D9) (Fig.D8)
  • Page 27 8.3.7. Removal of the Sub Operation FPC 8.3.8. Removal of the Sub Operation FPC Unit P.C.B. (Fig.D10) (Fig.D11)
  • Page 28 8.3.10. Removal of the Battery Case (Fig.D12) 8.3.9. Removal of the Main P.C.B. (Fig.D14) 8.3.11. Removal of the Jack Door (Fig.D13) (Fig.D15)

  • Page 29: Disassembly Procedure For The Lens

    8.3.12. Removal of the Battery Door Unit 8.4. Lens Disassembly Procedure Precaution: 1. Do not remove the CCD when disassembling or re- assembling the lens in order to maintain it clean. When remove it, refer to item "8.6.". 2. Keep dust or dirt away from the lens. 3.
  • Page 30 8.4.1. Removal of the Zoom Motor and 8.4.2. Removal of the Master Flange Unit Lens FPC Unit 1. Unscrew the 3 screws (C). 2. Unscrew the 1 screw (D). 1. Remove the 18 solders (A). 3. Remove the master flange unit. 2.
  • Page 31 8.4.3. Removal of the Cam Frame Unit/ 8.4.4. Removal of the Direct Frame/1st Direct Frame/1st Lens Frame Unit/ Lens Frame Unit/2nd Lens Frame 2nd Lens Frame Move Unit Move Unit 1. Push the cam frame unit from the lens front side in the 1.
  • Page 32 8.4.5. Removal of the 1st Lens Frame 8.4.6. Removal of the 2nd Lens Frame Unit/2nd Lens Frame Move Unit Move Unit 1. Remove the convex (2 points), and then draw out the 1. Draw out 2nd lens frame move unit in the direction of shutter flex.

  • Page 33: Assembly Procedure For The Lens

    8.5. Assembly Procedure for the 8.5.2. Phase alignment of the Drive Frame Unit/Penetration Unit Lens Fixed Frame Unit 8.5.1. Phase alignment of the Drive Frame Unit and Penetration Cam Unit...
  • Page 34 8.5.3. Install of the 2nd Lens Frame Move 8.5.4. Install of the 1st Lens Frame Unit/ Unit 2nd Lens Frame Move Unit...
  • Page 35 8.5.5. Phase alignment of the Direct 8.5.6. Phase alignment of the Cam Frame Frame/1st Lens Frame Unit/2nd Unit/Direct Frame/1st Lens Frame Lens Frame Move Unit and Cam Unit/2nd Lens Frame Move Unit and Frame Unit Fixed Frame Unit/Drive Frame Unit/ Penetration Cam Unit...
  • Page 36 8.5.7. Install of the Master Flange Unit 8.5.8. Install of the Lens FPC Unit and Zoom Motor...

  • Page 37: Removal Of The Ccd Unit

    8.6. Removal of the CCD Unit 8.7. Removal of the Focus Motor To prevent the CCD unit from catching the dust and dirt, do not remove the CCD unit except for replacing.

  • Page 38: The Application Of Grease Method

    8.8. Application Grease Method The grease application parts of lens unit are as follows. Apply grease additionally in the specified position if necessary. When the grease is applied, use a toothpick and apply thinly. • Focus motor (lead screw)/Fasten groove of nut/Guide pole - Grease: RFKZ0472 - Amount of application: 2 - 4 mg •...

  • Page 39: Measurements And Adjustments

    9 Measurements and Adjustments 9.1. Introduction When servicing this unit, make sure to perform the adjustments necessary based on the part(s) replaced. Before disassembling the unit, it is recommended to back up the camera data stored in flash-rom as a data file. IMPORTANT NOTICE (After replacing the MAIN P.C.B.) After replacing the MAIN P.C.B., it is necessary to use the “DIAS”...
  • Page 40 9.2.2. Flash-Rom Data Backup When trouble occurs, it is recommended to backup the Flash-rom data before disassembling the unit. There are two kinds of Flash-rom data backup methods: [ ROM_BACKUP (Method of Non-PC backup) ] 1. Insert the SD-card into the camera. 2.

  • Page 41: Details Of Electrical Adjustment

    9.3. Details of Electrical Adjustment 9.3.1. How to execute the Electrical Adjustment It is not necessary to connect the camera to a PC to perform adjustments. “Flag reset operation” and “Initial setting operation” are required when carrying out the alignment, follow the procedure below. 9.3.1.1.
  • Page 42 9.3.1.3. Execute Adjustment (In case of “OIS Adjustment”) 1. Perform step “9.3.1.1.” to “9.3.1.2.”, to reset the OIS flag status “F” (Set) to “0” (Reset) 2. Press [ DISPLAY ] button after Flag reset. OIS Adjustment screen is displayed on the LCD panel. (Refer to Fig.3-4) 3.
  • Page 43 9.3.2. Adjustment Specifications The following matrix table shows the relation between the replaced part and the Necessary Adjustment. When a part is replaced, make sure to perform the necessary adjustment(s) in the order indicated. The table below shows all the information necessary to perform each adjustment.

  • Page 44: After Adjustment

    9.4. After Adjustment 9.4.1. Initial Setting Since the initial setting has been released to execute the built-in adjustment software, it should be set up again before shipping the camera to the customer. Refer to the procedure described in “3.4.2. INITIAL SETTINGS” for details. [ IMPORTANT ] 1.

  • Page 45: Maintenance

    10 Maintenance 10.1. Cleaning Lens and LCD Panel Do not touch the surface of lens and LCD Panel with your hand. When cleaning the lens, use air-Blower to blow off the dust. When cleaning the LCD Panel, dampen the lens cleaning paper with lens cleaner, and the gently wipe the its surface. Note: The Lens Cleaning KIT ;...
  • Page 46 DSC1002011CE S1. About Indication of The Schematic Diagram Service Manual S1.1. Important Safety Notice COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL CHARACTERISTICS Diagrams and Replacement FOR SAFETY. WHEN REPLACING ANY OF THESE COMPONENTS USE ONLY THE SAME TYPE. 1.Although reference number of the parts is indicated on the P.C.B. drawing and/or Parts List schematic diagrams, it is NOT mounted on the P.C.B.

  • Page 47: S2. Voltage Chart

    S2. Voltage Chart Note) Indicated voltage values are the standard values for the unit measured by the DC electronic circuit tester (high-impedance) with the chassis taken as standard. Therefore, there may exist some errors in the voltage values, depending on the internal impedance of the DC circuit tester. S2.1.

  • Page 48: S3. Block Diagram

    S3. Block Diagram S3.1. Overall Block Diagram (25mm ~ 125mm) IC3001 CCD SIGNAL PROCESSOR X6001 (24MHz) 1/2.33" 14 MEGA PIX CDS, AGC, A/D, TG, CCD DRIVER ZOOM OIS UNIT IRIS SHUTTER FOCUS CARD IC3002,3003 REGULATOR MICROPHONE IC9101 SYSTEM IC IC9101 SYSTEM IC SPEAKER MOTOR DRIVE,...

  • Page 49: S4. Schematic Diagram

    S4. Schematic Diagram S4.1. Interconnection Diagram PS8001 ET8001 FLASH TOP P.C.B. M8001 (COMPONENT SIDE) MICROPHONE P8002 : (FOIL SIDE) ET8002 LCD UNIT BATTERY SPEAKER FP9003 FP9001 CCD POWER CCD THERMO SUBSW1 V11A VDOMH V13R VDOML V13L IDVCC V12L TEST OUT V12R SUB OPERATION FPC (FOIL SIDE)

  • Page 50: S4.2. Sub Operation Schematic Diagram

    S4.2. Sub Operation Schematic Diagram PLAY <==> REC K0D112B00145 S9501 FRAME_GND REC_PLAY_SW R9501 FT9501 TO MAIN BOARD BL_MINUS RIGHT RIGHT BL_PLUS VREF_Y VREF_Y K1MN04BA0162 G_GYRO_Y G_GYRO_Y FP9501 GYRO_GND TO BACKLIGHT GYRO_GND DOWN DOWN PW_GY3R1V PW_GY3R1V DELETE DELETE DISPLAY DISPLAY MENU MENU LEFT LEFT...

  • Page 51: S4.3. Flash Top Schematic Diagram

    S4.3. Flash Top Schematic Diagram CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH THE SAME TYPE 1.5A 32V FUSE. GYRO_X(YAW) ATTENTION: POUR UNE PROTECTION CONTINUE LES RISQUES 1.5A 32V D' INCENDIE N' UTILISERQUE DES FUSIBLE DE MÉME TYPE 1.5A 32V. C7302 N.C.

  • Page 52: S4.4. Ccd Flex Schematic Diagram

    S4.4. CCD Flex Schematic Diagram FT3101 CON_CHK CCD_GND CCD_GND 31 30 CCD_GND SUBSW2 SUBSW2 V11B MSUBSW MSUB MSUB MSUBSW MSUBSW V11B [29] MSUBSW CCD_GND [29] CCD_GND IC3101 R3107 CCD_OUT MN34571PBH-V 1300 CCD_GND [10] [20] SUBSW2 SUBSW1 SUBSW1 SUBSW2 R3101 12 13 14 15 V4 V4 R3108...

  • Page 53: S4.5. Lens Flex Schematic Diagram

    S4.5. Lens Flex Schematic Diagram POSITIVE VOLTAGE LINE YHI+ YDR+ DRIVE COIL (Y) OIS UNIT YDR- IRA- IRA+ IRA+ DC SOLENOID IRB- (IRIS) IRB- IRB+ SHUTTER UNIT IRB+ DC SOLENOID (SHUTTER) XDR- XDR- XHO+ DRIVE COIL (X) XDR+ XHI- HALL SENSOR (X) XHO- TO MAIN OIS UNIT...

  • Page 54: S5. Print Circuit Board

    S5. Print Circuit Board S5.1. Sub Operation Flex P.C.B. IC9701 (Foil Side) DMC-FX66/FX68 Sub Operation Flex P.C.B.

  • Page 55: S5.2. Flash Top P.c.b

    S5.2. Flash Top P.C.B. R8011 CL8011 CL8005 CL7304 CL8008 C8001 F8021 CL8001 CL8006 CL7301 CL8003 Q8001 CL8004 L8001 RL8003 CL8202 CL8010 CL8201 TL8007 D8001 RL8001 (Component Side) VA8001 ET8003 C8014 RL8002 S8002 CL8002 ET8004 TL8004 ET8005 CL7303 CL7302 (Foil Side) DMC-FX66/FX68 Flash Top P.C.B.

  • Page 56: S5.3. Ccd Flex P.c.b

    S5.3. CCD Flex P.C.B. (Component Side) C3101 R3107 R3102 IC3101 (Foil Side) DMC-FX66/FX68 CCD Flex P.C.B. S-11...

  • Page 57: S5.4. Lens Flex P.c.b

    S5.4. Lens Flex P.C.B. ZOOM MOTOR UNIT SHUTTER UNIT CO. BARREL ENCODER (FULL RETRACT) Pin 1 OIS UNIT ZOOM ENCODER 2 ZOOM ENCODER 1 Pin 45 FOCUS MOTOR UNIT DMC-FX66/FX68 LENS FLEX P.C.B. S-12...

  • Page 58: S6. Replacement Parts List

    ELECTROSTATIC DISCHARGE (ESD) TO ELECTROSTATICALLY SENSITIVE (ES) DEVICES section. Definition of Parts supplier: 1. Parts marked with [ENERGY] in the remarks column are supplied from Panasonic Corporation Energy Company. 2. Parts marked with [PAVCSG] in the remarks column are supplied from PAVCSG.
  • Page 59 DMC-FX66/ FX68 series vol.1 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R8038 ERJ3GEYJ100V M.RESISTOR CH 1/10W 10 1 [PAVCSG] VEP59078A SUB OPERATION FPC UNIT 1 (RTL) E.S.D. VEP58108A FLASH TOP P.C.B. 1 (RTL) E.S.D.[PAVCSG] S8001 K0F212A00003...
  • Page 60 DMC-FX66/ FX68 series vol.1 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks 108-2 VMB4308 FOCUS SPRING ML-421S/ZTK SMALL SECONDARY BATTERIES 1 [Energy] 108-3 VXP3298 3RD LENS FRAME UNIT VEP56099A MAIN P.C.B. 1 (RTL) E.S.D. VGQ0M00 BATTERY LOCK KNOB VHD2019...
  • Page 61 DMC-FX66/ FX68 series vol.1 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VPK4273 PACKING CASE 1 EB-S,EE-S,EG-S,EP-S,SG-S VPF1317 CAMERA BAG VPK4276 PACKING CASE 1 EB-K,EE-K,EF-K,EG-K,EP-K DE-A60AA BATTERY CHARGER 1 EB,EF,EG,EP,GN VPK4284 PACKING CASE 1 EB-V,EF-V,EG-V,EP-V,SG-V DE-A60BB BATTERY CHARGER...

  • Page 62: S7. Exploded View

    S7. Exploded View S7.1. Frame and Casing Section 51-2 51-1 20-1 B101 B102 B103 B104 B109 104-1 B107 B108 104-3 108-3 70-1 104-2 B110 B105 B111 B106 70-2 108-2 108-1 S-17...

  • Page 63: S7.2. Packing Parts And Accessories Section

    S7.2. Packing Parts and Accessories Section (DMC-FX66EE/EF/EG/EP DMC-FX68GC/GD) (DMC-FX66EB DMC-FX68GC/GH) (DMC-FX68GK/GT) (DMC-FX68GN) S-18...
