La Crosse Technology WS-1025U Quick Start Manual

O U TD OOR
W INDOW T HE RM OME T ER
MODEL: WS-1025U
DC: 110920
For more product information visit: bit.ly/laxtech_support
POW ER U P
1. Grasp both ends of the Mounting Bracket and detach it from the
Window Thermometer.
2. Use a screwdriver to open the Battery Cover and remove the
plastic tab from under the AAA battery. Thermometer should
turn on.
3. Replace Battery Cover and set the time. This will help ensure
your MIN/MAX values reset correctly.
4. Follow the mounting steps under POSITIONING for best results.
Mounting Bracket
Adhesive
Strips for
Window
Mounting
Battery Cover
1-AAA
(included)
Current
Temperature
(Fahrenheit only)
Page 2
SE T T I M E
1. Hold the MODE button to enter the Settings Menu.
2. Use the + button to adjust, and MODE to confirm.
Settings Menu order:
• Hour
• Minutes
P O SI T I O N I N G
1. Select a location where the Window Thermometer will be out of
Leg
direct sunlight for accurate readings.
2. Clean your window and remove the Adhesive Strip covers from
the Mounting Bracket.
Slot for
3. Firmly press the bracket onto your window surface, holding the
Leg
Adhesive Strips down for a good 30 seconds.
Buttons
4. Reattach the Window Thermometer onto the Mounting Bracket.
5. For improved visibility, UV, and rain protection, slide the
included plastic plate onto the back of the thermometer.
Maximum
Temperature
Resets at 8AM
M I N / M A X T E M PE R AT UR E
• The minimum temperature automatically resets at 8:00 P.M.
• The maximum temperature automatically resets at 8:00 A.M.
Note: Time needs to be setcorrectly for accurate minimum and
Minimum
maximum temperatures over the past 24 hours.
Temperature
Resets at 8PM
Page 3
