Smeg Universale PL65233XIN User Instructions

Hide thumbs

Advertisement

Quick Links

Download this manual
Contents
1.
Description of the controls _______________________________ 2
2.
Operating instructions __________________________________ 10
3.
Cleaning and maintenance ______________________________ 27
4.
Troubleshooting ______________________________________ 33
Thank you for choosing one of our products.
You are advised to read this manual carefully; it contains all the
information you need to use your dishwasher safely, correctly and in the
most satisfactory manner.
Following the cleaning instructions provided here will keep your
dishwasher's performance at peak levels in the long term.
USER INSTRUCTIONS: these consist of recommendations for using the
appliance, a description of its controls and of the correct cleaning and
maintenance procedures.
1

Advertisement

loading

Related Manuals for Smeg Universale PL65233XIN

Summary of Contents for Smeg Universale PL65233XIN

  • Page 1 Contents Description of the controls _______________________________ 2 Operating instructions __________________________________ 10 Cleaning and maintenance ______________________________ 27 Troubleshooting ______________________________________ 33 Thank you for choosing one of our products. You are advised to read this manual carefully; it contains all the information you need to use your dishwasher safely, correctly and in the most satisfactory manner.

  • Page 2: Description Of The Controls

    User instructions 1. Description of the controls Front panel All the dishwasher controls are grouped on the front panel. Programming and option selection are only possible with the door closed. ON/OFF BUTTON AND WARNING LIGHT OPTION SELECTION BUTTONS AND WARNING LIGHTS “CHILD LOCK”...
  • Page 3 User instructions PROGRAMS TABLE DURATION CONSUMPTION PROGRAMME LOAD CROCKERY AND PROGRAM NUMBER CUTLERY PROGRESS MINUTES WATER POWER & SYMBOL LITRES KWh (1) 1 SOAK Recommended for rinsing 0,02 dishes while waiting for Cold prewash another wash cycle. Recommended if you 2 ½...
  • Page 4 User instructions NOTES AND REFERENCES Only run the soak program with half loads. Options cannot be used with the soak program. Standard programme under EN 50242. See information sheet provided IEC/DIN reference programme. **** Reference program for laboratories: Detergent: 20g in the dispenser + 10g in the door or tablet.
  • Page 5 User instructions Washing programs The dishwasher is equipped with a control panel and an INFORMATION DISPLAY from which it is possible to carry out all the power switch-on, switch-off and programming operations. Before starting a washing program make sure that: ...
  • Page 6 User instructions DRY ASSIST If there is a “D” in the “DURATION” column of the programs table, the door opens automatically at the end of the cycle. This allows the dishes to be dried perfectly even at low rinse temperatures, and therefore significant energy savings.
  • Page 7 User instructions CHANGING A PROGRAM To change the running program it is necessary:  to interrupt the running program (see “I ”); NTERRUPTION A PROGRAM  select the new program;  start the program (see “S ”). TARTING THE PROGRAM ANNULLING A PROGRAM To annul the program, keep the START/PAUSE button (7) pressed until the program is interrupted (light on and confirmation beep).
  • Page 8 User instructions OPTION SELECTION Options are selected by pressing the relative button by the symbol of the option required; the light comes on to confirm that the option has been activated.  It is not possible to select any options when the soak program is being used.
  • Page 9 User instructions TO SAVE ON ENERGY! … AND PROTECT THE ENVIRONMENT  Always try to run the dishwasher fully loaded.  Do not wash the dishes in running water.  Use the washing program that is most appropriate for each type of load.

  • Page 10: Operating Instructions

    User instructions 2. Operating instructions Once the dishwasher has been correctly installed, prepare for use as follows:  Adjust the water softening system;  Add the regenerating salt;  Add the rinse aid and detergent. Using the water softening system The amount of scale contained in the water (water hardness index) can cause whitish staining on the dry dishes, which tend to...
  • Page 11 User instructions  Do not use table salt as it contains insoluble substances which, over time, may damage the water softening system.  When necessary, refill the regenerating salt container before starting the washing program. In this way, the excess saline solution will be immediately removed by the water;...
  • Page 12 User instructions WATER HARDNESS TABLE WATER HARDNESS SETTINGS German French degrees (°dH) degrees (°dH) All lights off 0 – 6 0 – 11 (no salt) 7 – 10 12 – 18 One light on 11 – 15 19 – 27 Two lights on 16 –...
  • Page 13 User instructions ADDING THE RINSE AID The rinse aid helps the dishes dry faster and prevents the formation of scale deposits and staining; it is automatically added to the water during the final rinse cycle, from the container situated on the inner side of the door. To add rinse aid: ...
  • Page 14 User instructions ADJUSTING THE RINSE AID DISPENSER MODE Press and hold the PROGRAM SELECTION (6) button, after approximately 15 seconds the salt light flashes, keep it pressed until the rinse aid light (4) flashes and the program indicator lights (8) indicate the current setting.
  • Page 15 User instructions ADDING THE DETERGENT To open the detergent dispenser cover, lightly press button P. Add the detergent or tablet and close the cover by sliding it until it stops, indicated by a click. The dispenser will open automatically during the wash cycle. Only add the detergent (also in tablet form) if the dispenser is dry ...
  • Page 16 User instructions The introduction of detergent into the rinse aid dispenser, even in liquid form, will damage the dishwasher. General warnings and recommendations Before using the dishwasher for the first time, it is advisable to read the following recommendations concerning dish types to be washed and their loading.
  • Page 17 User instructions WARNING!  Make sure that the dishes are securely in place so that they cannot tip over or obstruct the rotation of the spray arms during the washing cycle.  Do not place very small objects in the baskets as these could fall and obstruct the spray arms or the wash pump.
  • Page 18 User instructions Using the baskets The dishwasher has a capacity of 13 place-settings, including serving dishes. LOWER BASKET The lower basket receives the full force of the lower spray arm, and should therefore be used for the “toughest” items with a heavier degree of soiling. All types and combinations of loads are permitted, provided that the dishes, pots and pans are arranged with all the soiled surfaces...
  • Page 19 User instructions LOADING THE LOWER BASKET Carefully load flat plates, soup plates, dessert and serving dishes, positioning them vertically. Pots, pans and their covers must be loaded upside down. When loading soup plates and dessert bowls, be sure to leave a gap between them. Loading examples: UPPER BASKET The upper basket should be loaded with small or medium-sized items...
  • Page 20 User instructions CUTLERY BASKET The basket is suitable for all types of cutlery, except long items that may interfere with the upper spray arm. The cutlery should be arranged in the spaces in the upper racks to allow the water to pass effectively between the items.
  • Page 21 User instructions TOP CUTLERY BASKET (on some models only) The basket is designed to take cutlery, placed in the spaces provided, long utensils, positioned lengthwise and small items. The “drawer” extraction system makes the basket easier to load, but it can also be taken completely off its runners by removing the retainers (as shown here).
  • Page 22 User instructions EXAMPLES OF LOADING FOR INTENSIVE DIRT 13 Standard place setting If the bottom basket inserts are of the fold-down type, they should be laid flat for easier loading. 13 Standard place setting TOP RACK (on some models only) If the bottom basket inserts are of the fold-down type, they should be laid flat for easier loading.
  • Page 23 User instructions UPPER BASKET EQUIPMENT (depending on the model) Cutlery tray For knives, spoons (tea and dessert) and long objects. The ends are designed to hold long stemmed glasses. - It can be removed by pressing and pushing the release levers (B) at the same time.
  • Page 24 User instructions Fold-down shelves For mugs, cups and long objects. The ends are designed to hold long stemmed glasses When not used they can be moved to a vertical position (until a click is heard). Shelves with expandable wings For small objects, mugs and cups. They can be used either closed or open (pull the upper, sliding part).
  • Page 25 User instructions Fold-down tines These can be secured in a vertical position, resting on the bottom of the basket if unused, or placed in an intermediate position, as required. The single tine on the right is ideal for supporting long stemmed glasses.
  • Page 26 User instructions ADJUSTING THE UPPER BASKET The height of the top basket can be adjusted to allow large dishes or pans to be placed in the bottom basket. The adjustment procedure may be type A or B, depending on the dishwasher model purchased.

  • Page 27: Cleaning And Maintenance

    User instructions 3. Cleaning and maintenance Before carrying out any work, always unplug the appliance from the electrical supply or switch off the all-pole disconnection device. General warnings and recommendations Avoid the use of acidic or abrasive detergents. Clean the outer surfaces and door-lining of the dishwasher regularly using a soft cloth moistened with water or with a normal detergent suitable for painted surfaces.
  • Page 28 User instructions CLEANING THE FILTER UNIT  It is advisable to periodically inspect the centre filter C and, if necessary, to clean it. To remove the filter, grip the tabs, turn anticlockwise and lift upwards;  push the centre filter D from the underside to remove it from the micro- filter: ...
  • Page 29 User instructions BEFORE STARTING THE DISHWASHER AFTER PROLONGED DISUSE:  Check that there are no deposits of sludge or rust inside the water pipe: if there are, allow the water to run from the water supply tap for a few minutes. ...
  • Page 30 User instructions If the dishes fail to dry or remain dull, check that:  there is rinse aid inside the special container;  the rinse aid dispenser setting is correct;  the detergent used is of good quality and has not lost its effectiveness (for example, through incorrect storage, with the box left open).
  • Page 31 User instructions If the door does not close: 1 - Check the position of the door lock catch (D) 2 - If necessary, raise it by adjusting the plastic screw (V) next to the catch. 3 - Check the condition of the lock hook (G); if it has not triggered (reference N), the door opens and closes normally.
  • Page 32 User instructions If after following the above troubleshooting instructions the problem persists, call the nearest After-Sales Centre. WARNING: any operations performed on the appliance by unauthorised persons are not covered by the warranty and shall be paid for by the user.

  • Page 33: Troubleshooting

    User instructions 4. Troubleshooting The dishwasher is equipped with a self-diagnostics system that is capable of detecting and signalling a number of possible faults. FAULT DESCRIPTION Acquastop failure The anti-flooding system has been activated (for the relevant models only). The system is tripped in case of water leaks.
  • Page 34 User instructions FAULT DESCRIPTION Turbine flow-regulator malfunction (for the relevant models only) The appliance is not able to "measure" the amount of water loaded accurately. Interrupt the program and switch off the dishwasher. Switch the dishwasher back on, program it again and start the washing cycle.
