GE 25836EE1 User Manual

Model 25836
• If your home has specially wired alarm equipment connected to the telephone
line, ensure the installation of this product does not disable your alarm
equipment. If you have questions about what will disable alarm equipment,
5.8 GHz Cordless
consult your telephone company or a qualified installer.
US Number is located on the back of the cabinet.
Handset User's Guide
REN Number is located on the back of the cabinet.
2 Rights of the Telephone Company
Should your equipment cause trouble on y our line which may harm the telephone
network, the telephone company shall, where practicable, notify you that
temporary discontinuance of service may be required. Where prior notice is not
practicable and the circumstances warrant such action, the telephone company
may temporarily discontinue service immediately. In case of such temporary
discontinuance, the telephone company must: (1) promptly notify you of such
temporary discontinuance; (2) afford you the opportunity to correct the situation;
and (3) inform you of your right to bring a complaint to the Commission pursuant to
procedures set forth in Subpart E of Part 68, FCC Rules and Regulations.
The telephone company may make changes in its communications facilities,
equipment, operations or procedures where such action is required in the
operation of its business and not inconsistent with FCC Rules and Regulations. If
these changes are expected to affect the use or performance of your telephone
equipment, the telephone company must give you adequate notice, in writing, to
allow you to maintain uninterrupted service.
Interference Information
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference; and (2)
This device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
Privacy of Communications may not be ensured when using this product.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna (that is, the antenna for radio or
Equipment Approval Information
television that is "receiving" the interference).
• Reorient or relocate and increase the separation between the
Your telephone equipment is approved for connection to the Public Switched
telecommunications equipment and receiving antenna.
Telephone Network and is in compliance with parts 15 and 68, FCC Rules and
• Connect the telecommunications equipment into an outlet on a circuit different
Regulations and the Technical Requirements for Telephone Terminal Equipment
from that to which the receiving antenna is connected.
published by ACTA.
If these measures do not eliminate the interference, please consult your dealer or an
1 Notification to the Local Telephone Company
experienced radio/television technician for additional suggestions. Also, the Federal
On the bottom of this equipment is a label indicating, among other information, the
Communications Commission has prepared a helpful booklet, "How To Identify and
US number and Ringer Equivalence Number (REN) for the equipment. You must,
Resolve Radio/TV Interference Problems." This booklet is available from the U.S.
upon request, provide this information to your telephone company.
Government Printing Office, Washington, D.C. 20402. Please specify stock number
The REN is useful in determining the number of devices you may connect to your
004-000-00345-4 when ordering copies.
telephone line and still have all of these devices ring when your telephone number
Notice: The changes or modifications not expressly approved by the party responsible
is called. In most (but not all) areas, the sum of the RENs of all devices connected
for compliance could void the user's authority to operate the equipment.
to one line should not exceed 5. To be certain of the number of devices you may
Hearing Aid Compatibility (HAC)
connect to your line as determined by the REN, you should contact your local
telephone company.
This telephone system meets FCC standards for Hearing Aid Compatibility.
A plug and jack used to connect this equipment to the premises wiring and
Licensing
telephone network must comply with the applicable FCC Part 68 rules and
requirements adopted by the ACTA. A compliant telephone cord and modular
plug is provided with this product. It is designed to be connected to a compatible Licensed under US Patent 6,427,009.
modular jack that is also compliant. See installation instructions for details. FCC RF Radiation Exposure
Notes
Statement
• This equipment may not be used on coin service provided by the telephone
company.
This equipment complies with FCC RF radiation exposure limits set forth for an
• Party lines are subject to state tariffs, and therefore, you may not be able to use
uncontrolled environment. This equipment should be installed and operated with
your own telephone equipment if you are on a party line. Check with your local
a minimum distance of 20 centimeters between the radiator and your body. This
telephone company.
transmitter must not be co-located or operated in conjunction with any other antenna
• Notice must be given to the telephone company upon permanent disconnection
or transmitter."
of your telephone from your line.
THE LIGHTNING CAUTION: TO REDUCE THE
FLASH AND ARROW RISK OF ELECTRIC SHOCK, DO
WARNING: TO
Thomson Inc. HEAD WITHIN THE NOT REMOVE COVER (OR
PREVENT FIRE OR BACK). NO USER
TRIANGLE IS A
10330 North Meridian Street
ELECTRICAL SHOCK WARNING SIGN SERVICEABLE PARTS INSIDE.
ALERTING YOU OF REFER SERVICING TO
Indianapolis, IN 46290
Model 25836 HAZARD, DO NOT "DANGEROUS QUALIFIED SERVICE
© 2006 Thomson Inc. EXPOSE THIS VOLTAGE" INSIDE PERSONNEL.
00008024 (Rev. 1 Dom E)
THE PRODUCT.
06-28 Trademark(s) ® Registered PRODUCT TO RAIN
SEE MARKING ON BOTTOM / BACK OF PRODUCT
Printed in China Marca(s) Registrada(s) OR MOISTURE.
Introduction Important Installation Guidelines
CAUTION: When using telephone equipment, there • Avoid sources of noise and heat, such as motors, fluorescent lighting,
are basic safety instructions that should always
be followed. Refer to the IMPORTANT SAFETY • Avoid areas of excessive dust, moisture and low temperature.
INSTRUCTIONS provided with this product and save
• Avoid other cordless telephones or personal computers.
them for future reference.
• Never install telephone wiring during a lightning storm.
IMPORTANT: Because cordless phones operate on electricity,
• Never install telephone jacks in wet locations unless the jack is
you should have at least one phone in your home that isn't
cordless, in case the power in your home goes out.
• Never touch non-insulated telephone wires or terminals, unless the
Before You Begin
• Use caution when installing or modifying telephone lines.
Parts Checklist
Handset Layout
Make sure your package includes the items shown here.
Battery
compartment
door
talk/end/call back
Base Handset
(caller ID/volume down
Handset AC power
battery Line cord adaptor
Telephone Jack Requirements
Wall plate (delete/channel
To use this phone, you need an RJ11C type modular
telephone jack, which might look like the one pictured
here, installed in your home. If you don't have a Modular
modular jack, call your local phone company to find telephone
out how to get one installed. line jack
Installation
Digital Security System
Your cordless phone uses a digital security system to protect against false
ringing, unauthorized access, and charges to your phone line.
When you place the handset in the base, the unit verifies its security code.
After power outage or battery replacement, you should place the handset in
Base Layout
the base for about 20 seconds to reset the code.
INSTALLATION NOTE: Some cordless telephones operate
at frequencies that may cause or receive interference
with TVs, microwave ovens, and VCRs. To minimize or
prevent such interference, the base of the cordless
telephone should not be placed near or on top of a TV,
microwave ovens, or VCR. If such interference continues,
move the cordless telephone farther away from these
appliances. Certain other communications devices may
also use the 5.8 GHz frequency for communication, and,
if not properly set, these devices may interfere with each
other and/or your new telephone. If you are concerned
with interference, please refer to the User's Guide for
these devices on how to properly set channels to avoid
CAUTION:
interference. Typical devices that may use the 5.8 GHz
RISK OF ELECTRIC SHOCK
DO NOT OPEN
frequency for communication include wireless audio/video
THE EXCLAMATION
senders, wireless computer networks, multi-handset
POINT WITHIN THE
TRIANGLE IS A
cordless telephone systems, and some long-range cordless
WARNING SIGN
ALERTING YOU OF telephone systems.
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
Installing the Phone
Installing the Handset Battery
microwave ovens, heating appliances and direct sunlight.
NOTE: You must connect the handset battery before use.
CAUTION: To reduce the risk of fire or personal injury,
use only the Thomson Inc. approved Nickel-Cadmium
(Ni-Cd) battery model 5-2459 that is compatible with
this unit.
specifically designed for wet locations.
1. Locate battery and battery door which are packaged together inside a
plastic bag and are separate from the handset.
telephone line has been disconnected at the network interface.
2. Locate the battery compartment on the back of the handset.
3. Plug the battery pack cord into the jack inside the compartment.
NOTE: To ensure proper battery installation, the connector
is keyed and can be inserted only one way.
battery
pack
display
PRESS DOWN
FIRMLY
black wire
4. Insert the battery pack.
(button)
5. Close the battery compartment by pushing the door up until it snaps into
place.
Caller ID/vol +
(caller ID/volume
6. Set the RINGER switch (on the handset) to ON.
Caller ID/vol -
up button)
Base Station
button)
1. Choose an area near an electrical outlet and a telephone wall jack
format
(RJ11C), and place your cordless telephone on a level surface, such as a
(button)
desktop or tabletop, or you may mount it on the wall.
redial
(button)
del/chan mute
(button)
button)
flash/prog
mem
(flash/program
(memory button)
button)
# pause
* exit
(button)
(button)
2. Plug one end of the telephone line cord into the TEL LINE jack on the
bottom of the base and the other end into a modular jack.
3. Plug the AC power converter into the electrical outlet and the DC
connector into the jack on the bottom of the base.
4. Place the handset in the base cradle. The charge/in use indicator turns
on, verifying the battery is charging .
charge/in use 5. Allow the phone to charge for 16 hours prior to first use. If you don't
page
(indicator) properly charge the phone, battery performance is compromised.
(button)
CAUTION: Use only the 5-2677 (black) or 5-2728 (gray)
power adaptor that came with this unit. Using other
power adaptors may damage the unit.
NOTE : The phone is tone dial only and does not support pulse
dial mode.
Wall Mounting
1. Slip the mounting holes (on the back of the base) over the wall plate posts,
and slide the unit down into place. (Wall plate not included.)
2. Place the handset on the base cradle.
Set Up 4. When finished, press the talk/end/call back button again to hang up.
NOTE : You may enter up to 32 pre-dial digits.
There are four programmable menus available: Language, Area Code, Ringer
Redial
Tone, and Default Setting.
During programming, you may press the flash/prog button at any time to go
While the phone is ON (in TALK mode), press the redial button to redial the
to the next option. To exit the menu, keep the previous setting and return to
last number you dialed (up to 32 digits).
the standby mode, press the *exit button.
- OR -
Display Language
While the phone is OFF (in standby mode), press the redial button and then
the talk/end/call back button to redial the last number.
1. Press the flash/prog button until 41ENG 2FRA 3ESP shows in the display.
1ENG is the default.
Flash
2. Use the Caller ID/vol (- or +) button or the touch-tone pad on the handset
Use the flash/prog button to activate custom calling services such as call
to enter your selection.
waiting, which are available through your local phone company.
3. Press flash/prog again to save.
TIP: Don't use the talk/end/call back button to activate
Local Area Code
custom calling services such as call waiting, or you'll hang
up the phone.
1. Press the flash/prog button until AREA CODE - - - shows in the display.
Channel Button
- - - is the default.
red wire
2. Use the touch-tone pad on the handset to enter your three digit area
While talking on the phone, it may be necessary for you to manually change
code.
the channel to improve reception and reduce noise or static on the line.
3. Press flash/prog again to save. Press and release the del/chan button to move to the next clear channel.
NOTE: If you make a mistake, press the del/chan button to
Exit
erase a wrong number.
Press the *exit button to cancel any command you initiated.
Ringer Tone
Finding the Handset
1. Press the flash/prog button until RINGER TONE 41 shows in the display.
1 is the default. This feature helps locate a misplaced handset.
2. Use the Caller ID/vol (- or +) button or the touch-tone pad on the handset Press the page button on the base. The handset beeps continuously for
to scroll to 1, 2, or 3. about 2 minutes until you press the talk/end/call back button on the handset
or the page button on the base.
3. Press flash/prog to save.
NOTE: You may still page the handset when the ringer is off.
Default Setting
Ringer Switch
1. Press the flash/prog button until DEFAULT 4NO shows in the display.
NO is the default. The ringer switch is located on the side of the handset, it has two positions, On
and Off.
2. Use the Caller ID/vol (- or +) button on the handset to scroll
to YES or NO.
Volume
3. Press flash/prog to save. You will hear a confirmation tone.
When the phone is ON (in TALK mode) press the Caller ID/vol (- or +) button
Cordless Phone Basics
to adjust the listening level. Choose from four volume settings. VOL 1 is the
lowest volume and VOL 4 is the highest volume.
Charge/In Use Indicator
Mute
The phone is ON when the charge/in use indicator on the base is lit. The
Use mute during a phone conversation to speak privately and off-line with a
base indicator flashes when you receive a call.
third party.
Answering a Call
1. Press the mute button. MUTE shows in the display. The party on the
telephone will not hear you.
1. When the phone rings, pick up the handset and press the talk/end/call back
button. 2. Press the mute button when finished.
Caller ID (CID)
2. When finished, press the talk/end/call back button or place the handset
on the base cradle to hang up.
IMPORTANT: In order to use this unit's Caller ID features,
Making a Call
you must subscribe to either the standard Name/Number
Caller ID Service or Call Waiting Caller ID Service. To
1. Pick up the handset and press the talk/end/call back button. Wait for
know who is calling while you are on the phone, you must
the dial tone. The call timer starts counting minutes and seconds in the
subscribe to Call Waiting Caller ID Service.
display.
This unit receives and displays information transmitted by your local phone
2. Dial a telephone number.
company. This information can include the phone number, date, and time; or
3. When finished, press the talk/end/call back button again or place the
the name, phone number, date, and time.
handset on the base cradle to hang up.
Pre-dialing
1. Make sure the phone is OFF (not in TALK mode).
2. Dial a telephone number (the number you dial shows in the display).
NOTE: If you make a mistake dialing the number, use
the del/chan button to backspace and erase the wrong
number, and enter the correct number.
3. Press the talk/end/call back button on the handset. The number
Caller ID phone number
automatically dials and the call timer starts counting the minutes and
seconds in the display.
Call Waiting Caller ID
Provided you subscribe to Call Waiting Caller ID service from your phone
company; if you receive an incoming call and you are already on the phone,
a beep indicates the presence of a Call Waiting call on the line. Only the
handset that is in use at the time of the call will display and store the Call
Waiting Caller ID information.
• When you hear the call waiting beep in the handset receiver, press the
flash/prog button to put the current call on hold and answer the incoming
call. Press flash/prog again to return to the original call.
Receiving CID Records
When you receive a call, the Caller ID information is transmitted between the
first and second ring. The Caller ID information appears on the display while
the phone rings, giving you a chance to monitor the information and decide
whether or not to answer the call.
Storing CID Records (In CID Memory)
If you are not at home or cannot answer, your telephone's Caller ID memory
stores the data for the 40 most recent calls you received so you can see who
called while you were unavailable. When the 41st call is received, the oldest
Caller ID record (1st call) is automatically deleted.
You may review the stored information at any time. Calls received since your
last review show as NEW in the display. Calls that have not been previously
reviewed but were received from the same number more than once show as
REPT in the display.
Reviewing CID Records
As calls are received and stored, the display is updated to let you know how
many calls have been received.
• Press the Caller ID/vol (-) to scroll through the call records from the most
recent to the oldest.
• Press the Caller ID/vol (+) to scroll through the call records from the oldest
to the newest.
Dialing a Caller ID Number
1. Make sure the phone is OFF (not in TALK mode).
2. Use the Caller ID/vol (- or +) button to display the desired record.
3. Press talk/end/call back. The number dials automatically.
NOTE: Depending on (a) how the incoming caller's phone
number is formatted when it is received, and (b) whether
or not you previously pre-programmed your local area
code into the set up menu, you may need to adjust the
format of the incoming caller's stored phone number
before making the call, press the format button to adjust
the number, and try again
Available formats include:
Number of digits Explanation
Eleven digits long distance code "1 " 1-317-888-8888
+3-digit area code
+7-digit telephone number.
Ten digits 3-digit area code + 317-888-8888
7-digit telephone number.
Seven digits 7-digit telephone number. 888-8888
Storing CID Records in Internal Memory
You may also store CID information in the phone's internal memory.
NOTE: It is important that you format CID records correctly
Time Date Number of calls BEFORE storing in internal memory as you cannot reformat
CID records stored in memory.
1. Make sure the phone is OFF (in standby mode).
2. Press the Caller ID/vol (- or +) button to scroll to the desired caller ID.
3. Press the mem button.
4. Press a number key (0 - 9) to store the number in that memory location.
You will hear a confirmation tone.
Caller ID name
Example
