INSTRUCTIONS FOR SAFE OPERATION, AND MAINTENANCE
WARNING
TASK FORCE TIPS LLC
MADE IN USA · tft.com
©Copyright Task Force Tips LLC 2004-2022
Understand manual before use. Operation of this device without understanding the manual and
receiving proper training is a misuse of this equipment. Obtain safety information at tft.com/serial-
number.
This equipment is intended for use by trained and qualified emergency services personnel for
firefighting. All personnel using this equipment shall have completed a course of education
approved by the Authority Having Jurisdiction (AHJ).
This instruction manual is intended to familiarize firefighters and maintenance personnel with the
operation, servicing, and safety procedures associated with this product. This manual should be
kept available to all operating and maintenance personnel.
Improper use of agent can result in injury or damage to the environment. Follow the agent
concentrate manufacturer's instructions and fire service training to avoid using the wrong type of
agent for disinfection purposes.
There are a wide variety of agent concentrates. Each user is responsible for verifying that any agent
concentrate chosen to be used with this unit has been tested to assure that the agent obtained is
suitable for the purpose intended.
UL521
Pat# 5,810,0 89
TAS K FOR CE TIP S
Valpar aiso, IN 46383-
9327
+1 219 462-61 61 • 800
348-26 86 • MADE IN
U.S.A.
WAR NING
Read manua l before
use.
www.t ft.com
D E C O N / p a k
POR TAB LE DEC ONT AM INA
TIO N SYS TEM
DECON/pak™
Portable Decontamination System
TM
P ATE NTE D
UL502 -D
0.1% to 0.5% continuously adjustable
1
RATED FLOW
12 GPM at 100 PSI
45 L/MIN at 6.8 BAR
Minimum Operating Condition
7 GPM at 40 PSI
30 L/MIN at 3 BAR
Maximum Operating Condition
27 GPM at 500 PSI
100 L/MIN at 40 BAR
ADDITIVE SETTINGS
RINSE (water only)
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 · 219-462-6161 · Fax 219-464-7155
LIU-050 February 7, 2022 Rev3
Advertisement
Table of Contents
Related Manuals for TFT DECON/pak
Summary of Contents for TFT DECON/pak
- Page 1 Understand manual before use. Operation of this device without understanding the manual and WARNING receiving proper training is a misuse of this equipment. Obtain safety information at tft.com/serial- number. This equipment is intended for use by trained and qualified emergency services personnel for firefighting.
- Page 2 DANGER PERSONAL RESPONSIBILITY CODE The member companies of FEMSA that provide emergency response equipment and services want responders to know and understand the following: Firefighting and Emergency Response are inherently dangerous activities requiring proper training in their hazards and the use of extreme caution at all times. 2.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1.0 MEANING OF SAFETY SIGNAL WORDS 2.0 SAFETY 3.0 GENERAL INFORMATION 3.1 SPECIFICATIONS 3.2 PART IDENTIFICATION 3.3 LEFT OR RIGHT HAND OPERATION 3.4 DILUTION EQUIVALENTS 4.0 FLOW CHARACTERISTICS 5.0 AGENT SELECTION 5.1 AGENT COMPATIBILITY 6.0 OPERATION 6.1 HOSE CONNECTION 6.2 FILLING THE TANK 6.3 CONNECTING DISCHARGE HOSE AND NOZZLE 6.4 SETTING AGENT CONCENTRATION... -
Page 4: Meaning Of Safety Signal Words
MEANING OF SAFETY SIGNAL WORDS A safety related message is identified by a safety alert symbol and a signal word to indicate the level of risk involved with a particular hazard. Per ANSI Z535.6, the definitions of the four signal words are as follows: DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury. -
Page 5: General Information
The DECON/pak is not intended to be used for Class A, Class B, or any other type of foam concentrate. If you intend to use the DECON/ pak for liquids other than decontamination agents and water, we urge you to contact Task Force Tips Service Department at 800-854- 6864. -
Page 6: Dilution Equivalents
DILUTION EQUIVALENTS Agents used in the DECON/pak are to be diluted according to the manufacturer’s specifications. The DECON/pak delivers agent at between 0.1 and 0.5%. The following chart describes percentages and dilution ratios. Percentage ml/l Oz/gal Ratio 0.23% 2 US teaspoons 1:427 0.39%... -
Page 7: Agent Selection
Figure 6.0 HOSE CONNECTION Attach inlet fire hose to the coupling on the inlet end of the DECON/pak. Larger hoses may be used with an adapter. For maximum maneuverability, we recommend attaching 1” hose to the DECON/pak itself. FILLING THE TANK Unscrew the fill port lid by turning counterclockwise. -
Page 8: Connecting Discharge Hose And Nozzle
Turn the knob to the desired concentrate percentage. CONTROLLING FLOW Pressurize the hose line. Turn the flow control valve to start water flowing through the DECON/pak. Flow may be reduced by partially closing the control valve. AGENT QUALITY... -
Page 9: Shut Down After Use (Flushing)
SHUT DOWN AFTER USE (FLUSHING) DECON/pak should be flushed with water after each use to prevent agent concentrate from drying out inside of the Control Block and Percentage Knob. 1. Reduce pump pressure to 100 psi or less. 2. Remove the nozzle and/or hose from the quick-connect on the front of the Control Block. -
Page 10: Warranty
46383-9327 USA, within a reasonable time after discovery of the defect. TFT will examine the equipment. If TFT determines that there is a defect attributable to it, TFT will correct the problem within a reasonable time. If the equipment is covered by this limited warranty, TFT will assume the expenses of repair. -
Page 11: Troubleshooting
DECON/pak. Reset percentage knob to proper percentage when finished. For years of service, periodically inspect your DECON/pak. Make sure the hose and fan nozzle are in place. Look for debris in the bottom of the tank and flush if necessary. -
Page 12: 11.0 Operation And Inspection Checklist
Operating equipment that has failed the checklist is a misuse of this equipment. TASK FORCE TIPS LLC 3701 Innovation Way, Valparaiso, IN 46383-9327 USA 800-348-2686 · 219-462-6161 · Fax 219-464-7155 MADE IN USA · tft.com ©Copyright Task Force Tips LLC 2004-2022 LIU-050 February 7, 2022 Rev3...
