GE GSS20IEP Dimension Manual

GE Appliances
GSS20IEP – GE 19.9 Cu. Ft. Side-By-Side Refrigerator with Dispenser
®
Dimensions (in inches)
A B

Front View

Specification Revised 7/05
310283
"94 SxS Refer
H
G
C
D

Top View

Height to top of hinge (in.) A
Height to top of case (in.) B
Case depth without door (in.) C
Case depth less door handle (in.) D
Case depth with door handle (in.) E
Depth with fresh food door open 90° (in.) F
E
Width (in.) G
F
Width with door open 90° less door handle (in.) H
Each side (in.)
Top (in.)
Back (in.)
†Water hook-up fits in back air clearance when calculating installation depth.
If installed against a wall, allow clearance of 10-3/4" on freezer side to
remove bin.
Clearance required to remove fresh food full-size pan without disassembling
is 13-1/2" .
Allow additional space for any necessary leveling adjustments.
Total volume and shelf
area are calculated by
the Association of Home
Appliance Manufacturers'
standards.
For answers to your Monogram,
GE appliance questions, visit our website at
®
GEAppliances.com or call
GE Answer Center service, 800.626.2000.
®
67-1/2
66-1/2
28
†
† 31-1/4
33-9/16
†
† 47-3/8
31-1/2
31-5/8
1/8
1
1
Listed by
Underwriters
Laboratories
R
GE Profile or
® ™
R
