Dimensions and Installation Information (in inches)
Heighttotopofhinge(in.)A
Heighttotopofcase(in.)B
Casedepthwithoutdoor(in.)C
Casedepthlessdoorhandle(in.)D
Casedepthwithdoorhandle(in.)E
Depthwithfreshfooddooropen90°(in.)F
Width(in.)G
Widthwithdooropen90°inc.doorhandle(in.)H
Eachside(in.)
Top(in.)
Back(in.)
† W aterhook-upfitsinbackairclearancewhencalculating
installationdepth.
Ifinstalledagainstawall,allowclearanceof10-3/4"onfreezer
sidetoremovebin.
Clearancerequiredtoremovefreshfoodfull-sizepanwithout
disassemblingis15".
Allowadditionalspaceforanynecessarylevelingadjustments.
ForanswerstoyourMonogram,
GEProfile
®
GE
®
appliancequestions,visitourwebsiteat
ge.comorcallGEAnswerCenter
service,
®
800.626.2000.
22.7Cu.Ft.StainlessSide-By-SideRefrigeratorwithDispenser

69-1/4
68-3/4
23-7/8
†
26-3/4
†
29-3/16
†
45-9/16
†
35-3/4
41-3/16
1/8
1
1/2
or
™
A
B
Front View
"94 SxS Refer
C
D

Top View

Listed by
Underwriters
Laboratories
Specification Created 2/07
H
G
E
F
Total volume and shelf
area are calculated by
the Association of Home
Appliance Manufacturers'
standards.
310178
