- Page 1 LIFESTYLE ® BUILT-INvisible ® Home Theater System Media Center Installation Guide ® Home Theater System...
- Page 2 Bose recommends that you keep your sales slip and product registration card together with this guide. ©2003 Bose Corporation. No part of this work may be reproduced, modified, distributed or otherwise used without prior written permission. Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories. Confidential Unpublished Works.
-
Page 3: Table Of Contents
Contents Where to find … System Installation ............. Before you begin . -
Page 4: System Installation
System Installation Before you begin Check the shipping carton for the items shown in Figure 1. Figure 1 Carton contents AM loop antenna FM antenna ® Component video adapter Optional IR emitter cable Media center power supply Mounting strip Extension cable for TV on/off 120 VAC power cord (US/Canada) TV on/off detector... -
Page 5: Connecting The Antennas
• Place the media center close enough to other sound sources (TV and VCR) to allow for easy cable connections. If you need additional audio and/or video cables to connect all of your components, see your dealer or call Bose ®... -
Page 6: Connecting To A Cable Radio Provider
To make component video connections, you will need video-grade cables for the Y, Pb, ® and Pr jacks and the Bose component video adapter (Figure 5). This adapter plugs into the S-VIDEO and COMPOSITE outputs. Your system will send the correct signals to these jacks ®... -
Page 7: Connecting Your Vcr To The System (Optional)
Note: If your VCR did not come with the stereo audio and video cables required to connect it to your LIFESTYLE ® system, contact your local electronics store or authorized Bose ® dealer. 1. Connect the left (L) and right (R) audio outputs on the rear panel of your VCR to the L and R VCR audio inputs on the rear panel of the media center (Figure 6). -
Page 8: Installing The Tv On/Off Detector (Optional)
System Installation The rear panel of the media center provides audio and video connections for your cable/sat- ellite box. 1. Connect the left (L) and right (R) audio outputs (if available) on the rear panel of your cable/satellite box to the L and R AUX audio inputs on the rear panel of the media center (Figure 7). -
Page 9: Turning Off The Internal Speakers In Your Tv
System Installation Figure 8 Back of TV Mounting the detector TV on/off detector installed using the mounting strip TV on/off detector on your TV Media center rear panel RECORD TAPE VC R DC POWE R 1.1A SENSO R VIDEO INPUTS COMPOSITE S-VIDEO ANTENNA... -
Page 10: Finishing The Installation
System Installation Finishing the installation Two setup discs are included in the carton with the media center. • Setup Disc 1 verifies that your system’s speakers Setup Disc 1 are connected correctly and that your new system is performing as intended. ADAPTiQ ®... - Page 11 System Installation Save the headset for possible future use When you have played both discs and followed their instructions, the installation of your ® ® LIFESTYLE BUILT-INvisible system is completed and its performance is tailored to your par- ticular listening area. Significantly changing the arrangement of the room (relocating seating, furniture, speakers) will change your listening environment.
-
Page 12: Reference
Reference Connecting external equipment Other equipment can be connected to your system using standard RCA audio cables. Be sure to match the red connector to the R (right) channel and the white (or black) connector to the L (left) channel. A Y adapter can be used to connect mono sources. The appropriate cables are available at most electronic stores. -
Page 13: Connecting Other Playback Equipment
Reference Connecting other playback equipment Other playback components such as an audio CD changer can be connected to the AUX inputs on the rear panel of the media center. Figure 11 AUX input connections RECORD TAPE VC R DC POWE R 1.1A SENSO R VIDEO INPUTS... -
Page 14: Connecting The Optional Ir Emitter Cable
3. Confirm that IR signals now work to control that component. Move the emitter around, as necessary, to find the best position. 4. Use the double-sided tape enclosed with the emitter to affix it in the proper position. Note: If you have questions, or need to obtain a replacement emitter, contact Bose ® customer service. -
Page 15: Technical Information
Reference Technical information Media center power pack power rating USA/Canada: 120V 0.55A 50/60 Hz 33VDC 1.1A Media center inputs TAPE: 2Vrms, maximum AUX: 2Vrms, maximum VCR: 2Vrms, maximum TV: 2Vrms, maximum DIGITAL: SPDIF (1 each for TV, VCR, TAPE, and AUX) with sync 75 Ω... - Page 16 ©2003 Bose Corporation, The Mountain, Framingham, MA 01701-9168 USA 273656 AM Rev.00 JN00035...
