Summary of Contents for New Holland Speedrower 130
Page 1
SERVICE MANUAL Speedrower ® Self-Propelled Windrower Part number 47698328 edition English April 2014...
Page 2
Link Product / Engine Product Market Product Engine Speedrower® 130 North America F4GE9484 Speedrower® 130 International Region F4GE9484 47698328 14/04/2014 Find manuals at https://best-manuals.com...
Some information could not be updated due to modifications of a technical or commercial type, or changes to the laws and regulations of different countries. In case of questions, refer to your NEW HOLLAND Sales and Service Networks. 47698328 14/04/2014...
NEW HOLLAND. The installation and or use of such products could have negative effects upon the design character- istics of your machine and thereby affect its safety. NEW HOLLAND is not liable for any damage caused by the use of "NON-GENUINE" NEW HOLLAND parts and accessories.
INTRODUCTION Safety rules Speedrower® 130 [YEG6XX001 - ] Personal safety This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible death or injury. Throughout this manual you will find the signal words DANGER, WARNING, and CAUTION followed by special in- structions.
INTRODUCTION Safety rules Speedrower® 130 [YEG6XX001 - ] Speedrower® 130 General safety rules Use caution when operating the machine on slopes. Raised equipment, full tanks and other loads will change the center of gravity of the machine. The machine can tip or roll over when near ditches and embankments or uneven surfaces.
Page 11
INTRODUCTION Operate controls only when seated in the operator’s seat, except for those controls expressly intended for use from other locations. Before leaving the machine: 1. Park machine on a firm level surface. 2. Put all controls in neutral or park lock position. 3.
Page 12
INTRODUCTION When welding, follow this instructions in the manual. Always disconnect the battery before welding on the machine. Always wash your hands after handling battery components. Wheels and tires Make sure tires are correctly inflated. Do not exceed recommended load or pressure. Follow instructions in the manual for proper tire inflation.
Page 13
INTRODUCTION Do not weld or flame cut any items that contain flammable material. Clean items thoroughly with non-flammable solvents before welding or flame-cutting. Do not expose the machine to flames, burning brush, or explosives. Promptly investigate any unusual smells or odors that may occur during operation of the machine. General battery safety Always wear eye protection when working with batteries.
Page 14
INTRODUCTION Operator presence system Your machine is equipped with an operator presence system to prevent the use of some features while the operator is not in the operator’s seat. The operator presence system should never be disconnected or bypassed. If the system is inoperable, the system must be repaired. Power Take-Off (PTO) PTO-driven machinery can cause death or serious injury.
Page 15
INTRODUCTION To release the belt, push the red release button (1) on the buckle and pull the tongue from the buckle. 10041220 Air-conditioning system The air-conditioning system is under high pressure. Do not disconnect any lines. The release of high pressure can cause serious injury.
Page 16
INTRODUCTION Utility safety Make sure the machine has sufficient clearance to pass in all directions. Pay special attention to overhead power lines and hanging obstacles. High voltage lines may require significant clearance for safety. Contact local authorities or utilities to obtain safe clearance distances from high voltage power lines. Retract raised or extended components, if necessary.
Page 17
INTRODUCTION Do not use the steering wheel or other controls or accessories as handholds when entering or exiting the cab or operator’s platform. Header lift locks Do not work under the machine header unless it is securely blocked and/or the header safety latch is engaged. Header will fall rapidly if hydraulic lift system should fail.
• Do not open the air-conditioning system yourself. It contains gases that should not be released into the atmosphere. Your NEW HOLLAND dealer or air conditioning specialist has a special extractor for this purpose and will have to recharge the system properly.
INTRODUCTION Personal safety - Safety signs The following safety signs are placed on your machine as a guide for your safety and for those working with you. Walk around the machine and note the content and location of these safety signs before operating your machine. Keep safety signs clean and legible.
Page 21
INTRODUCTION WARNING Check torque of front wheel nuts and rear wheel bolts every 5 hours until no loss of torque is found. Failure to comply could result in death or serious injury. Quantity 1 English 87730677 87730677_A (1) Upper right corner of the cab door. 93100193 WARNING Always fasten seatbelt during operation.
Page 22
INTRODUCTION WARNING Before starting engine or any function. Warn bystanders. Sound horn 3 times. Failure to comply could result in death or serious injury. Quantity 1 English 86640432 French 86640433 Spanish 86640434 Russian 84378977 Chinese 84012892 86640432 (3) On the right-hand side cab glass, upper right side of glass.
Page 23
INTRODUCTION WARNING Set machine to clear obstructions and stones. Machine can throw stones and debris toward bystanders. Keep bystanders away while in operation. Keep all shields and covers in place and in good working order. When descending steep grades, place range control in field operating position to prevent loss of control.
Page 24
INTRODUCTION EMERGENCY EXIT If it becomes impossible to open the cab door, while in the cab, the right cab window can be used as an emergency exit. Remove the hammer from the bracket on the right rear post of the cab. Use the pointed hammer to shatter one of the windows.
Page 25
INTRODUCTION DANGER START ENGINE ONLY FROM OPERATOR'S SEAT. If safety start switch is bypassed, engine can start with transmission in gear and machine will move. DO NOT short or connect across terminals of starter solenoid. Failure to comply will result in death or serious injury.
Page 26
INTRODUCTION DANGER DO NOT use ether starting fluid with a "THERMOSTART" system. AN EXPLOSION MAY OCCUR. Failure to comply will result in death or serious injury. Quantity 2 English 629086 French 682683 Spanish 86600617 Russian 84379011 Chinese 84203074 629086 (9) On the air intake tube. NHPH12WR00345AA (9) Above the intercooler on the right-hand side of the radiator support.
Page 27
INTRODUCTION WARNING TO PREVENT LOSS OF CONTROL DO NOT tow on public roads or use recovery hook point as a hitch. An optional hitch receiver kit is available for swath roller. (See Section 10 - Optional equipment for more details) Failure to comply could result in death or serious injury.
Page 28
INTRODUCTION DANGER / POISON Shield Eyes Explosive Gases NO Sparks NO Flames NO Smoking Sulfuric Acid Flush eyes immediately with water. GET Medical help fast. Failure to comply will result in death or serious injury. KEEP OUT of reach of children. Do not tip. Battery must be secure and level.
Page 29
INTRODUCTION WARNING Before operating machine, read operator's manual and ALL SAFETY instructions. If manual is missing, contact your dealer or service department. Before starting engine or operation, clear area of bystanders. Disengage drives including PTO. Stop engine, wait for all movement to stop before leaving operator's position.
Page 30
INTRODUCTION WARNING 1. Operate at low speeds in tight areas or on hillsides. 2. Avoid abrupt changes in direction at high speeds. 3. Keep header as low as possible. 4. Before leaving operator's platform, put controls in neutral, set brake, lower header and stop engine. Failure to comply could result in death or serious injury.
Page 31
INTRODUCTION WARNING Torque in numbered sequence to 400 N·m (295 ft lb). Go around 3 times. Re-torque at 5 hour intervals until bolts retain torque. Failure to comply could result in death or serious injury. Quantity 2 English: 84240284 French 84240287 Spanish 84240286 Russian 84240288 84240284_A...
Page 32
INTRODUCTION DANGER CRUSHING HAZARD - HEADER Header will fall rapidly if hydraulic lift system should fall. Rest header on ground or engage header lock handle before working around raised header. Failure to comply will result in death or serious injury. Quantity 2 84554251 84554251_B...
Page 33
INTRODUCTION WARNING INSTRUCTIONAL SEAT. To be used for training or diagnostic purposes. Extra riders, especially children, are NOT permitted on machine. Buckle up! Failure to comply could result in death or serious injury. Quantity 1 English 86640438 French 86640439 Spanish 86640440 Russian 84379029 Chinese 84282118 86640438...
Page 34
INTRODUCTION WARNING Keep hands and clothing away from rotating fan and belts. Failure to comply could result in death or serious injury. Quantity 2 English 86501511 French 86509716 Spanish 86601164 Russian 84379019 Chinese 332511A1 86501511 (18) Left-hand side of fan shroud. 93100182 (18) Right-hand side of fan shroud.
Page 35
INTRODUCTION CAUTION WHEN BACKING UP, HOLD THE STEERING WHEEL AT BACK OF RIM AND MOVE YOUR HAND IN THE DIRECTION YOU WANT TO GO Failure to comply could result in minor or moderate injury. Quantity 1 86555355 86555355 (19) Attached to steering wheel. 93100185 WARNING TO PREVENT LOSS OF CONTROL...
Page 36
INTRODUCTION WARNING PRESSURIZED FLUID OR GAS Hydraulic accumulator contains gas and oil under pressure. Service or repair must be performed only by trained service technician. Failure to comply could result in death or serious injury. Quantity 1 84005363 84005363_B Non draper units only (21) Behind front skirt applied to the main frame.
Page 37
INTRODUCTION WARNING PRESSURIZED FLUID Use controller’s BLEED program to relieve system pressure before disassembling any hydraulic connection. Refer to service manual for more details. Failure to comply will result in death or serious injury. Quantity 1 47564945 47564945_A (22) Right-hand side frame rail near right-hand side platform.
DO NOT OPERATE TAG A. (1) Do not operate. B. (2) Do not remove this. C. (3) See other side. D. (4) Signed by. E. (5) Reason The DO NOT OPERATE tag can be obtained from your NEW HOLLAND dealer. 47698328 14/04/2014...
INTRODUCTION Torque - Standard torque data for hydraulics INSTALLATION OF ADJUSTABLE FITTINGS IN STRAIGHT THREAD O RING BOSSES 1. Lubricate the O-ring by coating it with a light oil or petroleum. Install the O-ring in the groove adjacent to the metal backup washer which is assembled at the extreme end of the groove (4).
Page 44
INTRODUCTION PIPE THREAD FITTING TORQUE PIPE THREAD FITTING Torque (Maximum) Thread Size Before installing and tightening pipe fittings, clean the 1/8-27 13 N·m (10 lb ft) threads with a clean solvent or Loctite cleaner and apply 1/4-18 16 N·m (12 lb ft) sealant L ®...
Only use CNH Original Parts or NEW HOLLAND Original Parts. Only genuine spare parts guarantee the same quality, duration, and safety as original parts, as they are the same parts that are assembled during standard production. Only CNH Original Parts or NEW HOLLAND Original Parts can offer this guarantee.
Page 46
Failure to comply could result in death or serious injury. W0111A The special tools that NEW HOLLAND suggests and illustrate in this manual have been specifically researched and designed for use with NEW HOLLAND machines. The special tools are essential for reliable repair operations. The special tools are accurately built and rigorously tested to offer efficient and long-lasting operation.
INTRODUCTION Hydraulic contamination Contamination in the hydraulic system is a major cause of the malfunction of hydraulic components. Contamination is any foreign material in the hydraulic oil. Contamination can enter the hydraulic system in several ways: • When you drain the oil or disconnect any line •...
Application Lubricant Lube class Engine crankcase See engine oil viscosity chart CI-4 or CH-4 Engine flywheel gearbox NEW HOLLAND AMBRA HYPOIDE SSL GEAR OIL Hydraulic system NEW HOLLAND AMBRA MULTI G 134™ HYDRAULIC J20A TRANSMISSION OIL Planetary final drives NEW HOLLAND AMBRA HYPOIDE 90 or...
INTRODUCTION Product identification - Product Identification Number (PIN) Speedrower® 130 [YDG670501 - ] The windrower identification plate (1) is located on the left side of the frame, next to the platform steps (2). The iden- tification plate includes the model number and the PIN. NOTE: The identification number of the windrower is re- quired when ordering service parts.
INTRODUCTION Part identification - Engine serial number Speedrower® 130 [YDG670501 - ] The engine specifications (1) are located on the right-hand side of the front gearbox housing (2). NOTE: The identification number of the engine is required when ordering service parts. The numbers may also be required to identify a stolen windrower.
Page 51
SERVICE MANUAL Engine Speedrower® 130 47698328 14/04/2014...
Page 54
Contents Engine - 10 Engine and crankcase - 001 TECHNICAL DATA Engine and crankcase General specification ............... 3 SERVICE Engine Remove .
Page 55
Engine - Engine and crankcase Engine and crankcase - General specification Description of operation The power supply is a four stroke turbo charged diesel engine. The engine has overhead valves with direct injection from a rotary fuel pump. A water cooling system, alternator and air conditioner compressor are part of the engine. The windrower propulsion, header drive, and header lift hydraulic pumps are driven through a splitter gearbox mounted on the flywheel end of the engine.
Page 56
Engine - Engine and crankcase Engine - Remove 1. Drain coolant from radiator and engine by opening valve (1). Catch fluid from drain hose and save for recycling. Remove the radiator cap to speed up the draining, using caution if the system is hot. 86070790 2.
Page 57
Engine - Engine and crankcase 7. Using a helper, detach four gas springs (1) from engine area side doors by removing four flange nuts and lock washers. 8. Remove side doors by removing one bolt (2) and loos- ening one (3) at each of twelve pivot clips (4). 9.
Page 58
Engine - Engine and crankcase 20. Remove four flange bolts, lock washers and flange nuts (1), to detach hood support frame from radiator side supports. Frame can now be removed with roof panel attached. 50041834 21. Disconnect wire harness at both sides of intake air heater (1) if so equipped, and at oil pressure switch (2).
Page 59
Engine - Engine and crankcase 24. Remove three 5/16 x 3–3/4 cap screws with lock washers and flange nuts (1) from holes in compressor and through lower mount casting. 25. Remove drive belt and lay compressor over to right side of machine with hoses connected. NHIL12WR00653AA 26.
Page 60
Engine - Engine and crankcase 29. Remove plug (1) to drain oil from gear box. 30. With adequate support provided for the pumps, re- move twelve flange bolts (2). 76113149 31. There are three tapped holes (1) in periphery of cover plate that are provided for removal purposes.
Page 61
