Part i t i on#1 ②コピー先HDDを接続し【OK】を押します。 ③コピー先の準備が整ったら【OK】を押すと開始されます。 トータルデータ量 実行中の機能 Copy x 1 483GB 経過時間と% コピー済データ量 1 : 00 4% 1 1.3GB ④コピーが完了すると結果が表示されます。 コピー成功回数 コピー失敗回数 Pass : 1 Fa i l : 0 経過時間 T i me 1 : 25 10 〈KD25/35HS〉...
Page 14
この機能を使用する前に、すべての重要なデータのバックアップを必ず行ってください。 4.3 DoD Erase(DoDイレース) HDDを3回消去する、米国国防総省(DoD5220)に準拠した消去方法です。トータル3回のアクセスを 行うため、フルイレースよりもさらに長い時間がかかります。 この機能を使用する前に、すべての重要なデータのバックアップを必ず行ってください。 操作方法 HDDを接続し、消去を選択し、【OK】を押します。 DoD Erase 1 ready 消去中 Eras i ng 1 HDD 5 : 20 終了すると結果が表示されます。 T i me : 1 : 30 : 09 Pass 1 Fa i l 0 11 〈KD25/35HS〉...
Page 16
注意!: S.M.A.R.T情報については、各HDD/SSDメーカーによって表示方法や値の計算方法が 異なりますので、値が正常に表示されなかったり、異常な値が表示される場合があります。 こちらは本製品の仕様となりますので、あらかじめご了承ください。 操作方法 機能を選択し、【OK】を押します。 [ 5. Ut i l i t y ] 1. Show HDD Info. 5.1.1 Model Number 型番を表示します。 Mode l : 型番 3000DM001--9YN166 5.1.2 Version of Firmware ファームウェアバージョンを表示します。 Vers i on : ファームウェアバージョン CC4C 13 〈KD25/35HS〉...
Page 17
[ Rea l l ocat i on E ] 代替セクタ処理回数 Not Ava i lab l e ! →処理が行われたことがない 場合は、 「Not Available」 と表示されます。 5.1.7 Off-line Scan Uncorrectable Sector Count 回復不可能なセクタの総数を表示します。 [ Off -- l i ne Scan ] 不良セクタ総数 14 〈KD25/35HS〉...
Page 19
5.2.2 Format HDDの機能を使って空のHDDをフォーマットします。 [ Update System ] 2. Format HDD ファームウェアファイルをフォーマットしたHDDにコピーします。 ファームウェアファイル ファームウェアファイル コピー フォーマット済 HDD アップデート処理に最適化するため、2GB の FAT フォーマットパーティションが作成されます。 Format HDD Do FORMAT HDD#1 Conf i rm ? HDDを本製品に接続して、5.2.1 Update BIOS を行います。 [ Update System ] 1. Update BIOS 16 〈KD25/35HS〉...
Page 20
【各機能紹介】 5.3 System Info.(システム情報) 本製品の名前およびBIOSバージョンを表示します。 KD25/35HS BIOS version Ver : 2.31.0 5.4 Read Speed HDDの読み込み速度を計測します。 R 0 : 03 2794G 191. 9M/S 612M 5.5 Write Speed HDDの書き込み速度を計測します。 操作方法 機能を選択し、【OK】を押します。 W 0 : 06 2794G 151.8M/S 996M 注意!: 本機能を使用する際は、HDDをDevice2側に接続する必要があります。 また、HDDのデータは消去されますのでご注意ください。 17 〈KD25/35HS〉...
Page 21
システムとファイルのみをコピーします。コピーを行う前に分析を行います。 コピー先HDDはコピー元のHDDのパーティションより大きい容量が必要です。 [ Copy Area ] System and F i l es Source HDD 320GB Target HDD 320GB データ : 20GB この場合20GB分のデータのみが パーティション : 90GB コピーされます。 20GB 20GB Copy area Partition 1 Partition 1 90GB 90GB Partition 2(Blank) 20GB 30GB data 320GB 320GB only! この処理はFAT16/32、NTFS、EXT2/3/4およびMBR、GPTのみサポートします。 その他の形式は正しくコピーできません。 6.1.3 Whole HDD(HDD全体をコピー)をお使いください。 18 〈KD25/35HS〉...
Page 22
前に パーティションの分析が行われます。 [ Copy Area ] ALL Part i t i ons Source HDD 320GB Target HDD 320GB データ : 20GB 120GBの パーティション : 90GB エリアがコピーされます。 20GB 20GB Copy Partition Partition 1 Partition 1 area 90GB 90GB Partition 2(Blank) Partition 2(Blank) 30GB 30GB 320GB 320GB この処理はFAT16/32、NTFS、EXT2/3/4およびMBR、GPTのみサポートします。 その他の形式は正しくコピーできません。 6.1.3 Whole HDD(HDD全体をコピー)をお使いください。 19 〈KD25/35HS〉...
Page 23
320GB 320GB 320GB 6.2 Skip Error(エラースキップ) この設定はコピー処理中のエラースキップの回数を設定します。 [Sk i p Error ] 6.3 Erase Master(イレースマスター) Drive1のHDDも消去対象に含めるかを設定します。イレース処理を行う前に必ずこの項目を確認、設定 してください。 6.3.1 Disable(無効) [ Erase Master ] D i sab l e 6.3.2 Enable(有効) [ Erase Master ] Enab l e 20 〈KD25/35HS〉...
Page 24
【各機能紹介】 6.4 Unknown Format(Unknownフォーマット) 不明なフォーマットされたパーティションをコピーするかしないかを設定します。 6.4.1 Copy Unknown(Unknownコピー) 形式を特定できない領域もすべてコピーします。 [Unknown Format ] Copy Unknown 6.4.2 Skip Unknown(Unknownスキップ) 形式を特定できない領域はスキップします。 [Unknown Format ] Sk i p Unknown 6.5 Transfer Rate(転送速度) 転送速度をUltraDMA2〜7に設定します。 [ Transfer Rate ] UDMA 5 21 〈KD25/35HS〉...
Page 25
6.6 Erase Pattern(イレースパターン) イレースパターンを選択します。 6.6.1 ONE Byte 毎バイト単位でランダムパターンを書き込みます。 [ Erase Pattern ] One Byte 6.6.2 4MB Byte 4MB単位のランダムなどこかにランダムパターンを書き込みます。 [ Erase Pattern ] 4MB Byte 6.7 Language(言語) LCD情報パネルに表示する言語を設定します。 6.8 Stop Motor Time 各種処理が完了した後、HDDの回転を停止する秒数を設定します。 6.9 Restore Default(デフォルトに戻す) 各設定項目を工場出荷時設定に戻します。 22 〈KD25/35HS〉...
Page 27
A: 本製品をHDD/SSDに接続する必要があるため、パソコンからHDDを取り出して 直接接続する必要がございます。 Q:コピーする前にコピー先HDD/SSDをフォーマットしておく必要はありますか? A: 必要ありません。 コピー元H D D/S S Dのファイルシステム、フォーマットで上書きされますので、 コピー先HDD/SSDの内容はどのようなフォーマットを行ってあっても消去されます。 Q:ライセンスのあるプログラムの入ったHDD/SSDをコピー可能ですか? A: H D Dの固有情報を参照するような特殊なプログラムが存在しない限り、コピーを 行うことは可能です。 ただし、コピーを行った後、そのHDD/SSDを使用できるのかは、そのプログラムの ライセンスに依存する形になります。 プログラムのライセンス内容をご確認ください。 Q: コピー元は320GBのHDDで100GBのパーティション内にデータが20GB入って います。System and Filesのコピーで32GBのSSDにコピーが可能ですか? A: コピーできません。 コピー元のパーティションサイズよりも大きいサイズのHDD/SSDが必要となります。 ※ 市販のパーティション編集を行うソフトウェアを使用して、あらかじめコピー元のHDDのパーティ ションサイズを小さくしてからコピーすることで、コピーが可能な場合もございます。 Q:Skip Errorを設定にしたのにSkipにならずエラーで止まってしまうのですが? A: Skip Errorはコピー元のHDDにしか適用されません。 コピー先のHDDに異常がないかご確認ください。 24 〈KD25/35HS〉...
Page 28
【FAQ】 Q:コピーが完了すれば、確実にコピーは行えていますか? A: コピーの段階ではコピー先HDDとのデータ検証は行っておりません。 Compareの機能を使って比較を行うことで確実な確認が行えます。 また、エラースキップが発生した場合、不完全なコピーとなり、データにアクセス できない可能性があります。 Q: 故障していないHDDなのにS.M.A.R.T情報のシークエラーレートが異常な値を示し ます。 A: 一部のHDDは取得する項目が異なるため、エラーのないHDDで異常な値が表示される 場合があります。 弊社テストでは、S e a g a t e社製H D Dにて異常な値が表示されることを確認済み です。(2013年1月現在) 25 〈KD25/35HS〉...
Century Corporation User's Manual KD25/35HS English User Guide KD25/35HS...
Page 32
This manual contains materials should be intended for personal use. All right reserved. No part of this manual may be reproduced, transmitted or transcribed without the expressed written permission of the manufacturer .The information present in this manual is subject to change without prior notice. 29 〈KD25/35HS〉...
Page 33
Use only approved power sources. The product is only suitable for operation in dry, dust free, clean environment. Do not allow liquids or foreign objects to enter. Failure to do so may severely damage your duplicator. 30 〈KD25/35HS〉...
Page 34
Supports DoD erase function which complies with the standard of Department of Defense. Auto detects and shows the bad sector quantities of HDD. Light weight for easily carried. 31 〈KD25/35HS〉...
Page 35
HDD's damage is. 5.1.8 Seek Error Rate To show the error rate of searching for data. It can represent the damage rate of data stored in the HDD. 5.1.9 Temperature To show the temperature of HDD. 32 〈KD25/35HS〉...
Page 36
Copy unknown area when the device can not identify the format. 6.4 Unknown For mat 6.4.2 Skip Unknown Skip copy unknown area when the device can identify the format. Select the proper transfer rate from UDMA2 to UDMA7, UDMA7 is 6.5 Transfer Rate the fastest. 33 〈KD25/35HS〉...
Page 37
A set of random character to be written into a set of area. 6.7 Language 6. Setup Select preferred language. 6.8 Stop Motor Time To set the time of motor stopping after finishing function executing. 6.8 Restore Default Back to original manufacturer setting. 34 〈KD25/35HS〉...
Page 38
*Users can go to Function “6.3 Erase Master” to select if erasing the source HDD. The default setting is “Disable” to erase the source HDD. *This function can be stopped while processing by pressing [ESC] for about 3~4 seconds. 35 〈KD25/35HS〉...
Page 39
The system will start executing DoD Erase after pressing [OK]. DoD Erase Prepare Pattern Erasing. Erasing 1 HDD DoD Erase 2:05 [02] 465G Erase[00] 4818M The system will show the result after finishing. DoD Erase Pass: 5 Fail: 0 36 〈KD25/35HS〉...
Page 40
5.1.1 Model Number This function is to show HDD’s model number. [Disc Info.] 1. Model Number Model: WDC WD 5000BPVT-00HXZT3 5.1.2 Version of Firmware This function is to show HDD’s firmware version.. [Disc Info.] 2. Version of Firmware Version 01.01A01 37 〈KD25/35HS〉...
Page 41
This function is to show the count of reallocating event. When the HDD fails to save data, it will need to redefine the location to store data. Therefore, more count of reallocation event represents more error times. [Disc Info.] 7. Reallocation Event Count [Reallocation Event Count] 38 〈KD25/35HS〉...
Page 42
Select Function “5.2.2 Create Update HDD” [Update System] 2. Create Update HDD Create Update HDD(create a 2GB FAT partition) (The purpose of this is because 2GB FAT HDD Partition can speed up the update process.) Do FORMAT HDD#1 Confirm ? 39 〈KD25/35HS〉...
Page 43
5. 3 S ystem Info. Thi s function shows the duplicator information such as model name and firmware version. KD25/35HS Ver: 2.31.0 5. 4 Read Speed Thi s function i s to measure the reading speed of the HDD by reading the whole HDD.
Page 44
HDD and identify the data area to copy. As long as the source HDD's data is within the target HDD's free spa ce, the copy will be processed. [Copy Area] System and Files Note: System and Files only supports FAT, NTFS, and LINUX(ext2/ext3/ext4). 41 〈KD25/35HS〉...
Page 45
HDD. [Copy Area] All Partitions 6.1.3 Whole HDD Copies the entire HDD, regardless of content, format, partition or free space. This mode will take much more time to duplicate the source HDD completely. [Copy Area] Whole HDD 42 〈KD25/35HS〉...
Page 46
This function is used to select if copying the areas with unknown format. 6.4.1 Copy Unknown Copies all the unknown area even if the format is not identified. [Unknown Format] Copy Unknown Enable 6.4.2 Skip Unknown Skips the unknown format area during copy process. [Unknown Format] Skip Unknown Enable 43 〈KD25/35HS〉...
Page 47
When the system finish function executing, the motor won’t stop running immediately. This function is used to set the time of motor stopping after finishing function executing. [Stop Motor Time] 8 Seconds Enable 6.9 Restore Default This function is to go back to the manufacturer's default setting. 44 〈KD25/35HS〉...
Page 48
1.System and Files 2.All Partitions 3.Whole HDD Supports all format. Quick copy(System and Support Format Files) supports FAT, NTFS, Linux(Exy2/Ext3/Ext4) Capacity up to 2TB Power Supply 12V, 3A Working 5℃~45℃ Temperature Storage (-20)℃~85℃ Working 20%~80% Humidity Storage 5%~95% 45 〈KD25/35HS〉...
Page 56
– 拷貝過程 Copy 2047M 0:26 1037M 拷貝結果 Pass 0:58 No Bad Sector ! 53 〈KD25/35HS〉...
Page 57
4.3 DoD U.S.A. Department of Defense 0(0*00) F(0*FF) DoD Erase Prepare Pattern Erasing 1 HDD DoD Erase 2:05 [02] 465G Erase[00] 4818M DoD Erase Pass: 5 Fail: 0 54 〈KD25/35HS〉...
Page 58
4.4 DoD 抹除並比對 DoD 抹除比對的方式 * 5.1.1 [Disc Info.] 1. Model Number Model: WDC WD 5000BPVT-00HXZT3 5.1.2 [Disc Info.] 2. Version of Firmware Version 01.01A01 55 〈KD25/35HS〉...
Page 59
[Disc Info.] 3. Serial Number Serial N0.: WD-WXB1A91M3998 5.1.4 [Disc Info.] 5. Device Power Cycle [Device Power Cycle] 5.1.5 [Disc Info.] 6. Power-on Hours [Power-on Hours] 5.1.6 [Disc Info.] 7. Reallocation Event Count [Reallocation Event Count] 56 〈KD25/35HS〉...
Page 65
[Skip Error] If it’s critical that there are no errors on the HDD, then the error counter should be set to 0. ,是否要抹除母碟。 [Erase Master] Disable [Erase Master] Enable [Unknown Format] Copy Unknown Enable [Unknown Format] Skip Unknown Enable 62 〈KD25/35HS〉...
Page 66
UDMA2 UDMA7 UDMA7 [Transfer Rate] UDMA5 Enable 4.3
D oD 4.4
D oD [Erase Pattern] ONE Byte Enable [Erase Pattern] 4MB Byte Enable [Stop Motor Time] 8 Seconds Enable 63 〈KD25/35HS〉...
Page 67
Windows,
L inux,
R AID FAT16/32,
N TFS,
L inux(Ext2/Ext3/Ext4) 12V,
3 A
5 ~45
(-‐20) ~85
20%~80%
5%~95%
CE,
F CC,
R oHS
64 〈KD25/35HS〉...
