Page 1: User Guide
User Guide Personal Computer V G X - T P s e r i e s...
Page 2: Table Of Contents
Contents Before Use ...5 Notice ...6 Documentation ...7 Getting Started ...10 Locating Controls and Ports...11 About the Indicator Lights ...16 Setting Up Your Computer ...17 Shutting Down Your Computer Safely ...29 Using Your VAIO Computer ...30 Using the Keyboard ...31 Using the Touch Pad ...35 Using the Optical Disc Drive ...36 Using the TV Function ...45...
Page 3 Using Peripheral Devices...76 Selecting Display Modes...77 Using the Multiple Monitors Function ...78 Connecting a Universal Serial Bus (USB) Device...80 Connecting a Printer ...83 Connecting an i.LINK Device ...84 Connecting to a Network (LAN) ...86 Customizing Your VAIO Computer ...88 Setting the Password ...89 Setting Up Your Computer with VAIO Control Center...94 Using the Power Saving Mode...95 Upgrading Your VAIO Computer...98...
Page 4 Computer ...118 System Security ...124 Networking ...125 Optical Discs ...128 Display ...132 Printing ...134 Microphone ...135 Speakers ...136 Keyboard...137 Touch Pad...138 Floppy Disks ...139 Audio/Video...140 Memory Stick ...143 Peripherals ...144 Support Options ...145 Sony Support Information ...146 e-Support ...147 Trademarks ...149...
Page 5: Before Use
Before Use ® Congratulations on your purchase of this Sony VAIO computer, and welcome to the on-screen User Guide. Sony has combined leading-edge technology in audio, video, computing, and communications to provide state-of-the-art personal computing experience. External views illustrated in this manual may look slightly different from those of your computer.
Page 6: Notice
In the manual, the ™ or ® marks are not specified. Sony Corporation reserves the right to make any modification to this manual or the information contained herein at any time without notice. The software described herein is governed by the terms of a separate user license agreement.
Page 7: Documentation
❑ Troubleshooting and Recovery Guide — Contains solutions to problems other than those you encounter during normal operation. ❑ Regulations, Guarantee, EULA and Service Support — Contains Sony guarantee conditions, safety / regulations, modem regulations, wireless LAN regulations, wireless WAN regulations, Bluetooth regulations, end user software license agreement, and Sony support services information.
Page 8 ❑ Specifications — The online specifications describe the hardware and software configurations of your VAIO computer. To view the online specifications: Connect to the Internet. Go to the Sony online support web site at http://www.vaio-link.com. ✍ You may have a separate disc that includes documentation for the bundled accessories.
Page 9: Windows Help And Support
Before Use Windows Help and Support Windows Help and Support is a comprehensive resource for practical advice, tutorials, and demonstrations to help you learn to use your computer. Use the search feature, index, or table of contents to view all Windows Help resources, including those on the Internet. To access Windows Help and Support, click Start and Help and Support.
Page 10: Getting Started
Getting Started This section describes how to get started using your VAIO computer. ❑ Locating Controls and Ports (page 11) ❑ About the Indicator Lights (page 16) ❑ Setting Up Your Computer (page 17) ❑ Shutting Down Your Computer Safely (page 29) Getting Started...
Page 11: Locating Controls And Ports
Locating Controls and Ports Take a moment to identify the controls and ports shown on the following pages. The appearance of your computer may be different from those illustrated in this manual due to variations in specifications. It may also vary in some countries or areas.
Page 12 Hard disk drive/Optical disc drive indicator Power button/Power indicator (page 16) WLAN (Wireless LAN) indicator (page 16) Getting Started (page 16)
Page 13 Front SD memory card slot (page 62) WLAN (Wireless LAN) switch (page 67) Remote sensor Point the supplied remote commander to this sensor for operations. Optical disc drive (page 36) Memory Stick slot (page 56) Air vent Media Access indicator (page 16) Hi-Speed USB (USB 2.0) ports (page 80)
Page 14 Back The area around the air vent (1) becomes hot while your computer is on. Be sure to wait until the computer cools down before you touch it. Air vents VHF/UHF input port (page 45) WLAN ANT port (page 69) Hi-Speed USB (USB 2.0) ports (page 80) Headphones jack...
Page 15 Bottom Air vents Memory module compartment cover (page 99) Security slot Getting Started...
Page 16: About The Indicator Lights
About the Indicator Lights Your computer is equipped with the following indicator lights: Indicator Functions Power 1 The indication behavior varies depending on the state of your computer: Green lit: the computer is on. Orange lit: the computer is in Sleep mode. Off: the computer is off.
Page 17: Setting Up Your Computer
Setting Up Your Computer Connecting a Display Connect a display (not supplied) to your computer. When connecting it, see the manual that came with your display as well. ✍ Connect the power cord of your display after connecting all other cables. Getting Started...
Page 18 To connect a display (HDMI-compatible TV) To hear sound from the device connected to the HDMI OUT port, you need to change the device for sound output. For the detailed instructions, see How do I change the sound output device? Plug one end of the HDMI cable (supplied) (1) to the HDMI OUT port (2) on the computer.
Page 19 The HDMI cable carries both video and audio signals. If a device driver other than the one provided by Sony is used, the image will not be displayed and the audio will not be heard. Always use the device driver provided by Sony for updates.
Page 20 Additionally, you can connect a high-quality home theater receiver or other surround sound decoder devices between your computer and TV using an HDMI connection. To connect a high-quality digital sound output device between your computer and a TV Before connecting the device to the computer, make sure the HDMI connection has been set up between the TV and the home theater receiver or surround sound decoder device first.
Page 21 To connect a display (monitor) If you want to connect a computer display, connect the display cable (1) (not supplied) into the monitor port (2) on the back of the computer. If necessary, plug the display cable into the display. Getting Started...
Page 22: Connecting A Power Source
Connecting a Power Source You need an AC adapter to connect your computer to an AC power source and it must be plugged into the power source before you can establish communication with your wireless keyboard. ✍ Use only the supplied AC adapter for your computer. To connect the AC adapter Plug one end of the power cord (1) into the AC adapter (3).
Page 23 Getting Started...
Page 24 Getting Started ✍ To disconnect your computer completely from AC power, unplug the power cord when the computer is off. Make sure that the AC outlets are easily accessible. If you unplug the AC adapter from your computer while the computer is on or in Sleep mode, you may lose all unsaved data.
Page 25 Attaching the Rear Cover An exclusively designed rear cover is supplied with your computer for port protection and tidy cabling. Once you have set up your computer, attach the rear cover. Be sure to hold the cover with your both hands when attaching it. You may not be able to attach the rear cover depending on the shape or size of connected cable plugs.
Page 26: Connecting The Wireless Keyboard
Connecting the Wireless Keyboard A wireless keyboard and four AA alkaline batteries for use in the keyboard are supplied with your computer. Before attempting to use the wireless keyboard, you must install the batteries and establish communication between the computer and the keyboard.
Page 27 Insert the supplied four AA batteries into the battery compartment as illustrated below: Turn on the computer. Slide the power switch (2) on the keyboard to the ON position. Press the CONNECT button (3) on the front of the computer. Press the CONNECT button (4) on the bottom of the keyboard.
Page 28 Getting Started ✍ You can check the battery indicator ( ) in the LCD window on the wireless keyboard for its battery power level. If the wireless keyboard does not operate properly, the batteries may need to be replaced. If you do not intend to use the wireless keyboard for an extended period of time, remove the batteries to avoid possible damage from battery leakage.
Page 29: Shutting Down Your Computer Safely
Shutting Down Your Computer Safely To avoid losing unsaved data, be sure to shut down your computer properly, as described below. To shut down your computer Turn off any peripherals connected to the computer. Click Start, the arrow next to the Lock button, and then Shut Down. Respond to any prompts warning you to save documents or to consider other users and wait for the computer to turn off automatically.
Page 30: Using Your Vaio Computer
Using Your VAIO Computer Using Your VAIO Computer This section describes how to get the most out of using your VAIO computer. ❑ Using the Keyboard (page 31) ❑ Using the Touch Pad (page 35) ❑ Using the Optical Disc Drive (page 36) ❑...
Page 31: Using The Keyboard
Using the Keyboard A wireless keyboard is supplied with your computer. The wireless keyboard uses a standard key arrangement with additional keys that perform specific functions. The VAIO-Link Web site (http://www.vaio-link.com) also contains glossary information to help you use the keyboard. Using the Wireless Keyboard To maintain good communication, operate the wireless keyboard within the distance limitations of keyboard: 10 m from your computer.
Page 32 ✍ Illustrated above is the English keyboard as an example. Using Your VAIO Computer Security slot Function keys Perform certain tasks. The task associated with each function key varies among software applications. Shortcut buttons Perform the pre-assigned tasks. The default tasks are as follows: : Launches VAIO Living Browser.
Page 33 Indicators (Num lock): Turns on while in the Num Lock state. (Caps lock): Turns on while in the Caps Lock state. (Scroll lock): Turns on while in the Scroll Lock state. (Connect): Turns on while connection between the computer and the wireless keyboard is in place to indicate that the keyboard is ready for use (page...
Page 34 Using Your VAIO Computer Battery compartment Storage compartment for the AA batteries. CONNECT button (page 26) Press to enable the wireless keyboard to communicate with the computer.
Page 35: Using The Touch Pad
Using the Touch Pad You can point to, select, drag, and scroll objects on the screen using the touch pad. Action Description Point Slide your finger on the touch pad (1) to place the pointer (2) on an item or object. Click Press the left button (3) once.
Page 36: Using The Optical Disc Drive
Using the Optical Disc Drive Your computer is equipped with an optical disc drive. To insert a disc Turn on the computer. Push in the optical disc drive tray with your fingertip to eject it. Grasp the tray and gently pull it out. Using Your VAIO Computer...
Page 37 Place a disc in the middle of the tray with the label side facing upward; and gently push it down until the disc clicks into place while holding the bottom of the tray with the other hand. When the optical disc drive tray is out, be sure not to exert pressure on the tray as it may damage the tray or the disc drive. Close the tray by pushing it in gently.
Page 38 Using Your VAIO Computer Reading and Writing Optical Discs ™ Your computer plays and records CDs, DVDs, and Blu-ray Disc media, depending on the model you purchased. Check your specifications for the type of optical disc drive installed on your model. Use the table below to see which types of media your optical disc drive supports.
Page 39 Video Music Extra DVD±RW/ ±R DL/RAM Blu-ray Disc Combo Blu-ray Disc P Supports writing data to DVD-R discs compliant with DVD-R for General Version 2.0/2.1. Supports writing data to DVD-RW discs compliant with DVD-RW Version 1.1/1.2. The DVD±RW/RAM disc drive on your computer does not support the DVD-RAM cartridge. Use non-cartridge discs or discs with a removable cartridge. Writing data to single-sided DVD-RAM discs (2.6 GB) compliant with DVD-RAM Version 1.0 is not supported.
Page 40 When you buy pre-recorded or blank discs for use with your VAIO computer, be sure to read the notices on the disc package carefully to check both playback and recording compatibility with your computer's optical disc drives. Sony does NOT guarantee the compatibility of VAIO optical disc drives with discs that are not compliant with the official "CD,"...
Page 41 Notes on writing data to a disc ❑ Only use circular discs. Do not use discs in any other shape (star, heart, card, etc.), as this may damage the optical disc drive. ❑ Do not strike or shake your computer while the optical disc drive is writing data to a disc. ❑...
Page 42: Playing Cds
Playing CDs To play an audio CD Insert a disc into the optical disc drive. If nothing appears on the desktop, click Start, All Programs, and the desired CD software to play the CD. If the Audio CD window appears, click to select an option. Copying Files to CDs To copy files to a disc Insert a recordable disc into the optical disc drive.
Page 43: Playing Dvds
Playing DVDs To play a DVD Close all running software applications. Insert a DVD into the optical disc drive. If nothing appears on the desktop, click Start, All Programs, and the desired DVD software to play the DVD. For instructions on how to use the software, see the help file included with your DVD software. Copying Files to DVDs To copy files to a disc Close all running software applications.
Page 44: Playing Blu-Ray Disc Media
Playing Blu-ray Disc Media To play a Blu-ray Disc media Close all running software applications. Insert a Blu-ray Disc media into the optical disc drive. If nothing appears on the desktop, click Start, All Programs, and the desired Blu-ray Disc software to play the disc. For instructions on how to use the software, see the help file included with your software.
Page 45: Using The Tv Function
Using the TV Function Your computer has a hybrid TV tuner board installed along with the Microsoft Windows Vista Home Premium operating system which includes the Windows Media Center that enables TV program viewing, recording, and playback. The hybrid TV tuner supports the following broadcasts: ❑...
Page 46 To connect your computer to land-based (terrestrial) or cable TV services The appearance of the TV coaxial cable and the VHF/UHF input port may vary in some countries or areas. Connect one end of a TV coaxial cable (supplied) (1) to the VHF/UHF input port (3)on the computer. Connect the other end of the cable to your TV wall outlet/cable service access (2).
Page 47: Using The Remote Commander
Using the Remote Commander A remote commander is supplied with your computer for using a wide variety of AV related software applications, including Media Center. ✍ For information on the BRAVIA remote control, see the manual that came with your BRAVIA TV. Before you use the remote commander Before using the remote commander, you need to insert the supplied AA manganese batteries to enable communication between the computer and the remote commander.
Page 48 Insert the supplied two AA batteries into the remote commander. Put the battery cover back on the remote commander and slide it in the reverse direction of the arrow illustrated above until the cover clicks into place. ✍ If the remote commander does not operate properly, you may need to replace the batteries. When the remote commander is not going to be used for an extended period of time, remove the batteries to avoid possible damage from battery leakage.
Page 49 Locating buttons on the remote commander ✍ Illustrated above is the English remote commander as an example. Using Your VAIO Computer Pause X button Press to pause media playback. Press again to resume playback. Stop x button Press to stop media playback or TV recording session. Forward M button Press to fast-forward media at three speeds.
Page 50 Guide button Press to view the TV program guide for your area. Alphanumeric buttons Press to select specific channels or enter text. (Press ENTER or OK to activate the channel selection.) CLEAR button Press to backspace and delete entered text. Teletext TV program mode buttons Red button Press to jump to the red shortcut link in teletext TV program mode.
Page 51: Setting Up Windows Media Center
Using Your VAIO Computer Setting up Windows Media Center The first time you launch Windows Media Center, the setup wizard will appear. To configure the TV tuner, click Custom setup and follow the on-screen instructions. In the Optional Setup window, click Configure tuners, TV signal, and Guide and follow the on-screen instructions.
Page 52 Controlling your computer and BRAVIA TV ("BRAVIA" Sync) If you have a Sony BRAVIA TV with the Control for HDMI function, connecting your computer and BRAVIA TV with an HDMI cable makes additional control features available with the computer's remote commander and the BRAVIA remote control.
Page 53 Using the computer's remote commander to simultaneously turn on the computer and the BRAVIA TV (One-Touch Play) When your computer and BRAVIA are off, you can press one of the following buttons on the computer's remote commander to turn both on and start Windows. ✍...
Page 54 ✍ You can press the sleep button on your wireless keyboard or the power button on the computer to turn on both your computer and BRAVIA. When your computer is in Sleep mode, you can press any key on your keyboard to turn on your BRAVIA. In case you have unplugged and re-plugged the HDMI cable, make sure that your computer and BRAVIA are properly connected by turning on the computer with the standard procedure before using the One-Touch Play feature.
Page 55 In such a case, try another code. Changes to this signal setting for the TV volume control may not work on some TVs. Sony assumes no liability for the controllability.
Page 56: Using The Memory Stick
Using the Memory Stick Memory Stick is a compact, portable, and versatile IC recording media especially designed for exchanging and sharing digital data with compatible products, such as digital cameras, mobile phones, and other devices. Because it is removable, it can be used for external data storage.
Page 57 For the latest information about the Memory Stick, visit the Memory Stick web site at http://www.memorystick.com/en/. Your computer has been tested and found compatible with Sony branded Memory Stick with capacity of up to 16 GB that are available as of May 2008.
Page 58 Inserting a Memory Stick To insert a Memory Stick Slide open the front panel door with your fingertip. Locate the Memory Stick slot (page Hold the Memory Stick with the arrow facing upward and pointing toward the slot. Carefully slide the Memory Stick into the slot until it clicks into place. The Memory Stick is automatically detected by your system and the contents on the Memory Stick are displayed.
Page 59 To view the contents on the Memory Stick Click Start and Computer to open the Computer window. Double-click the Memory Stick icon to view the list of data files saved in the Memory Stick. To format a Memory Stick The Memory Stick has been formatted in the factory default setting and is ready for use. If you want to reformat the media with your computer, follow these steps.
Page 60 Click Start. Follow the on-screen instructions. It may take time to format the Memory Stick depending on the media type. Using Your VAIO Computer...
Page 61 Removing a Memory Stick Do not remove the Memory Stick while the Media Access indicator light is lit. If you do, you may lose data. Large volumes of data may take time to load, so make sure the indicator is unlit before removing the Memory Stick. To remove a Memory Stick Check that the Media Access indicator light is unlit.
Page 62: Using The Sd Memory Card
Using the SD Memory Card Your computer is equipped with an SD memory card slot. You can use this slot to transfer data among digital cameras, camcorders, music players, and other audio/video devices. ✍ The SD memory card slot is located behind the front panel door. You need to open this door before accessing the slot. Using Your VAIO Computer...
Page 63: Sd Memory Card
❑ SDHC memory card ❑ MultiMediaCard (MMC) For the latest information on compatible memory cards, see Sony Support Information support web site. Your computer has been tested and found compatible only with major memory cards available as of May 2008. However, not all memory cards that meet the same specifications as the compatible media are guaranteed of compatibility.
Page 64: Inserting An Sd Memory Card
Inserting an SD Memory Card To insert an SD memory card Slide open the front panel door with your fingertip. Locate the SD memory card slot Hold the SD memory card with the arrow facing upward and pointing toward the slot. Carefully slide the SD memory card into the slot until it clicks into place.
Page 65 Removing an SD Memory Card Do not remove an SD memory card while the Media Access indicator light is lit. If you do, the card or its data may become damaged. To remove an SD memory card Check that the Media Access indicator light is unlit. Firmly grasp the extended part of the SD memory card.
Page 66: Using The Internet
Using Your VAIO Computer Using the Internet To use the Internet, you need to connect an external modem device, for example a USB telephone modem, an xDSL modem, or a cable modem, to your computer. For the detailed instructions on connection setups and modem configuration, see the manual that came with your modem.
Page 67: Using Wireless Lan (Wlan)
Using Wireless LAN (WLAN) Using the Sony Wireless LAN (WLAN), all your digital devices with built-in WLAN function communicate freely with each other through a network. A WLAN is a network in which a user can connect to a Local Area Network (LAN) through a wireless (radio) connection.
Page 68 Using Your VAIO Computer The IEEE 802.11b/g standard is a wireless LAN standard, using the 2.4 GHz bandwidth. The IEEE 802.11g standard provides high-speed communications, faster than the IEEE 802.11b standard. The IEEE 802.11a standard is a wireless LAN standard, using the 5 GHz bandwidth. The IEEE 802.11n draft standard is a wireless LAN standard, using the 2.4 or 5 GHz bandwidth.
Page 69 Connecting the Wireless LAN Antenna To use the wireless LAN functionality on your computer, you must connect the supplied wireless LAN antenna to your computer. To connect the wireless LAN antenna Screw the wireless LAN antenna cable (1) counterclockwise into the WLAN ANT port (2) on the back of your computer. Be sure to turn the cable plug counterclockwise so as not to damage the WLAN ANT port.
Page 70 Using Your VAIO Computer ✍ For better reception, if needed, you may mount the wireless LAN antenna to a wall using the supplied screw.
Page 71: Communicating Without An Access Point (Ad-Hoc)
Using Your VAIO Computer Communicating without an Access Point (Ad-hoc) An ad-hoc network is a network in which a LAN is created only by the wireless devices themselves, with no other central controller or access point. Each device communicates directly with other devices in the network. You can set up an ad-hoc network easily at home.
Page 72 To communicate without an access point (ad-hoc) The IEEE 802.11n draft standard, using the 2.4 or 5 GHz bandwidth, is not available on ad-hoc networks. Turn on the WLAN switch. Click Start and Control Panel. Click View network status and tasks under Network and Internet. Click Set up a connection or network on the left pane.
Page 73 Using Your VAIO Computer Communicating with an Access Point (Infrastructure) An infrastructure network is a network that extends an existing wired local network to wireless devices by providing an access point (not supplied). The access point bridges the wireless and wired LAN and acts as a central controller for the wireless LAN network.
Page 74 To connect to a wireless network Make sure an access point is set up. See the manual that came with your access point for more information. Turn on the WLAN switch. Click Start and Control Panel. Click View network status and tasks under Network and Internet. Click Manage wireless networks.
Page 75 Using Your VAIO Computer Stopping Wireless LAN Communication To stop wireless LAN communication Turn off the WLAN switch. Turning off the wireless LAN function while accessing remote documents, files, or resources may result in data loss.
Page 76: Using Peripheral Devices
Using Peripheral Devices Using Peripheral Devices You can add functionality to your VAIO computer by using the various ports on the computer. ❑ Selecting Display Modes (page 77) ❑ Using the Multiple Monitors Function (page 78) ❑ Connecting a Universal Serial Bus (USB) Device (page 80) ❑...
Page 77: Selecting Display Modes
Selecting Display Modes You can select which display to be used as the primary monitor when two displays (TV, desktop monitor, etc.) are connected to your computer. If you want to work on both displays at the same time, see Using the Multiple Monitors Function information.
Page 78: Using The Multiple Monitors Function
Using the Multiple Monitors Function The Multiple Monitors function allows you to distribute portions of your desktop across separate displays. For example, if you have a display connected to the HDMI OUT port and another connected to the monitor port, two displays can function as a single desktop.
Page 79 To use the Multiple Monitors function Click Start and Control Panel. Click Adjust screen resolution under Appearance and Personalization. Right-click the number 2 monitor and select Attached. Click OK. At the confirmation prompt, click Yes. ✍ Additionally, you can set the display colors and resolution for each display and customize the Multiple Monitors function. Using Peripheral Devices...
Page 80: Connecting A Universal Serial Bus (Usb) Device
Connecting a Universal Serial Bus (USB) Device ✍ You need to slide open the front panel door to access the USB ports on the front. Connecting a USB Mouse To connect a USB mouse Choose the USB port (1) you prefer to use. Plug the USB mouse cable (2) into the USB port.
Page 81: Connecting A Usb Floppy Disk Drive
Connecting a USB Floppy Disk Drive You can purchase a USB floppy disk drive and connect it to your computer. To connect a USB floppy disk drive Choose the USB port (1) you prefer to use. Plug the USB floppy disk drive cable (2) into the USB port. Your USB floppy disk drive (3) is now ready for use.
Page 82: Disconnecting A Usb Floppy Disk Drive
Disconnecting a USB floppy disk drive You can disconnect a USB floppy disk drive when your computer is on or off. Disconnecting the drive when the computer is in Sleep mode may cause the computer to malfunction. To disconnect a USB floppy disk drive ✍...
Page 83: Connecting A Printer
Connecting a Printer You can connect a Windows-compatible printer to your computer to print documents. Connecting a Printer Using the USB Port You can connect a USB printer compatible with your version of Windows to the computer. ✍ You need to slide open the front panel door to access the USB ports on the front. To connect a printer using the USB port Plug the power cord (1) of your printer into an AC outlet.
Page 84: Connecting An I.link Device
Connecting an i.LINK Device Notes on connecting i.LINK devices ❑ Your computer is equipped with an i.LINK port, which you can use to connect an i.LINK device, such as a digital video camcorder. ❑ The i.LINK port on your computer does not supply power to an external device. If the external device requires external power, be sure to connect it to a power source.
Page 85: Connecting A Digital Video Camcorder
On Sony digital video cameras, ports labeled DV Out, DV In/Out, or i.LINK are i.LINK-compatible. The Sony digital video camcorder shown here is an example. Your digital video camcorder may need to be connected differently. You cannot access the pictures stored on a Memory Stick when using an i.LINK connection.
Page 86: Connecting To A Network (Lan)
Connecting to a Network (LAN) You can connect your computer to 100BASE-TX/10BASE-T-type networks with an Ethernet network cable. Connect one end of a network cable (not supplied) to the network (Ethernet) port on the back of the computer and the other end to your network. For detailed settings and devices needed to connect to the network, ask your network administrator.
Page 87 Using Peripheral Devices Do not plug a telephone cable into the network (LAN) port on your computer. If the network (LAN) port is connected to one of the telephone lines mentioned below, high electric current to the port may cause damage, overheating, or fire.
Page 88: Customizing Your Vaio Computer
Customizing Your VAIO Computer This section briefly describes how to change the main settings of your VAIO computer. Among other things, you will learn how to use and customize the look of your Sony software and utilities. ❑ Setting the Password (page 89) ❑...
Page 89: Setting The Password
Setting the Password Use one of the BIOS functions to set the password. Once you have set the password, you will be prompted to enter the password after the VAIO logo appears to start your computer. The power-on password allows you to protect your computer from unauthorized access. Adding the Power-on Password The power-on password is provided to protect your computer from unauthorized access.
Page 90 To add the power-on password (machine password) Turn on the computer. Press the F2 key when the VAIO logo appears. The BIOS setup screen appears. If not, restart the computer and press the F2 key several times when the VAIO logo appears.
Page 91 To add the power-on password (user password) Make sure you set the machine password before setting the user password. Turn on the computer. Press the F2 key when the VAIO logo appears. The BIOS setup screen appears. If not, restart the computer and press the F2 key several times when the VAIO logo appears.
Page 92: Changing/Removing The Power-On Password
Changing/Removing the Power-on Password To change or remove the power-on password (machine password) Turn on the computer. Press the F2 key when the VAIO logo appears. The BIOS setup screen appears. If not, restart the computer and press the F2 key several times when the VAIO logo appears.
Page 93 To change or remove the power-on password (user password) Turn on the computer. Press the F2 key when the VAIO logo appears. The BIOS setup screen appears. If not, restart the computer and press the F2 key several times when the VAIO logo appears.
Page 94: Setting Up Your Computer With Vaio Control Center
Setting Up Your Computer with VAIO Control Center The VAIO Control Center utility allows you to access system information and to specify preferences for system behavior. To use VAIO Control Center Click Start, All Programs, and VAIO Control Center. Select the desired control item and change the settings. Once finished, click OK.
Page 95: Using The Power Saving Mode
Customizing Your VAIO Computer Using the Power Saving Mode In addition to the normal operating mode, your computer has a distinct power saving mode called Sleep mode. Using Normal Mode This is the normal state of the computer when it is in use. The green power indicator light is lit in this mode.
Page 96: Using Sleep Mode
Using Sleep Mode Sleep mode temporarily suspends the entire system operations for lower power consumption. The orange power indicator light is lit in this mode. Turn off your computer if you do not intend to use it for a long period of time. To activate Sleep mode Click Start, the arrow next to the Lock button, and Sleep.
Page 97 If the computer is not used for a certain period of time, it will enter Sleep mode. To modify this, you can change the Sleep mode settings. To change the Sleep mode settings Click Start, Control Panel, Hardware and Sound, and Power Options. Click Change plan settings under the current power plan.
Page 98: Upgrading Your Vaio Computer
Upgrading Your VAIO Computer Upgrading Your VAIO Computer Your VAIO computer and memory modules use high precision components and electronic connectors technology. To avoid invalidation of the warranty during your product warranty period, we recommend that: ❑ You should contact your dealer to install a new component. ❑...
Page 99: Adding And Removing Memory
Adding and Removing Memory If you want to expand the functionality of your computer, you can increase the amount of memory by installing optional memory modules. Before you upgrade your computer's memory, read the notes and procedures in this section. Notes on adding/removing memory modules ❑...
Page 100 ❑ Do not open the memory module package before you are ready to change the module. The package protects the module from ESD. ❑ Use the special bag supplied with the memory module or wrap the module in aluminum foil to protect it from ESD. ❑...
Page 101: Removing And Installing A Memory Module
Removing and Installing a Memory Module To change or add a memory module Shut down the computer and disconnect all peripheral devices. Unplug the computer and wait about an hour until the computer cools down. Unscrew the screws (indicated by the arrows below) on the bottom of the computer and remove the memory module compartment cover.
Page 102 Remove the currently installed memory module as follows: ❑ Pull the latches in the direction of the arrows (1). The memory module is released. ❑ Make sure that the memory module tilts up and then pull it out in the direction of the arrow (2). Remove the new memory module from its packaging.
Page 103 Upgrading Your VAIO Computer Slide the memory module into the memory module slot and push it in until it clicks into place. Do not touch any other components on the motherboard. Be sure to insert the connector edge of the memory module into the slot while aligning the notch on the module with the small projection in the open slot.
Page 104 Replace the memory module compartment cover and tighten the screws on the bottom of the computer. Connect a power source and turn on the computer. Upgrading Your VAIO Computer...
Page 105: Viewing The Amount Of Memory
Viewing the Amount of Memory To view the amount of memory Turn on the computer. Click Start, All Programs, and VAIO Control Center. Double-click the System Information icon under the System Information folder. You can view the amount of system memory. If the additional memory does not appear, repeat the installation procedure and restart the computer.
Page 106: Precautions
Precautions Precautions This section describes safety guidelines and precautions to help you protect your VAIO computer from potential damage. ❑ Using the Power Source (page 107) ❑ Handling Your Computer (page 108) ❑ Handling Floppy Disks (page 111) ❑ Handling Discs (page 112) ❑...
Page 107: Using The Power Source
❑ Unplug your computer from the AC outlet if you are not planning to use the computer for a long period of time. ❑ Make sure that the AC outlet is easily accessible. ❑ Use the AC adapter supplied with your computer or genuine Sony products. Do not use any other AC adapter as it may cause a malfunction.
Page 108: Handling Your Computer
Handling Your Computer ❑ Clean the cabinet with a soft cloth, which is dry or lightly moistened with a mild detergent solution. Do not use any type of abrasive pad, scouring powder, or solvent such as alcohol or benzine, as these may damage the finish of your computer.
Page 109 ❑ Do not place any objects on top of your computer as it may cause: ❑ Degradation in performance of the computer ❑ Discolorations on the surface of the computer ❑ Physical injuries if an object falls; or falls off the computer and breaks ❑...
Page 110 ❑ Your computer uses high-frequency radio signals and may cause interference to radio or TV reception. If this occurs, relocate the computer a suitable distance away from the set. ❑ Use only specified peripheral equipment and interface cables. Otherwise, problems may occur. ❑...
Page 111: Handling Floppy Disks
Handling Floppy Disks ❑ Do not open the shutter manually and touch the internal components of the floppy disk. ❑ Keep floppy disks away from magnets. ❑ Keep floppy disks away from direct sunlight and other sources of heat. ❑ Keep floppy disks away from any liquid. Do not let them get wet. When you are not using your floppy disk, always remove it from the floppy disk drive and put it in a storage case.
Page 112: Handling Discs
Handling Discs ❑ Do not touch the surface of the disc. ❑ Fingerprints and dust on the surface of a disc may cause read errors. Always hold the disc by its edges and central hole, as shown below: ❑ Proper care of the disc is essential to its continuous reliability. Do not use solvents (such as benzine, thinner, alcohol, commercially available cleaners, or anti-static spray) which may cause damage to the disc.
Page 113: Using Headphones
Precautions Using Headphones Preventing hearing damage – Avoid using headphones at high volume. Hearing experts advise against continuous, loud and extended play. If you experience a ringing in your ears, reduce the volume or discontinue use.
Page 114: Handling The Memory Stick
Handling the Memory Stick ❑ Do not touch the Memory Stick connector with your finger or metallic objects. ❑ Use only the adhesive label supplied with the Memory Stick as a label. ❑ Do not bend, drop, or expose the Memory Stick. ❑...
Page 115: Handling The Hard Disk
Handling the Hard Disk The hard disk drive has a high storage density and reads or writes data in a short time. However, it can be easily damaged by mechanical vibration, shock, or dust. Although the hard disk drive has the internal safety device to prevent losing data due to mechanical vibration, shock or dust, you should be careful when handling your computer.
Page 116: Updating Your Computer
Updating Your Computer Be sure to install the latest updates on your computer with the following software applications so that the computer can run more efficiently. ❑ Windows Update Click Start, All Programs, and Windows Update and then follow the on-screen instructions. ❑...
Page 117: Troubleshooting
Troubleshooting Troubleshooting This section describes how to solve common problems you might encounter when using your VAIO computer. Many problems have simple solutions. Try these suggestions before contacting VAIO-Link. ❑ Computer (page 118) ❑ System Security (page 124) ❑ Networking (page 125) ❑...
Page 118: Computer
❑ Remove any extra memory modules you may have installed since purchase. ❑ Check that you are using the supplied Sony AC adapter. For your safety, use only the genuine Sony AC adapter, which is supplied by Sony for your VAIO computer.
Page 119 What should I do if a BIOS error appears when I turn on my computer? If the message "Press <F1> to resume, <F2> to setup" appears at the bottom of the screen, follow these steps: Press the F2 key. The BIOS setup screen appears. If not, restart the computer and press the F2 key several times when the VAIO logo appears.
Page 120 What should I do if the power indicator lights but my screen remains blank? ❑ Make sure the proper input for your display (HDMI-compatible TV or computer display connected to the HDMI OUT or monitor port) is selected. ❑ Make sure your display (HDMI-compatible TV or computer display connected to the HDMI OUT or monitor port) is turned ❑...
Page 121 What should I do if my computer or software stops responding? ❑ If your computer stops responding while a software application is running, press the Alt+F4 keys to close the application window. ❑ If the Alt+F4 keys do not work, click Start, the arrow next to the Lock button, and Shut Down to turn off your computer. ❑...
Page 122: Why Doesn't My Computer Enter Sleep Mode
Why doesn't my computer enter Sleep mode? Your computer may become unstable if the operating mode is changed before the computer completely enters Sleep mode. To restore your computer to normal mode Close all open programs. Click Start, the arrow next to the Lock button, and Restart. If your computer does not restart, press the Ctrl+Alt+Delete keys and click the arrow next to the Shut down button and Restart.
Page 123: How Do I Check The Volume Of The Recovery Partition
What should I do if my game software does not work or it keeps crashing? ❑ Check the web site of the game if there are any patches or updates to download. ❑ Make sure you have installed the latest video driver. ❑...
Page 124: System Security
System Security How can I protect my computer against security threats, such as viruses? The Microsoft Windows operating system is preinstalled on your computer. The best way to protect your computer against security threats, such as viruses, is to download and install the latest Windows updates regularly. You can get important Windows updates by doing the following: Your computer must be connected to the Internet to download the updates.
Page 125: Networking
Networking What should I do if my computer cannot connect to a wireless LAN access point? ❑ Connection capability is affected by distance and obstructions. You need to place your computer away from obstructions or move any access point you may be using closer to the computer. ❑...
Page 126: Why Is The Data Transfer Speed Slow
❑ Wireless LAN communication uses divided frequency bands known as channels. Third-party wireless LAN access point channels may be preset to different channels from Sony devices. ❑ If you are using a wireless LAN access point, see connectivity information contained in the manual that came with your access point.
Page 127 Troubleshooting Why does the network connection stop when I change the encryption key? Two computers with the wireless LAN function may lose a peer-to-peer network connection if the encryption key is changed. You can either change the encryption key back to the original profile or re-enter the key on both computers so the key matches.
Page 128: Optical Discs
Optical Discs Why does my computer freeze when I try to read a disc? The disc that your computer is trying to read may be dirty or damaged. Follow these steps: Press the Ctrl+Alt+Delete keys and click the arrow next to the Shut down button and Restart to restart the computer. Remove the disc from the optical disc drive.
Page 129 What should I do if I cannot play a disc properly on my computer? ❑ Make sure the disc is inserted into the optical disc drive with the label facing upward. ❑ Make sure the necessary program(s) is installed according to the manufacturer's instructions. ❑...
Page 130 Click Device Manager on the left pane. The Device Manager window appears with a listing of your computer's hardware devices. If an "X" or an exclamation point appears on the listed device, you may need to enable the device or reinstall the drivers.
Page 131 What should I do if I cannot play Blu-ray Disc media? You may not be able to play some Blu-ray Disc contents on your computer. To play such contents, download and install the latest updates for WinDVD BD using VAIO Update. To download and install the updates on the computer, it must be connected to the Internet.
Page 132: Display
Display What should I do if my TV screen remains blank? ❑ Make sure that both power cords of your computer and TV are securely plugged into power sources. ❑ Make sure that your computer and TV are properly connected. ❑...
Page 133: How Do I Run Windows Aero
What should I do if the screen of my TV that is connected to the HDMI OUT port remains blank? ❑ Unplug the HDMI cable once and plug it back. ❑ Your TV may not be HDCP compliant. Be sure to use an HDCP compliant TV. ❑...
Page 134: Printing
Printing What should I do if I cannot print a document? ❑ Make sure your printer is on, and the printer cable is securely connected to the ports on the printer and your computer. ❑ Make sure your printer is compatible with the Windows operating system installed on your computer. ❑...
Page 135: Microphone
Troubleshooting Microphone What should I do if my microphone does not work? If you are using an external microphone, make sure the microphone is turned on and is properly plugged into the microphone jack on your computer. How can I prevent microphone feedback? Microphone feedback occurs when the microphone receives the sound from a sound output device, such as a speaker.
Page 136: Speakers
Speakers What should I do if my external speakers do not work? ❑ If you are using a program that has its own volume control, make sure the volume control is properly set. See the program's help file for more information. ❑...
Page 137: Keyboard
Keyboard What should I do if the keyboard configuration is wrong? The language layout of your wireless keyboard is labeled on the packaging box. If you choose a different regional keyboard when you complete the Windows setup, the key configuration will be mismatched. To change the keyboard configuration, follow these steps: Click Start and Control Panel.
Page 138: Touch Pad
Touch Pad What should I do if the touch pad does not work? ❑ Make sure that a mouse is not connected to your computer. ❑ If the pointer does not move while a software application is running, press the Alt+F4 keys to close the application window. ❑...
Page 139: Floppy Disks
Floppy Disks Why doesn't the Safely Remove Hardware icon appear on the taskbar when the drive is connected? Your computer does not recognize the floppy disk drive. First, make sure the USB cable is properly connected to the USB port. If you need to secure the connection, wait a few moments for the computer to recognize the drive. If the icon still does not appear, follow these steps: Close all programs that are accessing the floppy disk drive.
Page 140: Audio/Video
✍ i.LINK is a trademark of Sony Corporation used only to designate that a product contains an IEEE 1394 connection. The procedure to establish an i.LINK connection may vary, depending on a software application, an operating system, and a compatible i.LINK device. Not all products with an i.LINK connection can communicate with each other.
Page 141: How Do I Change The Sound Output Device
How do I change the sound output device? If you do not hear sound from the device connected to the HDMI OUT port or the OPTICAL OUT port, you need to change the device for sound output. Close all open programs. Click Start and Control Panel.
Page 142 How do I output the Dolby Digital or DTS sound through an S/PDIF or HDMI-compatible device? To output the Dolby Digital or DTS sound from a disc through an S/PDIF or HDMI-compatible device connected to your computer, follow these steps: Click Start and Control Panel.
Page 143: Memory Stick
Use of recorded music requires permission from the copyright holders. Sony is not responsible for music files that cannot be recorded from a CD or downloaded from other sources. Can I copy images from a digital camera using Memory Stick? Yes, and you can view video clips that you have recorded with Memory Stick-compatible digital cameras.
Page 144: Peripherals
Peripherals What should I do if I cannot connect a USB device? ❑ If applicable, check the USB device is turned on and using its own power supply. For example, if you are using a digital camera, check if the battery is charged. If you are using a printer, check if the power cable is connected properly to the AC outlet.
Page 145: Support Options
Support Options Support Options This section contains information on where to go for answers to questions about your VAIO computer. ❑ Sony Support Information (page 146) ❑ e-Support (page 147)
Page 146: Sony Support Information
Internet. Using a personalized account, you can log your technical queries with ease. ❑ VAIO-Link help lines: Before contacting VAIO-Link by telephone, try to solve the problem by reading the printed and non- printed documentation. ❑ Visit the other Sony web sites: ❑ http://www.club-vaio.com if you want to know more about VAIO and become part of the growing VAIO community.
Page 147: E-Support
Support Options e-Support What is e-Support? If you have searched our user guides and web site (http://www.vaio-link.com) but have not found an answer to your question or issue, use e-Support to solve it. Our e-Support Web Portal is an interactive web site on which you can submit any technical query you may have regarding your computer and receive answers from our dedicated support team.
Page 148 Support Options Can I submit my questions at any time? Yes, you can submit your questions 24/7, but keep in mind that our e-Support Team can only answer your queries from Monday till Friday between 8 am and 6 pm. Is there a cost involved for using e-Support? No, this is a free of charge service offered to all registered VAIO customers.
Page 149: Trademarks
Ready 2007 and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the U.S. and other countries. i.LINK is a trademark of Sony used only to designate that a product contains an IEEE 1394 connection. Roxio Easy Media Creator is a trademark of Sonic Solutions.
Page 150 Trademarks SDHC Logo is a trademark. ™ MultiMediaCard is a trademark of MultiMediaCard Association. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. All other names of systems, products, and services are trademarks of their respective owners. In the manual, the ™ or ® marks are not specified.
