- Page 1 Introduction Connecting Operating (hardware) SITRANS F Sofware installation SITRANS F M Verificator Operating (software) User guideline Operating Instructions Diagnostics and troubleshooting Technical Data 07/2019 A5E45134218-AB...
- Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
-
Page 3: Table Of Contents
Customer DB (database) .......................22 Printer settings ........................24 Saving files on a PC.......................26 Opening files saved on a PC....................27 Deleting files in the SITRANS F M Verificator................28 Renaming files in the SITRANS F M Verificator..............29 User guideline.............................31 On site verification instructions ....................31 Diagnostics and troubleshooting ........................33... - Page 4 Table of contents SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB...
-
Page 5: Introduction
A short circuit to earth will damage the Verificator. NOTICE Use in a domestic environment This Class A Group 1 equipment is intended for use in industrial areas. In a domestic environment this device may cause radio interference. SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB... - Page 6 Introduction SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB...
-
Page 7: Connecting
When removing the SITRANS F M MAGFLO transmitter, please be aware that some ® terminals may carry main voltage. Figure 2-1 Compact mounted transmitter Figure 2-2 IP67 transmitter on wall mounting bracket SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB... - Page 8 Once verification is completed, reinstall the transmitter. All application specific settings are restored after verification. Note The Verificator requires no external power supply during verification and it automatically establishes the correct power supply for each installation. SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB...
-
Page 9: Operating (Hardware)
Display device no. which are unique for this Verificator only. Software version and date for when the Verificator shall be returned for re-calibration. Display no. of test cycles (number of verifications). Device no. xxxxx Software ver. x.xx ReCal yyyy/mm/dd Test cycles xxxxx SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB... - Page 10 Press GO to initiate the verification Files can be renamed when a PC is connected. For more information on file names, refer to Renaming files in the SITRANS F M Verificator (Page 29). Select file name: ->...
- Page 11 Is only displayed if the SENSORPROM unit is not installed, or defect. ® Press GO to finish the verification test. The SENSORPROM unit can be checked with the SENSORPROM programmer . ® ® Verification finished Transmitter: -100% SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB...
-
Page 12: Verificator Software - Sensor - Insulation
Press ESC to quit. E2: Sensor failed Insulation fault Value xxxxxx xxx Press ESC to quit Sensor/system passed the insulation test Verification continues automatically. I2: Sensor Passed Insulation OK Please wait ..SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB... -
Page 13: Verificator Software - Sensor - Magnetism
Is only displayed if the measured „fingerprint“ is out of range. Could be caused by a defective Verificator. See "On site trouble shooting". Sensor Failed Sensor: Selftest Fail Press ESC to cancel SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB... - Page 14 Is displayed if the gathered readings are unstable. Verification finish Sensor: Selftest Fail Unstable reading Press GO to continue Magnetism test finished successfully, sensor passed the test. Sensor passed Magnetism OK Please wait ..SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB...
-
Page 15: Verificator Software - Installation Passed
Insulation OK Press GO to continue For magnetism test use the "up" or "down" arrows to select magnetism test only. Select test ->magnetism test only<- Press GO to start Press ESC to cancel SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB... - Page 16 Is displayed if the measured values are out of range. Verification finish Sensor: Selftest Fail Out of range Press GO to continue Is displayed if the gathered readings are unstable. Verification finish Sensor: Selftest Fail Unstable reading Press GO to continue SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB...
-
Page 17: Sofware Installation
Uninstall the Verificator software programme and all other programs or applications on your PC that may use or control the serial port to which you connect the Verificator unit. Then reinstall and run the Verificator software. SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB... - Page 18 Sofware installation 4.1 Installation of PC software SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB...
-
Page 19: Operating (Software)
Double click the SITRANS F M MAGFLO icon to run the SITRANS F M MAGFLO Verificator program. The following is displayed: Select the communication port connected to the RS 232 cable/USB adaptor and click "OK". Communication commences and after a short time the following is displayed: SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB... - Page 20 Click "One" if you only want to transfer the selected file or click "All" to transfer all files. The files will now be transferrred from the Verificator to the PC. The "Progress Indicator" bar indicates that data transfer is in progress. SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB...
-
Page 21: Viewing And Printing Data
If you select an empty file and click "View File", you will receive the following message "File does not contain data". The data from the selected file is displayed in the "Verification Certificate" display as shown in the following example. SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB... -
Page 22: Customer Db (Database)
If you press the buttom "customer DB" it is possible to create, save and edit your specific customer information e.g. name, address etc. The information can then be printed on the certificate. SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB... - Page 23 Click "Print Preview" or "Print" to print the report. On next page you will find an example of a printed SITRANS F M MAGFLO Verification Certificate. SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB...
-
Page 24: Printer Settings
Operating (software) 5.4 Printer settings Printer settings In the printer settings you can choose to remove the Siemens logo by removing the mark, if the "Verification Certificate" is to be printed on special paper. SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB... - Page 25 Operating (software) 5.4 Printer settings SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB...
-
Page 26: Saving Files On A Pc
Select a file for which data has been retrieved from the Verificator, then click "Save File". The following is displayed: If you want to save the file under a different folder, select a new folder under "Save in". SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB... -
Page 27: Opening Files Saved On A Pc
When the menu for selection of COM port shows up, click "cancel" and click "OK" for continuing in unconnected mode in the next menu. Select a file location in the above directory in which you want to open the saved file. Then click "Load File". SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB... -
Page 28: Deleting Files In The Sitrans F M Verificator
Operating (software) 5.7 Deleting files in the SITRANS F M Verificator Select the required file and click "Open". The required file will now be copied to the choosen location and can be opened by clicking "View File". Deleting files in the SITRANS F M Verificator Connect the Verificator to a PC as described under Data transfer. -
Page 29: Renaming Files In The Sitrans F M Verificator
Operating (software) 5.8 Renaming files in the SITRANS F M Verificator ● Select a file to delete. ● Click "Delete File(s)". Click "One" if you only want to delete the selected file or click "All" if you want to delete all files in the Verificator. - Page 30 Operating (software) 5.8 Renaming files in the SITRANS F M Verificator Enter the new name in the field "New File Name" and click "OK". File names can be up to 16 characters long. The new file name will be transferred to the Verificator.
-
Page 31: User Guideline
● Switch On the power to the flowmeter. ● The verification is now complete.The data is stored in the Verificator and can be accessed by using the Verificator software on a PC. SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB... - Page 32 User guideline 6.1 On site verification instructions SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB...
-
Page 33: Diagnostics And Troubleshooting
● Media temperature inside the limits of 0° - 60°C• No foreign magnetic material in the sensor tube ● A correct earthing installation of sensor and transmitter ● PCB terminal centre screw mounted in compact installation and a wire connected from PE to ground in the terminal box SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB... - Page 34 Table 7-1 Spare part ordering Description Order number Adaptor for IP67 transmitters FDK:083F4165 Adaptor for 19" transmitters FDK:083F4166 WARNING Important Please check that the earth wire has been mounted to the connection box. SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB...
-
Page 35: Re-Calibration
● Exchange of adapter cable incl. connector ALL-IN-ONE 9LA1110-8QT10-9BA0 ● STANDARD package package ● ADVANCED Suitcase and cable package Note Please use the VSR procedure for sending in equipment to the factory. SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB... - Page 36 Diagnostics and troubleshooting 7.2 Re-calibration SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB...
-
Page 37: Technical Data
PC with at least 486 processor and Windows 95, 98, NT or XP CE-confirmity ● Emission: EN 50081-1 ● Immunity: EN 50082-2 Traceability Calibration at Siemens Hagenau (COFRAC acredited laborato‐ ries) traceable to national and international standards Recalibration Mandatory recalibration with one year interval to maintain tracea‐ bility... - Page 38 Technical Data SITRANS F M Verificator Operating Instructions, 07/2019, A5E45134218-AB...
