Melal Part cal return path to the chassis. Any current measured must not exceed 0.5mA. Reverse the instrument power cord plug in the out- ohmmeter let and repeat the test. See Fig. 1-1. Fig. 1-2 Insulation Resistance Test Samsung Electronics...
Page 3
(5) antenna wiring. Always inspect in all areas tinuously and new instructions are issued whenev- for pinched, out-of-place, or frayed wiring, Do not er appropriate. change spacing between a component and the printed-circuit board. Check the AC power cord for damage. Samsung Electronics...
Page 4
Components i-enti- fied by shading, by( ) or by ( ) in the circuit dia- gram are important for safety or for the characteris- tics of the unit. Always replace them with the exact replacement components. Samsung Electronics...
Page 5
(6) Do not remove a replacement ESD device from its protective package until immediately before your are ready to install it.(Most replacement ESD devices are packaged with leads electrically short- ed together by conductive foam, aluminum foil or comparable conductive materials). Samsung Electronics...
Page 6
◆ Be sure to put on a wrist strap grounded to the sheet. ◆ Be sure to lay a conductive sheet made of copper etc. Which is grounded to the table. Samsung Electronics...
Page 7
Pick-up. (See Fig. 1-4) 4) Disassembly the Pick-up. Note : If the assembly and disassembly are not done in correct sequence, the Pick-up may be damaged. PICK-UP ASS'Y SOLDER LAND 4 POINTS SHORT SOLDER LAND 2 POINTS SHORT Fig. 1-4 Samsung Electronics...
Note : Reassembly in reverse order. 2-1-1 Top Cabinet Removal 1) Remove 3 Screws Œ on the back Top Cabinet. 2) Lift up the Top Cabinet in direction of arrow. Œ 3 SCREWS Fig. 2-1 Top Cabinet Removal Samsung Electronics...
Page 9
Note : If Tray Œ doesn’t open, insert a Screw driver ¨ into the Emergency hole ˇ (as shown in detailed draw- ing) and then push it in the direction of arrow “B”. Open Tray manually. Œ TRAY ´ DOOR-TRAY "A" "B" ˇ EMERGENCY HOLE ¨ SCREW DRIVER <Side View> Fig. 2-2 Door-Tray Removal Samsung Electronics...
Page 11
2-1-4 Ass’y Deck Removal 1) Disconnect Flat-Cable,Connect-Wire from DCN1, DCN2 on Main PCB. 2) Remove 3 Screws Œ from the Ass’y Deck and lift it up. Œ 3 SCREWS DECK-ASS'Y FLAT-CABLE CONNECT-WIRE MAIN PCB DCN1 DCN2 Fig. 2-4 Ass’y Deck Removal Samsung Electronics...
Page 12
1) Remove 2 Screws Œ and lift up the Jack PCB ´. 2) Remove 3 Screws ˇ and lift up the Main PCB ¨. Œ 2 SCREWS ´ JACK PCB ˇ 3 SCREWS ¨ MAIN PCB Fig. 2-5 Main PCB, Jack PCB Removal Samsung Electronics...
Page 13
All manuals and user guides at all-guides.com Disassembly and Reaasembly 2-2 PCB Location JACK PCB MAIN PCB KEY PCB * DVD-M30x SERIES/M40x SERIES MODELS ONLY Fig. 2-6 PCB Location Samsung Electronics...
Page 14
MAIN PCB DCN1 ˇ ¨ CONNECT-WIRE (HCN1) HOUSING PCB MAIN PCB DCN2 ˆ Ø MAIN PCB JACK PCB DCN1 ∏ ” PCN1 MAIN PCB JACK PCB PCNS1 ’ ˝ FCN1 MAIN PCB JACK PCB CN2-S Fig. 2-7 Connector Diagram Samsung Electronics...
Page 15
MAIN PCB DCN1 ˇ ¨ CONNECT-WIRE (HCN1) HOUSING PCB MAIN PCB DCN2 ˆ Ø MAIN PCB JACK PCB DCN1 ∏ ” PCN1 MAIN PCB JACK PCB PCNS1 ’ ˝ KCN1 KEY PCB JACK PCB Fig. 2-8 Connector Diagram Samsung Electronics...
Page 16
3) Pull the Tray Disc ¨ to disassemble , while simultaneously pushing 2 Stoppers ˆ (left, right) in the direction arrow “C”, “D”. ˆ STOPPER ˇ SLIDER HOUSING "C" ¨ TRAY DISC "B" "A" Œ SCREW DRIVER "D" ´ EMERGENCY HOLE ˆ STOPPER Fig. 2-9 Tray Disc Removal Samsung Electronics...
Page 17
2) Lift down the Assy P/U Deck ˇ while simultaneously pushing 2 Hooks ¨, ˆ in the direction of arrow “A”, “B”. ¨ HOOK "A" ˆ HOOK "B" <Assembly Point> Œ DCN2 ´ DCN3 SLIDER HOUSING ˇ ASSY- P/U DECK Fig. 2-10 Assy P/U Deck Removal 2-10 Samsung Electronics...
All manuals and user guides at all-guides.com Exploded Views and Parts List 4-1 Cabinet Assembly 100 (DECK-DVD MECHA) 601 (ASSY-PCB-MAIN) CN1B 602 (ASS'Y-PCB-JACK) S.N.A. (CHASSIS-REAR) S.N.A. (CABINET-BOTTOM) S.N.A. : Service Not Available DVD-M103/M105/M105B/M107/M107G/M108/M109 DVD-M101/M104G DVD-M201 DVD-M203/M205/M205G/M207/M207G DVD-M300 UT01 DVD-M301/M305/M307/M307G/M403/M405/M407/M407G/M409 (Normal) (Joy-Stick) (Jog-Shuttle) VOL. CON SLOW MODE...
Page 32
ASSY FRONT CABINET Refer to table below ASSY-DOOR Refer to table below KNOB-VOLUME Refer to table below KNOB-JOG AH61-00534B FOOT-FRONT;DVD-M101,ABS 94HB,-,SILVER,4M AH65-00003A CLAMP-CORD POWER;DVD-M101,NYLON 66,-,-,- AH97-00563A ASSY-DVD DECK;DP-7,MILLENO,1LD(SEM) AH97-00714B ASSY-DVD DECK;DP-7,MILLENO,2LD Refer to table below CABINET TOP 6003-000275 SCREW-TAPTITE;BH,+,B,M3,L10,BLK ,SWCH101 6003-000276 SCREW-TAPTITE;BH,+,B,M3,L10,ZPC(YEL),SWC...
Page 33
All manuals and user guides at all-guides.com Exploded Views and Parts List Regional Country Models Regional Code Assy-Deck UT01 Europe France DVD-M105 AH97-00639B AH97-00642E AH64-00933G AH92-00986C AH92-00987D AH59-00092B VD-M105B AH97-00639G AH97-00642D AH64-00933A AH92-00986C AH92-00987D AH59-00092A DVD-M205 AH97-00639A AH97-00642E AH64-00933G AH92-00986C AH92-00987D AH59-00092B DVD-M305...
Page 34
All manuals and user guides at all-guides.com Exploded Views and Parts List Regional Country Models Regional Code Assy-Deck UT01 Europe Hungary DVD-M105 AH97-00639B AH97-00642E AH64-00933G AH92-00986C AH92-00987D AH59-00092B DVD-M205 AH97-00639A AH97-00642E AH64-00933G AH92-00986C AH92-00987D AH59-00092B DVD-M305 AH97-00640A AH97-00643E AH64-11306Z AH64-00971E AH64-00933G AH92-00986D AH92-00987E...
Page 35
All manuals and user guides at all-guides.com Exploded Views and Parts List 4-2 Deck Assembly H107 H105 H106 H103 H102 H101 H240 H108 DCN1B H104 H250 H241 H211 H203 H207 H208 H202 H201 H204 H206 H205 H210 H209...
All manuals and user guides at all-guides.com 6. Block Diagrams 6-1 DVD-M101/M103/M105/M107/M108/M109/M201/203/M205/M207/M300/M301/M305/M307/M409 ; RCA Jack Output DECK ASS'Y (DP-7) MIC4 2K EEPROM Remote Control FLT Display MIC1 FIC1 MIC2 8M EPROM (TMP91C219F) (uPD780232) Main Controller Front Controller MIC3 1M SDRAM Spindle/Sied/Tray Motor Pick-up &...
Page 49
Post Filter (KS1454) Audio DAC Servo + DSP Post Filter Decoder Post Filter AC3 & MPEG 5.1 Compo Post Filter CVBS Yout Y/B/Pb Post Filter Cout Video VIC1 Encoder (MM1540) (4DAC) R/Pr C/R/Pr Post Filter B/Pb Comp/G/Y Post Filter Samsung Electronics...
Page 50
SIC1 Actuator & Motor Driver (KS1454) Servo + DSP Decoder CVBS Compo Post Filter AC3 & VIC1(MM1540) MPEG 5.1 Yout 6dB AMP Y/B/Pb Post Filter Cout Video Encoder C/R/Pr (4DAC) Post Filter Comp/G/Y Post Filter SCIC1(MM1443) 6dB AMP Samsung Electronics...
Page 51
Post Filter Cout Decoder AC3 & SCJ1 (TV) MPEG 5.1 DVD_RGB SCIC2 VIC1 CVBS (MC14053BD) (1540) A L/R Video Encoder CVBS (4DAC) A L/R DVD_L/R SCJ1 (VCR) SCIC1 DVD_Y CVBS (MM1443) DVD_CVBS A L/R CVBS A L/R VCR RGB Samsung Electronics...
Page 53
All manuals and user guides at all-guides.com PCB Diagrams 7-1 Main Samsung Electronics...
Page 54
All manuals and user guides at all-guides.com PCB Diagrams 7-2 Jack Samsung Electronics...
Page 55
All manuals and user guides at all-guides.com PCB Diagrams 7-3 Key (ONLY FOR DVD-M300) (ONLY FOR DVD-M301/M305/M307/M307G/M403/M405/M407/M407G/M409) 7-4 Deck 7-5 Housing 1 LD 2 LD Samsung Electronics...
All manuals and user guides at all-guides.com 8. Wiring Diagrams 8-1 DVD-M101/M103/M104G/M105/M105B/M107/M107G/M108/M109/M201/M203/M205/M205G/M207/M207G Samsung Electronics...
Page 57
All manuals and user guides at all-guides.com Wiring Diagrams 8-2 DVD-M300/M301/M305/M307/M307G/M403/M405/M407/M407G/M409 Samsung Electronics...
All manuals and user guides at all-guides.com Schematic Diagrams 9-4 AV-Decoder/Main-Micom/Key (Only for DVD-M10x/M20x Series models) Samsung Electronics...
All manuals and user guides at all-guides.com Schematic Diagrams 9-11 Front-Micom/VFD Display (Only for DVD-M3xx/M4xx Series models) 9-12 Samsung Electronics...
