Summary of Contents for Samsung DVD-M104

  • Page 1 AH68-00723F...

  • Page 2: Precautions Precautions

    Precautions 1. Setting up Ensure that the mains supply in your house complies whit that indicated on the identification sticker located at the back of your play. Install your player horizontally, on a suitable base (furniture), with enough space around it for ventilation (7~10cm). Make sure the ventilation slots are not covered. Do not stack other, or heavy devices on top over the player.

  • Page 3: Table Of Contents

    Before You Start Accessories Remote Control User’s Manual If remote doesn’t operate Install Batteries in the Remote Open the battery cover on the • Check the polarity + - of the batteries back of the remote. (Dry-Cell) • Check if the batteries are drained. Insert two AA batteries.

  • Page 4: General Features

    General Features Excellent Sound Various On-Screen Menu Functions Dolby Digital, a technology You can select various developed by Dolby Laboratories provides languages(Audio/Subtitle) and screen crystal clear sound reproduction. angles while enjoying movies. Screen Repeat Video with MPEG-2 compression technology. You can repeat a song or movie simply by Both regular and widescreen(16:9) pictures pressing the REPEAT button.

  • Page 5: Description-Front Panel

    Description-Front Panel Front Panel Controls STANDBY / ON • When the unit is first plugged in, the indicator lights. When STANDBY/ON is pressed on again, the light goes out and the player is turned on. DISC TRAY • Load the disc here. DISPLAY •...

  • Page 6: Tour Of The Remote Control

    Tour of the Remote Control Tour of the Remote Control DVD Function Buttons DVD POWER Button PLAY/PAUSE Button • Begin/Pause disc play. NUMBER Buttons SKIP Buttons STEP Button • Use to skip the title, chapter, or track. • Advances play one frame at a time. RETURN Button ZOOM Button •...

  • Page 7: Choosing A Connection

    Choosing a Connection The following show examples of connections commonly used to connect the DVD player with a TV and other components. Before Connecting the DVD Player • Always turn off the DVD player, TV, and other components before you connect or disconnect any cables.

  • Page 8: Playing A Disc

    Playing a Disc Before Play • Turn on your TV and press the TV/VIDEO button to select the video mode. • Turn on your Audio System and select AUX, CD or DVD. After plugging in the player, the first time you press the DVD POWER button, this screen comes up : If you want to select the language, press a NUMBER button.

  • Page 9: Using The Search & Skip Functions

    Using the Search & Skip Functions During play, you can search quickly through a chapter or track or use the skip function to jump to the next selection. Searching through a Chapter or Track During play, press the FWD or REV SEARCH button on the remote.

  • Page 10: Repeat Play

    Repeat Play Repeat the current track, chapter, title, a chosen section (A-B), or all of the disc When playing a DVD Press the REPEAT button on the remote. Repeat screen appears. Select Chapter, Title or A-B using the LEFT/RIGHT button. - A-B Repeat •...

  • Page 11: S.fit Play

    S.FIT Play Screen Fit Play Press Screen FIT button on remote control. - Allows you to eliminate the black bars in the top and bottom of the screen when a movie is playing in the Widescreen format(16:9). - Screen Fit will not work when Zoom mode is active. (you can not remove the black bars in screen) However, Zoom mode will work when Screen Fit is active.

  • Page 12: Slow Repeat Play

    Slow Repeat play This feature allows you slowly repeat scenes containing sports, dancing, musical instruments being played etc. so you can study them more closely. When playing a DVD Press the PLAY/PAUSE button. Press the F/SEARCH button to choose the play speed between 1/8X, 1/4X, and 1/2X of normal.

  • Page 13: Selecting The Audio Language

    Selecting the Audio Language You can select a desired language quickly and easily with the AUDIO button. Using the AUDIO button Press the AUDIO button. Use the UP/DOWN button to select the desired language on a DVD. - The audio languages are represented by abbreviations.

  • Page 14: Changing The Camera Angle

    Changing the Camera Angle When a DVD contains multiple angles of a particular scene, you can select the Angle function. Using the ANGLE button Press the ANGLE button to see if an ANGLE ( mark is present at the upper right hand corner of the screen.

  • Page 15: Using The Zoom And 3D Sound Functions

    Using the Zoom & 3D Sound Functions Using the Zoom Function (DVD/VCD) During play or pause mode, press the ZOOM button on the remote. A square will be displayed on screen. Use the UP/DOWN or LEFT/RIGHT button to select the part of the screen you want to zoom in on.

  • Page 16: Setting Up The Language Features

    Setting Up the Language Features If you set the player menu, disc menu, audio and subtitle language in advance, they will come up automatically every time you watch a movie. Using the Player Menu Language With the unit in Stop mode, press the SETUP button.

  • Page 17: Setting Up The Parental Control

    Setting Up the Parental Control The Parental Control function works in conjunction with DVDs that have been assigned a rating - which helps you control the types of DVDs that your family watches. There are up to 8 rating levels on a disc. With the unit in Stop mode, press SETUP button.

  • Page 18: Setting Up The Display Options

    Setting Up the Display Options With the unit in Stop mode, press the SETUP button. Use the UP/DOWN button to select DISPLAY OPTIONS. Then press the ENTER button. Use the UP/DOWN button to select the desired item. Then press the LEFT/RIGHT button. TV Aspect Depending on the type of television you have, you may want to adjust the screen setting (aspect ratio).

  • Page 19: Specifications

    *Total Harmonic Distortion 0.004 % *: Nominal specification • Samsung Electronics Co., Ltd reserves the right to change the specifications without notice. • Weight and dimensions are approximate. 79mm This Samsung product is warranted for the period of twelve (12) months from the original date of purchase, against defective materials and workmanship.
  • Page 20 Unless there is national legislation to the contrary, the rights under this warranty are the consumers sole rights and Samsung, its subsidiaries and distributors shall not be liable for indirect or consequential loss or any damage to records, compact discs, videos or audio taper or any other related equipment or material.
