EFIC206-B-TG-SILVER
.................................................................................... 2
.............................................................. 3
.............................................................. 5
... . . . . . . . .................................................. 7
.................................................................... 8
.................................................... 9
.............................................................. 13
............................................................................. 14
Advertisement
Related Manuals for Frigidaire EFIC206-B-TG-SILVER
Summary of Contents for Frigidaire EFIC206-B-TG-SILVER
-
Page 1: Table Of Contents
EFIC206-B-TG-SILVER Introduction ..................2 Important Safeguards .............. 3 Know Your Ice Maker ............... 5 Control Panel Operation ............7 Use Your Ice Maker ..............8 Cleaning and Maintenance ............ 9 Technical Parameters .............. -
Page 2: Introduction
INTRODUCTION Ice maker plugged in Pour the water into the water tray... -
Page 3: Important Safeguards
IMPORTANT SAFEGUARDS When using an electrical appliance, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury, including the following: Read all instructions before using. 2. Remove all packing material and carefully check your ice maker to ensure it is in good condition and that there is no damage to the ice maker or power cord and plug. - Page 4 IMPORTANT SAFEGUARDS 15. Metal sheet or other electric object are not allowed to be inserted into the appliance to avoid fire and short circuit. 16. Do not use outdoors. 17. Never clean with scouring powders or hard implements. 18. Please keep the instruction manual. 19.
-
Page 5: Know Your Ice Maker
KNOW YOUR ICE MAKER 6. Ice shovel 1. Transparent lid 7. Upper cover 2. Water tray 8. Bullet evaporator 3. Ice shovel board 9. Rear housing 4. Ice basket 10. Front housing 5. Button... - Page 6 KNOW YOUR ICE MAKER FEATURES Quick ice making time can help you enjoy ice in a short time. It Prompts when the ice is full and water is insufficient. The machine can make bullet shaped ice. 9 pcs ice can be made in eight minutes. 1.
-
Page 7: Control Panel Operation
CONTROL PANEL OPERATION A. Ice Full (Ice full alarm) B. Add Water (Water shortage alarm) C. Ice Making (Ice making alarm) 1) Plug in the power, the "ICE MAKING" indicator flashes, and the machine will start the deicing function. Press the power button, the "ICE MAKING"... -
Page 8: Use Your Ice Maker
USE YOUR ICE MAKER Step 1 Open the lid and take out the basket and add water to the reservoir. Note: There is a maximum scale MAX in the reservoir. The water should not exceed the MAX position. If the water exceeds the maximum scale MAX, you need to open the bottom drain plug, release the excess water, and cover with a transparent cover. -
Page 9: Cleaning And Maintenance
CLEANING AND MAINTENANCE Clean the inner liner, ice collecting tray, water box, ice shovel and evaporator frequently. When cleaning, unplug the unit and remove the ice cubes. Use a diluted solution of water and vinegar to clean the inside and the outside surface of the Ice maker. Do not spray Ice maker with chemicals or diluted agents such as acids, gasoline or oil. - Page 10 CLEANING AND MAINTENANCE TROUBLESHOOTING Please note, if a power failure occurs due to disconnection of the power cord, or the power button has been pushed off during an ice making cycle, small ice chips may formed and lodge in the automatic shovel causing it to jam.
- Page 11 CLEANING AND MAINTENANCE Unplug the power to take out the ice which blocking All indicators Water tray is blocked the tray, then plug the power twinkle by ice cube and press the POWER simultaneously button, the machine will restart 3mins later. The machine has been working, but Replace the solenoid valve...
- Page 12 CLEANING AND MAINTENANCE Correct Disposal of this product This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources.
-
Page 13: Technical Parameters
TECHNICAL PARAMETERS Model number : EFIC206-B-TG-SILVER Daily ice output : 12kg/24hours Ice storage capacity : 1.5L/600g Refrigerant : R600a Water tank capacity : 1.5L Power : 120V~/60Hz Power consumption : 120W N.W : 7.75KG G.W : 8.6KG Max overall dimensions:(LxWxH):... -
Page 14: Warranty Card
WARRANTY CARD To make a warranty claim, do not return this product to the store. Please email support@curtiscs.com or call 1-800-968-9853. 1 Year Warranty This product is warranted to be free from defects in material and workmanship for a period of one (1) year from the date of original purchase. During this period, your exclusive remedy is repair or replacement of this product or component found to be defective, at our option;...
