Dual fuel light oil/ gas burners progressive two-stage or modulating operation gas side/two-stage light oil side
Hide thumbs Also See for RLS 160/M MX:
Table of Contents

Advertisement

Quick Links

Installation, use and maintenance instructions
Dual fuel light oil/ gas burners
GB
Progressive two-stage or modulating operation gas side/
two-stage light oil side
CODE
20147789
20147790
20147887
20147888
MODEL
RLS 160/M MX
RLS 160/M MX
RLS 160/M MX
RLS 160/M MX
TYPE
781T
781T
781T
781T
20148049 (3) - 11/2020
