TopPage
In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig-
inal condition and only parts identical to those specified should be used.
CAUTION .......................................................... i
[1]
SPECIFICATIONS......................................... 1-1
[1]
OPERATION MANUAL.................................. 2-1
[1]
DIMENSIONS................................................ 3-1
[1]
REMOVING OF MAJOR PARTS................... 4-1
[1]
ADJUSTMENT PROCEDURE ...................... 5-1
[2]
[1]
TROUBLESHOOTING TABLE ...................... 6-1
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with specified
ones for maintaining the safety and performance of the set.
SERVICE MANUAL
LCD COLOR TELEVISION
MODELS
CONTENTS
[1]
BLOCK DIAGRAM................................. . ........7-1
[2]
OVERALL WIRING DIAGRAM .............. . ........7-3
[1]
GRAM .................................................... . ........8-1
[2]
SCHEMATIC DIAGRAM ........................ . ........8-2
[1]
BOARD .................................................. . ........9-1
[2]
BOARD .................................................. . ........9-2
[3]
[4]
[5]
BOARD .................................................. . ......9-17
LC-42BX5H/M/X
No. SY6X2LC42BX5M
LC-42BX5H
LC-42BX5M
LC-42BX5X
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
