SERVICE MANUAL
This model is classified as a
Service Manual describes replacement parts for the green product. When repairing this green
product, use the part(s) described in this manual and
For (*1) and (*2), refer to
© TOSHIBA CORPORATION
file://C:\Program Files\zeus\js\!!fcover.html
LCD Color Television
22AV605PG
green product
(*1), as indicated by the underlined serial number. This
GREEN PRODUCT PROCUREMENT
Ver. 2.00
lead-free solder
(*2).
LEAD-FREE
and
Page 1 of 1
SOLDER.
10.08.2016
Advertisement
Table of Contents
Related Manuals for Toshiba 22AV605PG
Summary of Contents for Toshiba 22AV605PG
- Page 1 Service Manual describes replacement parts for the green product. When repairing this green product, use the part(s) described in this manual and lead-free solder (*2). GREEN PRODUCT PROCUREMENT LEAD-FREE SOLDER. For (*1) and (*2), refer to © TOSHIBA CORPORATION file://C:\Program Files\zeus\js\!!fcover.html 10.08.2016...
-
