How To Check This Installation Procedure; Before Connection; Symbols In The Illustration; Installing The License - Canon imagePRESS Server G100 Installation Procedure

Before Connection > Installing the license

How to Check this Installation Procedure

Symbols in the Illustration

The frequently-performed operations are described with symbols in this procedure.
Screw
1x
Unused Parts
Packaged Item
Install
Harness Connector
(Common for Guides and Clamps)
1x
1x 1x
Connect
Remove
Install
Power
Check the sound Check visually
ON OFF
Before Connection > Installing the license
1x 1x
1x
Tighten Loosen
Remove
Power Cord
1x
Connect
Disconnect
Disconnect
Check Push Cleaning
F-1-1

Before Connection

Installing the license

Be sure to take out the license certificate included in the package and obtain the license key
in advance. Make the setting of the EFI Controller by the Web browser in the Control Panel.
Register the license by the following procedure.
1) Log in to the host machine as an administrator (mode).
Factory default password is as follows.
• System administration division ID: 7654321
• System administration password: 7654321
CAUTION:
When [System Manager Information Settings] is set, it is required to log in as a system
manager in accordance with instructions from the user administrator.
2) Select Settings/Registration > [Management Settings] > [License/Other] > [Register
License].
3) Enter the license key of the Web browser.
Example: 8888-7777-6666-5555-4444-3333
4) Press [Start] > [OK].
5) Turn OFF and then ON the main power switch to determine the registration.
