Summary of Contents for Rinnai Q Series
- Page 1 | HSNRQ25B | HSNRQ35B | HSNRQ50B | HSNRQ70B | HSNRQ80B Indoor | HINRQ25B | HINRQ35B | HINRQ50B | HINRQ70B | HINRQ80B Outdoor | HONRQ25B | HONRQ35B | HONRQ50B | HONRQ70B | HONRQ80B Q Series Split Type Wall Mounted Air Conditioner Installation Manual...
- Page 2 OH&S requirements This appliance must be installed, maintained and removed only by an Authorised Person. For continued safety of this appliance it must be installed and maintained in accordance with the manufacturer’s instructions. REFRIGERANT Rinnai Split AC IM...
-
Page 3: Table Of Contents
Connecting Vapour / Liquid Pipes To Indoor & Outdoor Units ���������������������������������������������������������������������� 13 Air Purging & Leakage Test �������������������������������������������������������������������������������������������������������������������������� 14 Evacuation Vacuum Method / Leak Test ������������������������������������������������������������������������������������������������������ 14 Adding Refrigerant for Longer Line Length �������������������������������������������������������������������������������������������������� 14 Final Checklist �������������������������������������������������������������������������������������������������������������������������������������������������� 15 Contacts Rinnai Split AC IM... -
Page 4: Warnings And Important Information
For safety and warranty purposes, appliances that may be damaged or incorrect MUST NOT be installed or operated under any circumstances. Installation of damaged or incorrect appliances may contravene local government regulations. Rinnai disclaims any liability or responsibility whatsoever in relation to the installation or operation of damaged or incorrect appliances. - Page 5 Make sure that the area has been made safe by having suitable ventilation and is free from ignition sources before charging or releasing the charge of R32. Model HSNRQ25B HSNRQ35B HSNRQ50B HSNRQ70B HSNRQ80B Standard Charge (g) 1000 1350 1350 1600 Minimum Floor Area (m 0.62 0.96 1.74 1.74 2.45 Rinnai Split AC IM...
- Page 6 The table below indicates the temperature ranges the air conditioner can be operated within. MODE Cool Mode Heat Mode Dry Mode Room Temperature > 17°C < 27°C > 17°C Outdoor Temperature -15°C ~ 52°C -15°C ~ 24°C -15°C ~ 52°C Rinnai Split AC IM...
-
Page 7: Installation General
11. Outdoor unit air discharge and protective grille (on front of unit) WEIGHTS & DIMENSIONS Model HSNRQ25B HSNRQ35B HSNRQ50B HSNRQ70B HSNRQ80B Indoor 12.0 14.0 14.0 14.0 Weight (kg) Outdoor 27.0 30.5 47.0 47.5 61.0 Indoor 1100 1100 1100 Dimensions (mm) 1010 Outdoor Rinnai Split AC IM... -
Page 8: Location
Ø6.35 HSNRQ80B Ø15.88 Ø6.35 The outdoor unit is charged for interconnecting pipe lengths of up to 10m. Additional refrigerant is to be added for lengths above 10m. IMPORTANT Indoor Outdoor unit unit Outdoor Indoor unit unit Rinnai Split AC IM... -
Page 9: Installation
Drill a Ø70mm wall penetration through the wall with a 2° to 4° fall to the outside wall. INSIDE 2° to 4° fall OUTSIDE Drain Pipe Connect the drain pipe to the drain hose outlet of the indoor unit, Bind the joint with PVC insulation tape (not supplied). Rinnai Split AC IM... -
Page 10: Electrical Connections
NOTE 2. Unscrew the rubber plug from the alternate drainage discharge connection point. 3. Clip the drainage hose into the alternate discharge connection point. 4. Screw the rubber plug into the unused drainage discharge connection point. Rinnai Split AC IM... -
Page 11: Outdoor Unit
Secure the electrical cable(s) and power cable onto the control board with the cable clip. Connect the cables as shown on the drawing below. Wiring HONRQ80B ONLY All Other Outdoor Models cover Re-install the wiring cover. Rinnai Split AC IM... -
Page 12: Dred Connection (Optional)
For the purposes of drainage a barbed elbow is also supplied. Insert the barbed elbow into the drainage point of the outdoor unit as shown. Drainage of the condensate must conform with all local regulations and municipal building codes including local OH&S requirements. IMPORTANT Rinnai Split AC IM... -
Page 13: Refrigerant Pipes
Ø 12.7 mm Ø 1/2" 55 Nm Ø 15.88 mm Ø 5/8" 75 Nm Indoor Unit Outdoor Unit Vapour pipe Liquid pipe Ensure that both the connections and the refrigerant pipes are wrapped with insulation material. CAUTION Rinnai Split AC IM... -
Page 14: Air Purging & Leakage Test
It is very easy to overcharge, take caution in charging Vacuum refrigerant liquid and keep your eye on the scales to avoid Pump CAUTION overcharging the unit. Take care not to discharge refrigerant into the atmosphere during installation, re-installation, repair or service. Rinnai Split AC IM... -
Page 15: Final Checklist
No cooling or heating Is the end user fully aware of the operating procedure? Incorrect operation If you have answered no to any of the above, you must check and correct before appliance hand-over to customer. Rinnai Split AC IM... - Page 16 Help Line. Rinnai recommends that this appliance be serviced every 3 years. With our policy of continuous improvement, we reserve the right to change, or discontinue at any time, specifications or designs without notice. Rinnai Split AC Q Series IM R32 Issue 6 - May 2019...
