SERVICE MANUAL
• LBT-LX7 / LX8 is composed following models.
As for the service manual, it is issued for each component model,
then, please refer to it.
COMPONENT MODEL NAME FOR LBT-LX7/LX8
COMPACT DISC DECK
RECEIVER SYSTEM
SPEAKER SYSTEM
SPECIFICATIONS
General
Power requirements
European model:
230 V AC, 50 / 60 Hz
Mexican model:
120 V AC, 50 / 60 Hz
Australian models:
230 - 240 V AC, 50 / 60 Hz
Other models:
120 V, 220V, or 230 - 240 V AC,
50 / 60 Hz
Adjustable with voltage selector
Power consumption
(LBT-LX7)
220 watts
(LBT-LX8)
300 watts
Supplied accessories
AM loop antenna (1)
Remote RM-SR5B (1)
R6 (size AA) batteries (2)
FM wire antenna (1)
Speaker cords (2)
Design and specifications are subject to change without notice.
9-929-076-11
LBT-LX7/LX8
LBT-LX7
LBT-LX8
HCD-LX7
HCD-LX8
SS-LX7
SS-LX8
Sony Corporation
Home Audio Division Company
• Abbreviation
CND : Canadian model
EA
: Saudi Arabia model
SP
: Singapore model
PARTS LIST
Part No.
Description
ACCESSORIES & PACKING MATERIALS
********************************
1-475-572-41 COMMANDER, STANDARD (RM-SR5B)
1-501-374-11 ANTENNA, LOOP
1-501-659-41 ANTENNA (FM) (LBT-LX8)
1-501-804-11 ANTENNA (FM) (LBT-LX7)
1-775-512-21 CORD, SPEAKER
4-227-074-11 MANUAL, INSTRUCTION (ENGLISH)
4-227-074-21 MANUAL, INSTRUCTION (FRENCH) (EA)
4-227-074-31 MANUAL, INSTRUCTION (SPANISH) (AR, MX)
4-227-074-41 MANUAL, INSTRUCTION (FRENCH, SPANISH) (AEP)
4-227-074-51 MANUAL, INSTRUCTION ( GERMAN, DUTCH, SWEDISH) (AEP)
4-227-074-61 MANUAL, INSTRUCTION (ITALIAN, PORTUGUESE) (AEP)
4-227-074-71 MANUAL, INSTRUCTION (POLISH, RUSSIAN) (CIS)
4-227-074-81 MANUAL, INSTRUCTION (ARABIC) (EA)
4-227-074-91 MANUAL, INSTRUCTION (CHINESE)(SP, MY)
4-227-075-11 MANUAL, INSTRUCTION (CZECH) (CIS)
4-227-075-21 MANUAL, INSTRUCTION (HUNGARIAN) (CIS)
4-227-075-31 MANUAL, INSTRUCTION (GREEK ) (CIS)
4-227-075-41 MANUAL, INSTRUCTION (TURKISH) (CIS)
4-228-574-11 MANUAL, INSTRUCTION(ENGLISH, FRENCH, GERMAN, SPANISH,
DUTCH, SWEDISH, ITALIAN, PORTUGUESE, POLISH, RUSSIAN,
DANISH, FINNISH, HUNGARIAN, CZECH, GREEK, TURKISH)(SS-LX7)
4-210-254-01 CUSHION (FOOT)
4-991-151-31 COVER, BATTERY (FOR RM-SR5B)
COMPACT Hi-Fi STEREO SYSTEM
AEP Model
UK Model
LBT-LX7
E Model
LBT-LX7/LX8
Australian Model
LBT-LX8
MX : Mexican model
AR
: Argentine model
MY : Malaysia model
Remark
2000B001670-1
Printed in Japan ©2000.2
Published by Quality Assurance Dept.
