Identifying Controls

Front of the TV
Remote control
sensor within about
23 feet (7 meters) in
front of the TV set
Power indicator
(on: red, off: no light)
C.A.T.S. sensor
Plasma C.A.T.S. (Contrast Automatic
Tracking System) (p. 38)
Note
The TV consumes a small amount of electric energy even when turned off.
Do not place any objects between the TV remote control sensor and remote control.
Switches TV On or Off (Standby)
Viewing from SD Card (p. 26-29)
Lights the buttons for 5 seconds
Press again to turn off the button
lights
Changes the input mode (p. 34)
Switches to input terminal
that has "GAME" label (p. 34)
Displays Main Menu (p. 37)
Displays Sub Menu (p. 18, 39)
Colored buttons
(used for various functions)
(for example, p. 16, 27, 28, 32, 45)
Volume up/down
Sound Mute On/Off
Changes aspect ratio (p. 19, 59)
Switches to previously viewed channel
or input modes
External equipment operations
(p. 45)
TV controls/indicators
3D Eyewear transmitter
USB 1/2 connector
Selects channels
in sequence
Volume up/down
Displays the Main
Menu
Changes the input
mode
Chooses Menu and
Submenu entries
Remote control
Back of the TV
HDMI Input 4 connector
Video Input 2 connector
POWER button
Closed caption On/Off (p. 18)
Selects Audio Mode for TV viewing
(p. 18)
Exits from Menu screen
VIERA Link menu (p. 44-45)
Displays VIERA CAST screen (Home
screen) (p. 30)
Displays VIERA TOOLS (p. 21)
Selects/OK/Change
Returns to previous menu
Channel up/down
Displays or removes the channel
banner (p. 19)
Operates the Favorite channel list
function (p. 19)
Numeric keypad to select any channel
(p. 18) or press to enter alphanumeric
input in menus
(p. 16-18, 32, 34, 36, 44, 46, 48, 50, 52,
55, 56)
Use for digital channels (p. 18)
SD card slot
13
