POLYCOM
®
Quick Start Guide
The following figure displays the hardware features on the VVX 501 and VVX 601 business media
phones. The table lists each numbered feature shown in this figure.
VVX 501 & VVX 601 HARDWARE FEATURES
Feature
Reversible tab
Speaker
Dialpad
Security slot (on side)
USB Ports
For more information, visit epb.com/customer-support/business-support
or call 423-648-1500, option 2
VVX
501 & VVX
®
Secures the handset in the cradle when your phone stand is positioned at a high
angle. To secure the handset, remove the tab, reverse it so the protrusion points
up, and re-insert it. Then, position the handset so the protrusion on the tab fits
into the slot on the handset
Provides ringer and hands-free (speakerphone) audio output
Enables you to enter numbers, letters, and special characters. You can also use
the dialpad keys to select menu items that have index numbers
The connector on the left side of your phone that enables you to attach a laptop
cable lock to your phone so you can secure it to a desktop
Enable you to:
•
Attach a USB flash drive so you can record calls, update the background
picture on your phone, set up a screen saver, or use your phone as a digital
picture frame
•
Attach a USB headset
•
Attach a VVX Camera to the top-most port
601
®
Description
1
