FujiFilm Finepix 40i Quick Start Manual

Fujifilm finepix 40i: quick start
Hide thumbs Also See for Finepix 40i:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
I
USB Mass Storage Driver
I
Exif Viewer
I
DP Editor
I
Exif Launcher
I
Audio Downloading Software
Quick Start Guide
Thank you for purchasing these FUJIFILM products.
This Quick Start Guide provides you with a simple summary of how connect your PC
and camera via the USB ports and how to install the software provided in this package
on your personal computer (PC). Read this guide carefully to ensure that you use the
software correctly.
For detailed information on how to use the Exif Viewer and DP Editor software, refer to
the User's Guide on the enclosed CD-ROM.
BB11755-201(1)
E

Advertisement

Table of Contents
loading

Related Manuals for FujiFilm Finepix 40i

Summary of Contents for FujiFilm Finepix 40i

  • Page 1 Audio Downloading Software Quick Start Guide Thank you for purchasing these FUJIFILM products. This Quick Start Guide provides you with a simple summary of how connect your PC and camera via the USB ports and how to install the software provided in this package on your personal computer (PC).

  • Page 2: Important

    IMPORTANT Be sure to read this page before using the Software. NOTICE BEFORE OPENING THE PACKAGE OF CD-ROM PROVIDED BY FUJI PHOTO FILM CO., LTD., PLEASE READ THIS END USER LICENSE AGREEMENT CAREFULLY. ONLY IF YOU DO AGREE TO THIS AGREEMENT, YOU WILL BE ABLE TO USE THE SOFTWARE RECORDED ON THE CD-ROM.

  • Page 3: Table Of Contents

    The USB Driver does not provide remote photography functions. Exif Viewer Allows you to list the images on a digital camera or PC, print indexes of the images, view and print the images, and perform simple image processing operations. DP Editor Allows you to create print ordering information that can be used to obtain prints on printers that support DPOF (Digital Print Order Format).

  • Page 4: Installation On A Windows Pc

    Monitor Number of display colors: 65,536 or better NOTE • Connect the PC and digital camera directly using the USB cable. Connecting via USB hub is not guaranteed. • USB interface board is not guaranteed. • Windows 95 cannot be used.

  • Page 5: Windows 98

    Windows 98 6. The “Add New Hardware Wizard” dialog appears. Click [Next >]. NOTE If this Wizard doesn’t appear, update the USB driver (See P.23). 7. Select “Search for the best driver for your device (Recommended)” and click [Next >]. 8.

  • Page 6: Windows Millennium Edition

    Windows Millennium Edition 6. The “Add New Hardware Wizard” window opens. Click the [Next >] button. NOTE If this Wizard doesn’t appear, update the USB driver (See P.23). 7. When the “Select Other Driver” window opens, select USB Mass Storage in the \USBDRV \WIN98\USBS04CB.INF line on the CD-ROM drive and then click the...

  • Page 7: Installing The Enclosed Applications

    10. Select \USBDRV\WIN2KPRO on the CD-ROM drive and click the [Open] button. Click one of the icons on the left to simplify location selection. 11. Click the [OK] button in the location specification dialog box. 12. Check that UW2K04CB.INF has been detected and then click [Next >].
  • Page 8 DP Editor is a software utility for creating new DPOF files and is based on DPOF version 1.00. When you are using this software to edit DPOF files that were set up on a digital camera, some functions may not be available depending on the software version supported.

  • Page 9: Using The User's Guide

    9. Double-click the “Audiodl” folder on the CD-ROM. When the “Audiodl” folder window appears, double-click “Setup.exe”. 10. The Audio Downloading Software setup program starts up. Click the [Next >] button. When the window for selecting the installation destination appears, check the destination and then click the [Next >] button.

  • Page 10: Using The Software On Windows

    Mode dial to “Playback” mode. NOTE The media used should contain images shot using a FUJIFILM camera. 3. Connect the camera and PC using the USB cable. When the “Removable Drive” icon appears in the “My Computer”...

  • Page 11: Connecting The Camera To Your Pc And Downloading Mp3 Files

    6. To exit Exif Viewer, select “Exit” from the “File” menu or click the [Close] button in the main window. ✽ For more information on using Exif Viewer or DP Editor, refer to the User’s Guide (PDF document) on the CD-ROM. 7.

  • Page 12: Updating The Usb Driver On A Windows Pc

    7. Downloading the MP3 files: Click the [Transfer] button to download MP3 files registered in Audio Downloading Software to a SmartMedia (card) with ID. 8. Other functions: • To delete music (SVQ) files on a SmartMedia (card) with ID, select the music (SVQ) file from the file list and click the [Delete/Cancel] button.

  • Page 13: Uninstalling The Software On A Windows Pc

    NOTE If you cannot find USB Mass Storage in the “USB Controller” list, look under “Other devices”. 8. Select the “Driver” tab and click the [Update driver…] button. This launches the Upgrade Device Driver Wizard. 9. Select “Display a list of the known drivers for this device so that I can choose a specific driver”...

  • Page 14: Installation On A Macintosh

    : Amount required for installation: 60 MB minimum Amount required for operation: 110 MB minimum NOTE • Connect the Macintosh and digital camera directly using the USB cable. Connecting via USB hub is not guaranteed. • USB interface board is not guaranteed.
  • Page 15 1 Load the media into the camera, switch the camera on and set the Mode dial to “Playback” mode. NOTE Use media that contain photographs shot on a FUJIFILM digital camera. 2 Use the USB cable to connect the camera to the USB port on your Macintosh. NOTE •...

  • Page 16: Installing The Enclosed Applications

    DP Editor is a software utility for creating new DPOF files and is based on DPOF version 1.00. When you are using this software to edit DPOF files that were set up on a digital camera, some functions may not be available depending on the software version supported.

  • Page 17: Using The Software On A Macintosh

    Mode dial to “Playback” mode. NOTE Use media that contain photographs shot on a FUJIFILM digital camera. 3. Use the USB cable to connect the camera to your Macintosh. If a...

  • Page 18: Connecting The Camera To Your Macintosh And Downloading Mp3 Files

    Connecting the Camera to Your Macintosh and Downloading MP3 Files 1. Start up your Macintosh. 2. Load a SmartMedia (card) with ID into the camera, switch the camera on and set the Mode dial to “Playback” mode. 3. Use the USB cable to connect the camera to your Macintosh.

  • Page 19: Uninstalling The Software On A Macintosh

    Uninstalling the Software on a Macintosh NOTE Use this procedure only when the installed software is no longer required or when software installation fails. Uninstalling the USB Driver First, check that the digital camera is no longer connected. Then open the Extensions folder in the System folder on the hard disk and move the...

  • Page 20: Windows-Specific Problems

    I (Mac) Is the USB Driver active? Solution: Select “USB04CB_StorageShim” and “USB04CB_StorageDriver” in the Extensions Manager and restart your Macintosh. The PC hangs when I access the media. I (Win) When opening the Device Manager, there is a yellow “!” mark next to the driver in “Universal Serial Bus controllers”.
  • Page 21 When I install the driver, the “Could not find a driver for this device” message appears. I The installer cannot read the device driver due to a problem with your PC setup. Solution: Select “\USBDRV\WIN98” on the CD-ROM drive. When I install the driver, the “Could not find UMAS04CB.INF” message appears.

  • Page 22: Macintosh-Specific Problems

    Macintosh-specific Problems This message appeared when I connected the camera to my Macintosh. I Is the USB Driver installed? Solution: Install the driver on your Macintosh. When I connected the USB cable, Mac OS displayed the “Initialize disk?” message. I Is the media formatted? Solution: Disconnect the USB cable from the camera, insert the media into the camera and format the media.
  • Page 23 I get a message saying “Cannot find SmartMedia with ID in any drive.” I Is the camera switched on? Solution: Switch the camera on. I Is the camera set to USB connection mode? Solution: Some cameras have to be set to a particular mode (eg. Playback mode) for USB connection.
  • Page 24 MEMO MEMO...
  • Page 25 This brochure uses recycled paper. FGS - 002110 - FG Printed in Japan...

This manual is also suitable for:

Usb mass storage driverExif viewerDp editorExif launcherAudio downloading software
