P/N 900467-01 Rev. B 01/2019
DANGER
f i r e - p a r t s . c o m
WARNING: No not store gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance. An LP-cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or
property damage. Read the installation, operating and maintenance instructions thoroughly before install-
ing or servicing this equipment.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appli-
ance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
PFS
®
Report No. 10-87
WHEN USED AS AN OUTDOOR APPLIANCE
CARBON MONOXIDE WARNING
•
This appliance can produce carbon
monoxide which has no odor.
•
Using it in an enclosed space can
kill you.
•
Never use this appliance in an en-
closed space such as a camper, tent,
car or home.
WHEN USED AS INDOOR VENTED APPLIANCE
Installation and Operation Instructions
Superior
Vented Gas Log and Burner Set
®
Models
MNF30ONM
For use with log sets
US
LMF30GT A&B
LMF36GT A&B
IF YOU SMELL GAS:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the
MNF30OPM
LMF30MO A&B
LMF36MO A&B
WARNING: For Outdoor Use Only.
DANGER
appliance and immediately call your gas
supplier or fire department.
P900467-01
Advertisement
Table of Contents
Related Manuals for Superior Fireplaces LMF30GT
Summary of Contents for Superior Fireplaces LMF30GT
- Page 1 Vented Gas Log and Burner Set ® P/N 900467-01 Rev. B 01/2019 Models MNF30ONM MNF30OPM For use with log sets ® LMF30GT A&B LMF30MO A&B LMF36GT A&B LMF36MO A&B Report No. 10-87 WHEN USED AS AN OUTDOOR APPLIANCE WARNING: For Outdoor Use Only. DANGER...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety ..................2 Specifications ..............18 Product Identification ............3 Wiring Diagram ..............18 Local Codes.................4 Troubleshooting ..............19 Optional Remote Control Accessories ........4 Accessories ...............23 Unpacking................4 Parts ..................24 Product Features ..............4 Replacement Parts ............28 Installation ................4 Service Hints ..............28 Operation ................15 Technical Service...............28 Inspecting Burners.............16 Warranty ................29... -
Page 3: Product Identification
SAFETY Continued 1. This appliance is only for use with the type of gas indicated 15.This appliances must not be connected to any external on the rating plate. This appliance is not convertible for use electrical source. with other gases. 16.Operating appliance above elevations of 4,500 feet may 2. -
Page 4: Local Codes
LOCAL CODES INSTALLATION Install and use appliance with care. Follow all local codes. In WARNING: A qualified service person must the absence of local codes, use the latest edition of The Na- install appliance. Follow all local codes. tional Fuel Gas Code, ANSI Z223.1/NFPA 54* or CSA B149.1. *Available from: NOTICE: State or local codes may only allow American National Standards Institute, Inc. - Page 5 INSTALLATION Continued Minimum Noncombustible Material Clearances MINIMUM FIREPLACE CLEARANCE TO COMBUSTIBLE MATERIALS If Not Using Mantel Side Wall 16", Ceiling 42" NOTE: If using a mantel proceed to If Using Mantel. If not Floor 5", Front: 36" using a mantel, follow these instructions. You must have noncombustible material(s) above the fireplace LOG SIZING REQUIREMENTS* opening.
- Page 6 INSTALLATION Continued MANTEL CLEARANCES NOTICE: Surface temperatures of adjacent In addition to meeting noncombustible material clearances, walls and mantels become hot during opera- you must also meet required clearances between fireplace tion. Walls and mantels above the firebox may opening and mantel shelf. If you do not meet the clearances become hot to the touch.
- Page 7 INSTALLATION Continued INSTALLING DAMPER CLAMP ACCESSORY FOR INSTALLING APPLIANCE BASE ASSEMBLY VENTED OPERATION WARNING: You must secure this appliance NOTE: When used as a vented indoor appliance, appliance to fireplace floor. If not, appliance will move must be installed only in a solid-fuel burning fireplace with a working flue and constructed of noncombustible material.
- Page 8 INSTALLATION Continued Masonry Screw optional equipment shutoff valve from your dealer. For propane/LP units, the installer must supply an external regulator. The external regulator will reduce incoming gas pressure. You must reduce incoming gas pressure to between 11" and 14" of water. If you do not reduce incoming gas pres- sure, appliance regulator damage could occur.
- Page 9 INSTALLATION Continued Equipment Shutoff Valve PROPANE/LP 2. Cap off open end of gas pipe where equipment shutoff With 1/8" NPT Tap* From External valve was connected. Regulator 3. Pressurize supply piping system by either opening pro- Approved Flexible (11" W.C.** pane/LP supply tank valve for propane/LP gas or opening Gas Hose (if allowed to 14"...
- Page 10 INSTALLATION Continued Equipment Shutoff Valve Installing Remote Receiver Remote control accessories are available separately (see Accessories, Page 23). Read instructions shipped with re- mote control along with instructions below before attempting installation. 1. If unit is already installed in fireplace, continue with these Gas Meter instructions.
- Page 11 INSTALLATION Continued Right Front Log (D-019 or D027) Burner Switch Tube Control Valve Grate Finger Figure 17- Disconnecting Switch from Control Valve Figure 18 - Installing Right Front Log INSTALLING LOGS AND VOLCANIC STONE WARNING: Failure to position the parts in Round Tube accordance with these diagrams or failure to Burner...
- Page 12 INSTALLATION Continued Vertical Portion of Burner Tube Figure 19B - Installing Back Left Log (D-018) Rear View Figure 18C - Installing Right Front Log, Side View 3. Find the front left log (LMF30GTA/B or LMF30MOA/B mod- 2. Find the back left log (LMF30GTA/B or LMF30MOA/B mod- els: D-017, LMF36GTA/B or LMF36MOA/B models: D-025).
- Page 13 INSTALLATION Continued Square Grate Log Notch Grate Finger Log Slot Figure 21B - Installing Charred Log Top Side View Figure 20B - Installing Front Left Log 5. Find the middle split log (LMF30GTA/B or LMF30MOA/B models: D-021, LMF36GTA/B or LMF36MOA/B models: 4.
- Page 14 INSTALLATION Continued Right Split Back Top Log Crossover 6. Find the right split crossover log (D-022) The bottom of (D-023 or D029) Log (D-022) the log has a rectangular stand off that fits in the slots on the right side of the front right log and the middle split log. Place this log as shown in Figure 23.
-
Page 15: Operation
OPERATION FOR YOUR SAFETY 9. Slightly push in and turn control knob counterclockwise READ BEFORE LIGHTING to the ON position. 10.Wait one minute and move switch to the ON position to WARNING: If you do not follow these instruc- light burner. tions exactly, a fire or explosion may result NOTE: AUTO is only functional when using optional remote causing property damage, personal injury or... -
Page 16: Inspecting Burners
INSPECTING BURNERS Check pilot flame pattern and burner flame patterns often. Dark Orange PILOT ASSEMBLY Flames The pilot assembly is factory preset for the proper flame height. Alterations may have occurred during shipping and handling. Call a qualified service person to readjust the pilot if necessary. The height of the thermopile must be 3/8"... - Page 17 CLEANING AND MAINTENANCE Continued LOGS 6. In case any large clumps of dust have now been pushed into the burner repeat steps 3 and 4. • If you remove logs for cleaning, refer to Installing Logs and Clean pilot assembly also. Additional cleaning may be needed Volcanic Stone, Page 11, to properly replace logs.
-
Page 18: Specifications
SPECIFICATIONS MNF30ONM MNF30OPM • Rating (Variable): 29,000/40,000 Btu/Hr • Rating (Variable): 29,000/40,000 Btu/Hr • Type Gas: Natural • Type Gas: Propane/LP • Ignition: Electronic • Ignition: Electronic • Manifold Pressure: 3.4" W.C. • Manifold Pressure: 7.9" W.C. • Inlet Gas Pressure (in. of water): •... -
Page 19: Troubleshooting
TROUBLESHOOTING WARNING: Turn off appliance and let cool before servicing. Only a qualified service person should service and repair appliance. NOTE: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM POSSIBLE CAUSE REMEDY When igniter button is pressed, there 1. - Page 20 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY ODS/pilot lights but flame goes out 1. Control knob not fully pressed in 1. Press in control knob fully when control knob is released 2. Control knob not pressed in long 2. After ODS/pilot lights, keep control enough knob pressed in 30 seconds 3.
- Page 21 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Slight smoke or odor during initial 1. Residues from manufacturing 1. Problem will stop after a few hours operation processes and logs curing of operation Appliance produces a whistling 1. Turning control knob to HI position 1.
- Page 22 TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instruc- tions.
-
Page 23: Accessories
ACCESSORIES WALL-MOUNT ON/OFF SWITCH Purchase these appliance accessories from your local dealer. If they can not supply these accessories, contact IHP at Supe- (REMOTE READY MODELS ONLY) riorFireplaces.US.com for referral information. You can also Cat No. F0245, Model GWMS2 write to the address listed on the back page of this manual. For all models. -
Page 24: Parts
PARTS REMOTE-READY CONTROL MODELS MNF30ONM and MNF30OPM Cat. No. Model F2128 MNF30ONM F2130 MNF30OPM f i r e - p a r t s . c o m SuperiorFireplaces.us.com 900467-01B... - Page 25 PARTS REMOTE-READY MODELS MNF30ONM and MNF30OPM This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed under Replace- ment Parts on Page 28 of this manual. WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP.
- Page 26 PARTS LOG SET MODELS LMF30GTA/B, AND LMF36GTA/B This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed under Replacement Parts on Page 28 of this manual. f i r e - p a r t s . c o m LMF30GTA/B LMF36GTA/B CAT.
- Page 27 PARTS LOG SET MODELS LMF30MOA/B, AND LMF36MOA/B This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed under Re- placement Parts on Page 28 of this manual. f i r e - p a r t s . c o m LMF30MOA/B LMF36MOA/B CAT.
-
Page 28: Replacement Parts
REPLACEMENT PARTS See Pages 24-27 for a complete replacement parts list. Use 1. The model number of the appliance. only parts supplied from the manufacturer. 2. The serial number of the appliance. 3. The part number. Normally, all parts should be ordered through your IHP dis- 4. -
Page 29: Warranty
Innovative Hearth Products Superior Brand Gas Log Set ® Limited Three Year Warranty THE WARRANTY Innovative Hearth Products Limited Three Year Warranty ("IHP") warrants your Superior brand Gas Log Set ("Product") to be free from defects in materials and workmanship ®... - Page 30 SuperiorFireplaces.us.com Record the following important information about your appliance: Appliance model number Appliance serial number Date appliance was Installed Type of gas appliance uses Dealer name f i r e - p a r t s . c o m Innovative Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
