Frigidaire GLTF2070D Factory Parts Catalog

Front-load washing machine
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual
P12L0046.eps P12C0322.eps P12V0060.eps P12T0075.eps
134389100_2.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
GLTF2070DS0
Series
Frigidaire
Market
Gallery
Color
white
Volts
120
Wiring Diagram
134389100
Owner's Guide
134305700
Energy Guide
134381700
Installation Instructions 134305600
Installation Instructions 134305500
134389100_1.eps
Publication No.
5995404521
04/02/24
(EN/SERVICE/KC)
361
FRONT-LOAD
WASHING MACHINE
Model No.
GLTF2070D
Copyright
2003 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

Related Manuals for Frigidaire GLTF2070D

Summary of Contents for Frigidaire GLTF2070D

  • Page 1 Color white Volts Wiring Diagram 134389100 Owner's Guide 134305700 Energy Guide 134381700 Installation Instructions 134305600 Installation Instructions 134305500 FRONT-LOAD 134389100_1.eps WASHING MACHINE GLTF2070D Publication No. 5995404521 04/02/24 (EN/SERVICE/KC)  Copyright 2003 Electrolux Home Products, Inc. Model No. All rights reserved.

  • Page 2: Control Panel

    Publication No: 5995404521 GLTF2070DS0 CONTROL PANEL 02/04...
  • Page 3 POS. NO PART NO. 131272100 131272000 131271910 134202900 131427500 131373800 134224500 12 # 134204300 17 # 134381100 18 # 134207750 134205400 131243700 131823400 134208250 131786100 131306216 36 # 131974700 131271600 131803710 131863300 131307900 131168200 131749200 44 # 131899800 134191413 46*# 134201700 131931201 134205500...
  • Page 4 Publication No: 5995404521 02/04 GLTF2070DS0 CABINET/TOP P12V0060...
  • Page 5 Hinge, door Screw, quad pan head, 10-16 x 0.312 Pin, panel locator, side Panel, Service, white, kick plate Screw, hex washer hd, 8-18AB x 1.125 Screw, pan head, 8-18AB x 0.375, cr/sq drive Retainer, spring steel Panel, dryer top, white, top Bracket, top panel mtg.
  • Page 6 Publication No: 5995404521 02/04 GLTF2070DS0 MOTOR/TUB P12T0075...
  • Page 7 Screw, hex washer head, 1/4-10A x 2.165 Drum Assy, spin basket Vane Screw, vane mtg., 10-16AB x 0.375 Motor Screw, hex washer head, 12-14AB x 1.50, motor mtg. O-ring, tub Shell, outer tub, rear, with bearing Counterweight, drum rear Belt, drive-V, 6-rib Pulley, drive, large, drum rear, reinforced Washer, 0.41 x 1.50, 0.12 thick...

  • Page 8: Wiring Diagram

    Publication No: 5995404521 GLTF2070DS0 WIRING DIAGRAM 02/04...
  • Page 9 GLTF2070DS0 Publication No: 5995404521 WIRING DIAGRAM 02/04 # Functional Parts * Non-Ilustrated Parts...
