Vision Sensor
FZ3-30_-10/FZ3-35_-10/FZ3-H30_-10/FZ3-H35_-10
FZ3-70_-10/FZ3-75_-10/FZ3-H70_-10/FZ3-H75_-10
FZ3-90_-10/FZ3-95_-10/FZ3-H90_-10/FZ3-H95_-10
FZD-50_-10/FZD-55_-10
INSTRUCTION MANUAL
Thank you for selecting the FZ Series Vision Sensor.
This manual explains how to use the FZ Series Vision Sensor.
When using the FZ Series Vision Sensor, make sure to observe the following:
• The FZ Series Vision Sensor must be operated by personnel
knowledgeable in electrical engineering.
• To ensure correct use, please read this manual thoroughly to deepen your
understanding of the product.
• Please keep this manual in a safe place so that it can be referred to whenever necessary.
The meaning of "_" in model is described below.
0:NPN I/O type
TRACEABILITY INFORMATION:
Representative in EU:
Omron Europe B.V.
Wegalaan 67-69 2132 JD Hoofddorp,The Netherlands
Manufacturer:
Omron Corporation, Sensing Devices & Components Div. H.Q.,
Application Sensors Division
Shiokoji Horikawa,Shimogyo-ku, Kyoto 600-8530 JAPAN
NOTICE:
This product meets CISPR11 class A.
The intended use of this product is in an industrial environment only.
OMRON Corporation 2009 All Rights Reserved.
FZ Series
5:PNP I/O type
(SETUP)
5319282-8C
Advertisement
Table of Contents
Related Manuals for Omron FZ Series
Summary of Contents for Omron FZ Series
- Page 1 Thank you for selecting the FZ Series Vision Sensor. This manual explains how to use the FZ Series Vision Sensor. When using the FZ Series Vision Sensor, make sure to observe the following: • The FZ Series Vision Sensor must be operated by personnel knowledgeable in electrical engineering.
- Page 2 PRODUCTS, WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT LIABILITY. In no event shall responsibility of OMRON for any act exceed the individual price of the product on which liability is asserted. IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS REGARDING THE PRODUCTS UNLESS OMRON’S ANALYSIS CONFIRMS THAT THE PRODUCTS...
-
Page 3: Meanings Of Signal Words
Meanings of Signal Words The following signal words are used in this manual. Indicates a potentially hazardous situation which, if not avoided, will result in minor or moderate injury, or WARNING may result in serious injury or death. Additionally there may be significant property damage. Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury CAUTION or in property damage. -
Page 4: Precautions For Correct Use
55_-10) at its base, it will short-circuit to the FG of your device since the bottom surface is connected to the SG (0V). In order to avoid this, we provide insulating spacers. Please consult your OMRON representative for information. Camera cable... -
Page 5: Confirming Package Contents
• Do not install the product within 200 mm of power cables. • Component Installation and Handling • OMRON Components Use only the camera and cables designed specifically for the product. Failure to observe this may result in malfunction or damage of the product. -
Page 6: Basic Configuration
FZ-VM (2 m, 5 m) Long-distance Right-angle camera cable FZ-VSL2 (15m) Camera Power Supply Detects workpieces as images. Recommended Model Intelligent camera Automatic focus camera By OMRON Corporation S8VS-18024 Peripheral Device Standalone camera FZ-SC/FZ-S FZ-SC2M/FZ-S2M USB memory FZ-SC5M/FZ-S5M FZ-MEM1G FZ-SFC/FZ-SF FZ-SPC/FZ-SP... - Page 7 FZ-VSL (2 m, 5 m, 10 m) FZ-VM (2 m, 5 m) Camera Power Supply Detects workpieces as images. Recommended Model 3D vision camera FZD-STC2M By OMRON Corporation S8VS-18024 Peripheral Device USB memory Standalone camera FZ-SC/FZ-S FZ-MEM1G FZ-SC2M/FZ-S2M Input Device...
-
Page 8: Component Names And Functions
Component Names and Functions • LCD integrated type FZ3-300-10/FZ3-305-10/FZ3-H300-10/FZ3-H305-10/FZ3-700-10/FZ3-705-10 FZ3-H700-10/FZ3-H705-10/FZ3-900-10/FZ3-905-10/FZ3-H900-10 FZ3-H905-10/FZD-500-10/FZD-505-10 Left-side view Front view Right-side view RS-232C/RS-422 connector Power/ ground I/O connector terminal (control lines, data lines) Monitor connector (analog RGB) Ethernet connector Camera connector USB connector POWER LED RUN LED USB connector Touch pen (holder) -
Page 9: Parallel Interface
Parallel Interface NPN I/O type FZ3-300-10/FZ3-350-10/FZ3-H300-10/FZ3-H350-10/FZ3-700-10/FZ3-750-10/FZ3-H700-10 FZ3-H750-10/FZ3-900-10/FZ3-950-10/FZ3-H900-10/FZ3-H950-10/FZD-500-10/FZD-550-10 • Internal Specifications [Input] signals: STEP0/ENCTRIG_Z0, STEP1/ENCTRIG_Z1, [Input] signals: RESET, DI0 to DI7, DSA0, DSA1 ENCTRIG_A0 to 1, ENCTRIG_B0 to 1 Input voltage 12 to 24 V DC ±10 % Input voltage 12 to 24 V DC ±10 % ON current *1 5 mA min. - Page 10 Parallel Interface PNP I/O type FZ3-305-10/FZ3-355-10/FZ3-H305-10/FZ3-H355-10/FZ3-705-10/FZ3-755-10/FZ3-H705-10 FZ3-H755-10/FZ3-905-10/FZ3-955-10/FZ3-H905-10/FZ3-H955-10/FZD-505-10/FZD-555-10 • Internal Specifications [Input] signals: STEP0/ENCTRIG_Z0, STEP1/ENCTRIG_Z1, [Input] signals: RESET, DI0 to DI7, DSA0, DSA1 ENCTRIG_A0 to 1, ENCTRIG_B0 to 1 Input voltage 12 to 24 V DC ±10 % Input voltage 12 to 24 V DC ±10 % ON current *1 5 mA min.
-
Page 11: Serial Interface
• Recommended items Use a shielded cable. Manufacturer Model Pin numbers will depend on the external device being connected. Refer Plug OMRON Corporation XM2A-0901 to the manual for the personal computer or PLC being connected. Hood OMRON Corporation XM2S-0911 •... - Page 12 Mounting • LCD integrated type (Unit: mm) • Panel mounting Make a mount hole on the panel. Panel thickness range: 1.6 to 4.8 mm Panel material: Metal (iron, aluminum or stainless) * No burr allowed Insert the LCD integrated controller into the hole, from the front panel.
- Page 13 Controller External Dimensions • LCD integrated type FZ3-300-10/FZ3-305-10/FZ3-H300-10/FZ3-H305-10 FZ3-700-10/FZ3-705-10/FZ3-H700-10/FZ3-H705-10 FZ3-900-10/FZ3-905-10/FZ3-H900-10/FZ3-H905-10 FZD-500-10/FZD-505-10 (Unit: mm) 4-M3 Depth 6 12.8 28.4 • Box type FZ3-350-10/FZ3-355-10/FZ3-H350-10/FZ3-H355-10 FZ3-750-10/FZ3-755-10/FZ3-H750-10/FZ3-H755-10 FZ3-950-10/FZ3-955-10/FZ3-H950-10/FZ3-H955-10 FZD-550-10/FZD-555-10 (Unit: mm) 4-M4 Depth 6 4-M4 Depth 6 – 11.5 4-M4 Depth 6...
-
Page 14: Controller Specifications
Sensing Devices Division H.Q. Tel: (1) 847-843-7900/Fax: (1) 847-843-7787 Application Sensors Division Shiokoji Horikawa, Shimogyo-ku, OMRON ASIA PACIFIC PTE. LTD. Kyoto, 600-8530 Japan No. 438A Alexandra Road # 05-05/08 (Lobby 2), Tel: (81) 75-344-7068/Fax: (81) 75-344-7107 Alexandra Technopark, Singapore 119967...
