Frigidaire FRT21G4B Factory Parts Catalog
Top mount refrigerator r134a series
Hide thumbs
Also See for FRT21G4B:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
Download this manual
See also:
Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT21G4BQ3
FRT21G4B
FRT21G4BW3
FRT21G4B
MARKET
North America
WIRING DIAGRAM - # 240379009
OWNER'S GUIDE - # 240400105
SERVICE DATA SHEET - # 240379009
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
Publication No.
5995372421
020520
-EN/SERVICE /KC
357
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21G4B
©2002 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT21G4B
Summary of Contents for Frigidaire FRT21G4B
- Page 1 PRODUCT NO. BASE MODEL NO. FRT21G4BQ3 FRT21G4B FRT21G4BW3 FRT21G4B MARKET North America WIRING DIAGRAM - # 240379009 OWNER’S GUIDE - # 240400105 SERVICE DATA SHEET - # 240379009 ELECTROLUX HOME PRODUCTS, INC P.O. Box 212378, Augusta, GA 30917 SERIES COLOR...
- Page 2 Publication No. FRT21G4B 5995372421 DOOR 05/02...
- Page 3 A = FRT21G4B (FRT21G4BQ3) B = FRT21G4B (FRT21G4BW3) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRT21G4B DOOR PART NO DESCRIPTION 240514607 Gasket,frzr door seal ,white ,magnetic 240514608 Gasket,refr door seal ,white ,magnetic 240331401 Rack-door,20.27" x 1.72" 240311502...
- Page 4 Publication No. FRT21G4B 5995372421 CABINET 05/02...
- Page 5 A = FRT21G4B (FRT21G4BQ3) B = FRT21G4B (FRT21G4BW3) POS. NO 10*# 13 # # = Fast-moving Parts * = Non-Illustrated Parts FRT21G4B CABINET PART NO DESCRIPTION 240355402 Cover-fan 240433201 Screw,hex washer head ,8-18 x 0.375 240367001 Knob-damper control 5303001028 Nut,push-on...
- Page 6 Publication No. FRT21G4B 5995372421 SHELVES 05/02...
- Page 7 A = FRT21G4B (FRT21G4BQ3) B = FRT21G4B (FRT21G4BW3) POS. NO 14 # 17*# 21 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts FRT21G4B SHELVES PART NO DESCRIPTION 215667501 Tray,ice cube ,plastic 240358003 Shelf,freezer ,full-width ,wire 5303299664 Spacer,shelf...
- Page 8 Publication No. FRT21G4B 5995372421 SYSTEM 05/02...
- Page 9 A = FRT21G4B (FRT21G4BQ3) B = FRT21G4B (FRT21G4BW3) POS. NO 14 # 15 # 21 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts FRT21G4B SYSTEM PART NO DESCRIPTION 240444401...
-
Page 10: Wiring Schematic
Publication No. FRT21G4B 5995372421 WIRING SCHEMATIC 05/02... -
Page 11: Wiring Diagram
FRT21G4B Publication No. 5995372421 WIRING DIAGRAM # = Fast-moving Parts 05/02 * = Non-Illustrated Parts...
